About the Kenwood KFC-P510PS
After years of patchy factory sound, I remember installing aftermarket speakers and simply being grateful for audio that was consistent and solid. Kenwood's Performance Series delivers all of that and goes a step beyond, providing articulate lows, clean vocals, and startling highs. With their latest technology incorporated into these speakers, you'll get the biggest sonic bang for your buck.
Quality Kenwood sound
Kenwood's KFC-P510PS 5-1/4" component system provides a rich, dynamic sound reinforced by a solid low end. This polypropylene woofer cone sports a Diamond Array pattern that increases surface strength for reduced distortion and improved bass response. A rubber surround provides reliable playback in spite of the prolonged exposure to the elements that life in your car doors brings.
A 1" soft dome tweeter rounds out this strong system, providing high-frequency details with accuracy. And Kenwood makes things a little easier by incorporating an in-line crossover network into each tweeter — no need to find a spot for a bulky crossover module.
Installation note: You'll need a pair of our universal backstraps to install the tweeters in the factory locations.
- component system includes two 5-1/4" woofers and two tweeters
- Diamond Array Pattern injection polypropylene woofer with rubber surround
- 1" soft dome tweeter
- in-line crossover network
- handles up to 45 watts RMS (240 watts peak power)
- frequency response: 63-24,000 Hz
- sensitivity: 86 dB
- woofer top-mount depth: 2-3/8"
- grilles included
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # KFC-P510PS
What's in the box:
- Two woofers
- 2 Woofer grilles
- 2 Plastic grille rings
- 2 Tweeters (each tweeter has a 5" Length of wire attached)
- 2 Flush-mount tweeter housings (installed on tweeters)
- 2 Flush-mount retaining clips
- 2 OEM tweeter mounting brackets
- Two 30" Tweeter wires with in-line crossovers
- Eight 1" Screws
- Four 5/8" Screws
- 2 Wing nuts
- 8 Large speed clips
- 4 Small speed clips
- Grille putty
- Installation instructions (English/ French/ Spanish)
- Warranty information
- Specifications and Templates on the box
More details on the Kenwood KFC-P510PS
Features & specs
|Speaker Size||5 1/4|
|Tweeter Design||1" Dome|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||86|
|Sensitivity at 2.83 volts||N/A|
|Frequency Response||63 - 24k Hz|
|Minimum RMS Wattage||---|
|Maximum RMS Wattage||45|
|Peak Power Handling (Watts)||240|
|Top-mount Depth (Inches)||2 7/16|
|Bottom-mount Depth (Inches)||2 1/2|
|Cutout Diameter or Length (inches)||4 3/4|
|Mounting Height (Inches)||0.2|
Woofers: The 5-1/4" woofer cones are textured Polypropylene and use rubber surrounds for added durability and bass response. The woofer basket is designed to fit a standard 4-hole 5-1/4" application.
Soft Dome Tweeters: The 1" soft dome tweeters offer smooth highs and low distortion.
Tweeter Mounting Options: The tweeters can be flush mounted using the supplied housings and metal retaining-clips. Once installed the tweeters can pivot in the housing, so their angles can be adjusted to obtain a better soundstage. The tweeters can also be top or bottom mounted in a factory tweeter location using the included brackets. The tweeters cannot pivot when installed in the OEM brackets. Once mounted in the appropriate housing, the tweeters have these dimensions:
|Flush Mount||Factory Top Mount (remove bottom mount flanges)||Factory Bottom Mount (remove top mount flanges)|
|Mounting Depth||1.288"||mounting screw depth||1.005"|
Crossover Network: The low-pass crossovers are wired to the terminals and attached to the woofer baskets; the high-pass crossovers are integrated in the included 30" tweeter wires. The crossover point is 4.6 kHz.
