About the Infinity Kappa 62ix
The legend continues...
The legend continues...
Infinity's reputation is legendary, but their Kappa Series car speakers don't rest on those laurels. Designed and built for audiophile tastes, these Kappa 62ix 6-1/2" speakers benefit from a refined design, Infinity's proprietary technology, and premium materials to deliver uncompromised audio quality.
Edge-driven dome tweeters
Infinity employs an edge-driven design in their soft dome tweeters for a smoother, more open response and minimal distortion at high volume. The UniPivot tweeter design means you can aim each tweeter toward your ears, so you'll enjoy excellent stereo imaging even if the speakers are mounted way down low in your doors. Each tweeter also features a level control button so you can adjust the brightness to your taste.
Woofers enhanced with Plus One+ technology
Bring on the bass. Kappa's glass fiber woofer will hold its shape when the power's cranked up, so you still get punchy and defined bass. Glass fiber weighs less than traditional materials, so you don't need a ton of power to drive this woofer either. Infinity's Plus One+ woofer technology extends the cone right up to the edge of the basket, giving you lots of surface area — and a bigger cone means more bass to complement the superior high-frequency response.
Awesome power handling, no matter the system
These 2.5-ohm speakers boast ultra-high sensitivity so that you can power them with a factory radio or aftermarket stereo, but you'll get your best results feeding them plenty of power from an outboard amp. Either way, these speakers' low impedance safely takes advantage of every watt of power available for exceptional performance. Enjoy Kappa sound quality at any volume. Grilles are included.
- 6-1/2" 2-way car speakers
- Plus One+ glass-fiber woofer cone with hi-roll rubber surround
- edge-driven, soft dome tweeter
- included brackets allow mounting in a variety of 6-3/4" and 6-1/2" openings
- 2.5-ohm impedance
- handles up to 75 watts RMS (225 watts peak power)
- frequency response: 45-25,000 Hz
- sensitivity: 95 dB at 2.83 volts
- top-mount depth: 2-1/16"
- grilles included
- warranty: 3 years
- Our 60-day money-back guarantee
- MFR # KAPPA-62IX
What's in the box:
- Two 2-way speakers
- 2 Grilles
- 2 Grille frames
- 2 Plastic adapter brackets
- Eight 1-3/8" Screws
- Eight 1/2" Screws
- 8 Speed clips
- 2 Adhesive backed foam gaskets
- 2 Adhesive backed Infinity logo badges
- Template on box
- Installation manual
More details on the Infinity Kappa 62ix
Features & specs
|Speaker Size||6 1/2|
|Tweeter Design||Edge-Driven Dome|
|Woofer Composition||Glass Fiber|
|Parts Warranty||3 Years|
|Labor Warranty||3 Years|
|Sensitivity (1W at 1 meter)||N/A|
|Sensitivity at 2.83 volts||95|
|Frequency Response||45 - 25k Hz|
|Minimum RMS Wattage||---|
|Maximum RMS Wattage||75|
|Peak Power Handling (Watts)||225|
|Top-mount Depth (Inches)||2 1/8|
|Bottom-mount Depth (Inches)||2 7/16|
|Cutout Diameter or Length (inches)||5 1/8|
Plus One Woofer Cones: The Plus One speaker cones offer more surface area than other speakers that fit in the same size opening. This is accomplished by using a new basket design and hi-roll surround. The result is greater bass output and an increase in efficiency.
High-Output Design: The high output 2.5Ω voice coil design compensates for the high in-line resistance of small gauge factory wiring and extracts every watt from factory receivers, increasing overall system output and efficiency (relative to 4Ω speakers). The speakers also benefit from increased power when you upgrade the wire and add aftermarket amplifiers, designed to power a 2.5Ω load.
Edge Driven Dome Tweeters: Each speaker has an Edge-driven textile dome tweeter. Edge-driven tweeters have better dispersion characteristics and allow for a lower crossover frequency than typical tweeters of the same size, which improves imaging, vocals and musical clarity. The tweeter also has an output level switch; choose +0 dB (flat) or +3 dB.
UniPivot Tweeter: The tweeter is angled and can be rotated about 270° after installation. This allows you to direct the tweeters toward the listeners, useful for speakers mounted low in a door.
Mounting Applications: These speakers are marketed as 6-1/2"; they will fit in standard 6-1/2" speaker openings (approximately 5" diameter), but do not use the standard 6-1/2" speaker bolt pattern. In order to install them in standard 6-1/2" speaker openings you must drill new screw holes. If new holes are drilled in the mounting surface of the car, no bracket is needed. If drilling in the car is not an option, the included brackets can be used, which have standard 6-1/2" mounting holes and the Ford non-symmetric four hole pattern. When using the brackets the depth becomes 1.866" and the mounting height becomes 1.056".
Terminals: The input terminals are set screws that will accept up to 12 gauge bare wire.
