Infinity Reference REF-9632ix 6"x9" 2-way car speakers

Item # 108R9632IX

One thing's for sure — our customers love Infinity's Reference Series speakers.

Find what Fits your vehicle

Remove

Checking fit...

One thing's for sure — our customers love Infinity's Reference Series speakers.

Item # 108R9632IX

About the Infinity Reference REF-9632ix

Alexander H.

A modern classic

One thing's for sure — our customers love Infinity's Reference Series speakers. Year after year, car after car, options like these Reference Series REF-9632ix 6"x9" car speakers remain a popular choice for replacing factory speakers because of their competitive pricing and superb sound.

A modern classic

One thing's for sure — our customers love Infinity's Reference Series speakers. Year after year, car after car, options like these Reference Series REF-9632ix 6"x9" car speakers remain a popular choice for replacing factory speakers because of their competitive pricing and superb sound.

Enhanced highs

Step up to a 1" edge-driven dome tweeter for smoother highs with minimal breakup. Plus, push-button tweeter attenuation gives you a "brightness" quick fix.

Plus One+ woofer cone

The Reference Series polypropylene woofer with its durable hi-roll rubber surround ensures you'll enjoy powerful sound every mile you drive. Its oversized cone moves more air than other speakers of similar size, adding plenty of punch to the speaker's impressive performance.

Excellent power-handling

These speakers will really blossom when powered by an external amplifier, but they're also sensitive enough to be a good match for a factory or aftermarket stereo. Plus, Infinity comes up with a safe way to get a little more power out of your system — these 3-ohm speakers combine with the speaker wire in your car so your car stereo sees actual 4-ohm impedance.

READ LESS

Product highlights:

  • 6"x9" 2-way speakers (pair)
  • Plus One+ polypropylene woofer cone with hi-roll rubber surround
  • 1" edge-driven, textile dome tweeter
  • True Four Ohm Impedance technology
    • speaker's 3-ohm impedance combines with speaker wire impedance for a 4-ohm load
    • compatible with virtually all factory or aftermarket car stereos
  • handles up to 100 watts RMS (300 watts peak power)
  • frequency response: 46-20,000 Hz
  • sensitivity: 94 dB
  • top-mount depth: 3-1/16"
  • grilles included
  • warranty: 1 year
  • MFR # REF9632IX

What's in the box:

  • Two 2-way speakers
  • 2 Grilles
  • 2 Grille frames
  • 2 Bottom mount rings
  • Eight 2" Screws
  • 8 Speed clips
  • 2 Adhesive backed foam gaskets
  • Instruction manual
  • Template on box

Featured video:

Customer reviews for Infinity Reference REF-9632ix

Loading reviews...

Average review:

4.5 out of 5 stars
46 reviews

Filter by rating

Customer photos

Customer provided image, click to load a larger version.
Customer provided image, click to load a larger version.

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee review (What's this?)

Reviewed on Samsung.com

This review was collected as part of a promotion

Pros:

Cons:

Crutchfield response
Customer provided image, click to load a larger version.
<< >>

More details on the Infinity Reference REF-9632ix

Pat M.

Features & specs

General
Speaker Size 6X9
Design 2-way
Tweeter Design Edge-Driven Dome
Impedance (Ohms) 3
Tweeter Composition Textile
Woofer Composition Polypropylene
Woofer Surround Rubber
Parts Warranty 1 Year
Labor Warranty 1 Year
Specifications
Sensitivity (1W at 1 meter) N/A
Sensitivity at 2.83 volts 94
Frequency Response 46 - 20k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 100
Peak Power Handling (Watts) 300
Top-mount Depth (Inches) 3 1/16
Bottom-mount Depth (Inches) 3 11/16
Cutout Diameter or Length (inches) 0
Mounting Height (Inches) 0.395
Frame Width 6.414
Frame Length 9.32

Product Research

Features

Plus One+ Woofer Cones: Each speaker uses a cone larger than other speakers of the same size. This is accomplished by using a unique basket design and hi-roll surround. The Plus One+ design offers greater bass output and an increase in efficiency.

Angled Tweeter: The tweeters are mounted at an angle (fixed), so they can be directed toward the listeners to improve imaging.

Tweeter Level Control: A switch on the front of the tweeter allows you to boost the tweeter output to +3dB, useful if the speakers are mounted low in a door where high frequencies are easily absorbed.

High-Output Design: The 3Ω voice coil design compensates for the high in-line resistance of small gauge factory wiring, extracting more power from factory (or aftermarket) receivers.

Loading accessories...

Customer Q&A

1 question already asked

Q
Curious why these won't work in the front doors of a 2018 Ram 1500? Depth issues or? I bought the 5.25 reference front and rear, not too happy with them for a full range speaker. 3.5 reference dash speakers pushing more sound. Rear 5.25s sound non existent.
bryan  Mar 14, 2019
2 answers
A
Lawrence hit the issue right on its head! These speakers need around 1/8" more mounting depth than the front doors have to offer a speaker, but there is roughly 1/4" extra mounting height so if you make a spacer around 1/8" thick, they should fit just fine My Bio: https://www.crutchfield.com/bio/Paul
jason  Mar 18, 2019 (Staff)
A
If it is depth you can probably get around it using an adapter ring. I wouldn't expect decent full range sound from a 5.25 speaker. I would probably go with custom fitting a component system or sub under the rear bench. Also, I believe those reference speakers have a crossover switch mounted by the Tweeter where you can cut some of the higher end. If you have the dash speakers installed I would consider cutting some of the highs from door speakers. I did this in my Nissan which has JBL pillar mounted tweeters.
lawrence  Mar 14, 2019
