Infinity Reference REF-9630cx

6"x9" component speaker system

Item # 108R9630CX

One thing's for sure — our customers love Infinity's Reference Series speakers.

Find what Fits your car

One thing's for sure — our customers love Infinity's Reference Series speakers.

Item # 108R9630CX

Ships free

In Stock
C$399.99
Add to wishlist

About the Infinity Reference REF-9630cx

Classic components

One thing's for sure — our customers love Infinity's Reference Series speakers. Year after year, car after car, options like this Reference Series REF-9630cx 6"x9" component speaker system remain a popular choice for replacing factory speakers because of their competitive pricing and superb sound.

Classic components

One thing's for sure — our customers love Infinity's Reference Series speakers. Year after year, car after car, options like this Reference Series REF-9630cx 6"x9" component speaker system remain a popular choice for replacing factory speakers because of their competitive pricing and superb sound.

Edge-driven dome tweeters

With this component system, you'll gain exceptional clarity and imaging, thanks to seperate 3/4" edge-driven textile dome tweeters that subdue any harshness in the high-frequency range. Infinity includes external crossovers that give you push-button tweeter attenuation for a "brightness" quick fix.

Bigger woofers

The Reference Series polypropylene woofer with its durable hi-roll rubber surround ensures you'll enjoy powerful sound every mile you drive. Its oversized cone moves more air than other speakers of similar size, adding plenty of punch to the speaker's impressive performance.

Bring on the power

You can power these speakers with up to 125 watts of RMS power — they'll work well with an external amplifier, but they're also a good match for a factory radio or aftermarket stereo. Plus, these 3-ohm speakers combine with the speaker wire in your vehicle so your car stereo sees actual 4-ohm impedance, so you get a little more volume out of your system.

READ LESS

Product highlights:

  • component speaker system includes 2 woofers, 2 tweeters, and 2 crossovers
  • 6"x9" Plus One+ polypropylene woofer with hi-roll rubber surround
  • 3/4" edge-driven textile dome tweeter
  • Starfish™ mounting brackets for easier tweeter installation in factory locations
  • True Four Ohm Impedance technology
    • speaker's 3-ohm impedance combines with speaker wire impedance for a 4-ohm load
    • compatible with virtually all factory or aftermarket car stereos
  • tweeter adjustment circuits (0, +3 dB)
  • handles up to 125 watts RMS (375 watts peak power)
  • frequency response: 46-21,000 Hz
  • sensitivity: 93 dB
  • woofer mounting depth: 3-1/16
  • grilles included
  • warranty: 1 year
  • Our 60-day money-back guarantee
  • MFR # REF9630CX
KEEP READINGREAD LESS

What's in the box:

  • 2 Woofers
  • 2 Tweeters (each has attached 6" speaker leads)
  • 2 Woofer grilles
  • 2 Woofer grille frames
  • 2 Woofer bottom mount rings
  • 2 Crossovers
  • 2 Tweeter flush-mount housings
  • 2 Threaded flush-mount adapters
  • 2 Plastic locking nuts
  • 2 Tweeter surface-mount housings
  • 2 Starfish tweeter mounts
  • Eight 1-3/8" Screws
  • Eight 1-1/8" Screws
  • 8 Speed clips
  • Six 5/8" Flat head screws
  • 2 Washers
  • 2 Nuts
  • 2 Adhesive backed foam gaskets
  • 2 Infinity logos
  • Instruction manual
  • Template on box

Customer reviews

Loading reviews...

Infinity Reference REF-9630cx reviews

Average review:

17 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Highly recommend

Crutchfield customer from Olivet, MI on 3/24/2019

2003 Buick Century

Verified customer (What's this?)
Verified employee purchase (What's this?)

Very clean sound using Kenwood exelon receiver jl audio amp as speakers go it don't get much better than this

Pros: Everything

Cons: None

Crutchfield response on

0 of 0 found this helpful

Great set of speakers

Crutchfield customer from South Riding, VA on 3/22/2019

Verified customer (What's this?)
Verified employee purchase (What's this?)

Great upgrade to replace factor original speakers. Very crisp sound from tweeters and good bass from woofers.

Pros: Crisp highs and nice additional bass as compared to stock.

Cons: None, but I still wanted yet more bass so I added a custom subwoofer box and amp.

Crutchfield response on

0 of 0 found this helpful

Great Upgrade

Andrew from Portland, OR on 3/8/2019

2006 Nissan Xterra

Verified customer (What's this?)
Verified employee purchase (What's this?)

Installed in a 2006 Nissan Xterra without RF Premium System. Really satisfied with the sound on these speakers. I have had an aftermarket head unit for years with the stock speakers and finally decided to upgrade them. What a huge difference. The imaging and separation of instruments is fantastic. I took off one star due to a bit of sibilance in the tweeters. Some tracks can be a little harsh on the "S's", but it's not bad by any means. Setting the tweeters to zero on the crossover helped. That is a nice feature. wanted the largest woofers that would fit in the front doors as I didn't want to do a sub on this one. They provide plenty of clean low end that is very punchy. I would suggest installing dynamat in the doors. These woofers move some air and they rattle the doors. I picked some up at the local shop that solved the problem. I had them installed with no amp at first because I didn't have the time to do all the wiring. They were pretty lifeless only powered off the head unit. Finally got the Sound Ordnance M-75-4 installed and it is night and day. This amp drives these really nicely to ear splitting levels. You definitely want an amp with these component speakers. I installed the IR 6.5 inch coax in the rear doors and they seem to be a great match. Good product. I'm happy

Pros:

Cons:

Crutchfield response on

0 of 0 found this helpful

Infinity Reference REF-9630cx

Lewis from Philadelphia, PA on 2/10/2019

2008 Toyota 4Runner

Verified customer (What's this?)
Verified employee purchase (What's this?)

Great sound with dynamat

Pros:

Cons:

Crutchfield response on

0 of 0 found this helpful

Tweeters very harsh.

Tim from Upland, CA on 1/7/2019

2006 Dodge Ram 2500

Verified customer (What's this?)
Verified employee purchase (What's this?)

Woofer puts out a decent amount of bass, but that tweeter is so bright and hissy. I've removed the highest frequencies using my head unit's equalizer. But I'm considering re-installing the stock (upgraded) tweeters, or returning the whole package.

Pros: Great bass

Cons: Tweeters sound hissy.

Crutchfield response on

0 of 0 found this helpful

Infinity Reference REF-9630cx

Edward from Wickenburg, AZ on 12/22/2018

1967 Chevrolet Impala

Verified customer (What's this?)
Verified employee purchase (What's this?)

Chose these speakers after I installed 4 Infinity speakers in my 2000 F-150. I'm building a system for my 1967 Impala. These fit will fit in the rear deck and sail panels. These sound great.

Pros:

Cons:

Crutchfield response on

0 of 0 found this helpful

2010 Camaro Infinity install

Jeff from Osceola, In. on 12/20/2018

2010 Chevrolet Camaro

Verified customer (What's this?)
Verified employee purchase (What's this?)

Installed these in my 2010 Camaro. Used stock head unit. Had to modify the stock installation location (top of rear deck) to make them work for me. Used Boston Acoustics tweeter mounts with Infinity tweeters. Made under deck mounts for 6x9's. Replaced stock BA amp with an Alpine PDR-F50. These speakers sound GREAT. Clarity is great, lows are good, highs not shrill but well defined. With a 10" sub and and amp and 6.5" Infinity Reference speakers in the doors my Camaro Rocks, sounds much better than stock Boston Acoustic system. JL Audio TWK 88 also helped in this setup. Highly recommend Infinity speakers and Crutchfield.

Pros: Super sound ,Great price (purchased on sale), Great customer service.

Cons:

Crutchfield response on
Customer review photo Customer review photo Customer review photo Customer review photo Customer review photo

0 of 0 found this helpful

Infinity Reference REF-9630cx

Jake from Gardner, KS on 12/18/2018

2007 Dodge Ram 3500

Verified customer (What's this?)
Verified employee purchase (What's this?)

Easy to install, good bass, great quality! They definitely made a great difference in my Mega Cab. I would definitely buy these again!

Pros: A definite upgrade to even the stock Infiniti system. Much higher quality,

Cons: ....

Crutchfield response on

0 of 0 found this helpful

100 times Bettter than the Factory Speakers!

Chip from Portland, ME on 12/10/2018

2011 Toyota Tacoma

Verified customer (What's this?)
Verified employee purchase (What's this?)

These speakers are beautiful sounding. No comparison with the factory Toyota speakers. This is the first time I have installed component speakers and the difference is remarkable. Finding a location for the crossover behind the door panel was a bit of a challenge, but was able to make it fit eventually without adding any extensions to the speaker wire.

Pros: Concert-hall sound.

Cons: Crossover is a little big and challenging to locate in the door panel.

Crutchfield response on

0 of 0 found this helpful

Infinity Reference REF-9630cx

Jeff from Gilbertsville, PA on 12/10/2018

2005 Toyota Tacoma

Verified customer (What's this?)
Verified employee purchase (What's this?)

Great speakers and big upgrade to my 05 Tacoma. Crutchfield supplies everything you need to DIY install, including years of knowledge if you run into a problem.

Pros: clear sound big improvement over any stock speakers

Cons:

Crutchfield response on

0 of 0 found this helpful

Clear and accurate sound

Crutchfield customer from Weddington, NC on 12/4/2018

2016 Chevrolet Camaro

Verified customer (What's this?)
Verified employee purchase (What's this?)

Great upgrade for a 2016 Camaro speakers. Followed Crutchfield Advisor's advice to purchase and install these. Crutchfield's excelent and clear instructions made the installation go smoothly. Ne speakers result is much clearer, cleaner sound, with high highs and great bass. This set is a huge upgrade over the Camaro's OEM from speaker set. List of installation accessories was perfect.

Pros:

Cons:

Crutchfield response on

0 of 0 found this helpful

Infinity Reference REF-9630cx

Crutchfield customer from Newnan, GA on 11/3/2018

2009 Toyota Tacoma

Verified customer (What's this?)
Verified employee purchase (What's this?)

I am happy with these speakers.

Pros:

Cons:

Crutchfield response on

0 of 1 found this helpful

Infinity Reference REF-9630cx

Crutchfield customer from High Point, NC on 10/23/2018

2015 Chevrolet Silverado 1500

Verified customer (What's this?)
Verified employee purchase (What's this?)

Great upgrade from the factory speakers!

Pros:

Cons:

Crutchfield response on

0 of 1 found this helpful

Speakers

Pat from San Diego, Ca on 10/21/2018

Verified customer (What's this?)
Verified employee purchase (What's this?)

Great combo nice speakers good sound

Pros: Nicely built Quality Sound

Cons: Need good amp

Crutchfield response on

0 of 1 found this helpful

Infinity Reference REF-9630cx

Crutchfield customer from Tucson, AZ on 9/24/2018

2006 Dodge Ram 2500

Verified customer (What's this?)
Verified employee purchase (What's this?)

Installed in a 2006 Dodge Ram 2500 Quad cab. 6 x 9's easily fit in doors with no modifications. Tweeters installed in outer factory dash locations. Needed to make mounting plates that lowered speakers approximately 1/2" so tweeters could be angled slightly for better sound. Took my time and turned out great. Sound and separation of component speakers is awesome.

Pros:

Cons:

Crutchfield response on

1 of 1 found this helpful

Nice package

Jeffery from Daphne, AL on 8/7/2018

2007 Dodge Ram 1500

Verified customer (What's this?)
Verified employee purchase (What's this?)

Very nice set of speakers, versatility and they can put some very nice bass out if your trying to build a system with no subwoofer.

Pros: As advertised gor sound quality

Cons: Crossover boxes are not that sturdy but work excellent, just be gentle.

Crutchfield response on
Customer review photo

2 of 2 found this helpful

Infinity Reference REF-9630cx

Crutchfield customer from Carrollton, TX on 6/11/2018

2016 Toyota 4Runner

Verified customer (What's this?)
Verified employee purchase (What's this?)

Sounds great

Pros:

Cons:

Crutchfield response on

0 of 1 found this helpful

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the Infinity Reference REF-9630cx

Pat M.

Features & specs

General
Speaker Size 6X9
Design 2-way
Tweeter Design 3/4" Edge-Driven Dome
Impedance (Ohms) 3
Tweeter Composition Textile
Woofer Composition Polypropylene
Woofer Surround Rubber
Parts Warranty 1 Year
Labor Warranty 1 Year
Specifications
Sensitivity (1W at 1 meter) N/A
Sensitivity at 2.83 volts 93
Frequency Response 46 - 21k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 125
Peak Power Handling (Watts) 375
Top-mount Depth (Inches) 3 1/8
Bottom-mount Depth (Inches) 3 11/16
Cutout Diameter or Length (inches) 0

Product Research

Woofers
Tweeters
Crossovers
Specifications

Woofers

Plus One+ Woofer Cones: Each speaker uses a larger cone than other speakers of the same size. This is accomplished by using a unique basket design and hi-roll surround. The Plus One+ design offers greater bass output and an increase in efficiency.

Hi-roll Rubber Surrounds: The hi-roll rubber surrounds allow the woofers a greater range of movement, resulting in longer X-max and more bass output.

Tweeters

Material: Each tweeter features a 3/4" edge-driven textile dome for smooth, accurate highs.

Mounting: The I-Mount tweeter mounting system and Starfish mounting brackets give you several different ways to mount the tweeters:

  • I-Mount: The tweeters can be surface- or flush-mounted with Infinity's innovative I-Mount system:
    • Surface Mount: Surface mounting the tweeters involves screwing the surface-mount cup to the mounting location, then inserting and locking the tweeter into the cup.
    • Flush Mount: Flush mounting is made easy through the use of the threaded flush-mount housing and plastic locking nut. Once a cutout is made, the tweeter is installed in the flush-mount adapter, then into the flush mount housing and inserted into the hole. The large plastic locking nut is threaded onto the adapter (from behind the mounting surface) to hold the complete assembly securely in place. When flush mounted, the tweeters may be angled for optimum response and imaging.
  • Starfish Mounting Brackets: The Starfish mounting brackets allow the tweeters to be installed in factory locations behind the grilles:
    • Bottom Mount: Once the Starfish bracket is trimmed, it is secured to the underside of the grille panel. The tweeter must be inserted into the bracket and locked into place before the bracket is mounted.
    • Surface Mount: Once the Starfish bracket is trimmed, it is screwed to the top of the mounting surface behind the grille panel. Then, the tweeter is inserted into the bracket and locked into place.
    • Flush Mount: There are two sets of tabs to flush mount the tweeter in the Starfish bracket, yielding different mounting dimensions. The upper tabs mount the tweeter completely below the opening and are glued in place. The lower mounting tabs are screwed in place and result in a mounting height just under a half inch. Once the bracket is mounted, the tweeter is inserted into the bracket and locked into place.

Dimensions:

  I-Mount Surface Mount I-Mount Flush Mount Starfish Bottom Mount Starfish Surface Mount Starfish Flush Mount Starfish Flush Mount (below mounting surface)
Mounting Height 0.854" 0.65" 0.0" 0.857" 0.386" 0.286"
Depth screw depth 0.786" 0.930" screw depth 0.471" 0.571"
Frame Diameter 1.474" 1.838" 3.036" 2.440" 2.330" 2.330"
Cutout Diameter N/A 1.581" N/A N/A 1.504" 1.257"

Crossovers

Selectable Tweeter Output Level: Each 2-way crossover allows you to select the tweeter output level according to system requirements and personal preference; the tweeter level can be set to +3 dB or 0 dB.

Connections: The crossover inputs and outputs are screw terminals; they will accommodate bare wire or spade connectors up to 0.31" wide. There are four mounting holes in each crossover.

Dimensions:

  • Width: 4"
  • Height: 1-1/8"
  • Depth: 3-1/4" (plus wire)

Specifications

High-Output Design: The 3Ω voice coil design compensates for the high in-line resistance of small gauge factory wiring, extracting more power from factory (or aftermarket) receivers. This results in clearer, richer sound for the listener.

Loading accessories...

Customer Q&A

Q
Crutchfield asked: Why did you buy this?
A
So excited to hear what this recommendations and system sounds like. Thanks. [ Richard  Nov 26, 2018 ]
A
Included for free, glad to have a reference to look at just incase [ Matthew  Nov 25, 2018 ]
A
After extensive research and talking to Crutchfield advisors I decided infinity was best choice for my factory upgrade for my 2018 Jeep grand cherokeee . These speakers allow me to step up my system will start with just speakers then these speakers will handle a amp latter down the road [ Jonathan  Nov 24, 2018 ]
A
I have a pair of Infinity reference 5 1/4 and they sound great. This will make a matched set of Infinitys. Super clean sound [ Shane  Nov 22, 2018 ]
A
adviser recommended them [ Nathan  Oct 04, 2018 ]
SHOW MORESHOW LESS

1 question already asked

Q
What's the minimum rms power this unit requires to work at its best?
[ hosein  Jun 10, 2018 ]
1 answer
A
The Infinity Reference REF-9630cx speakers would typically sound best with an aftermarket amplifier pushing close to 100 watts RMS per channel. For more help on selecting an amplifier, please contact an Advisor directly by phone (888.955.6000) or online chat. Thanks!
[ Larry  Jun 15, 2018 ]  Staff
