About the Metra 99-3012G-LC Dash and Wiring Kit
Metra's 99-3012G-LC dash and wiring kit allows you to install a double-DIN (4" tall) radio in your vehicle's dash opening. It also allows installation of a single-DIN (2" tall) radio with the provided pocket. The package includes a wiring harness that maintains your vehicle's Retained Accessory Power and warning chime features. The dash piece is painted silver to match your vehicle's finish.
Please enter your vehicle information or call an Advisor at 1-888-955-6000 to find out if this kit is compatible with your vehicle. Warranty: 60 days.
What's in the box:
- Interface module
- 4-pin to 44-pin Harness
- Radio housing
- 2 Brackets
- Four #8 x 3/8" screws
- 4 Panel-clips
- Installation Instructions
More details on the Metra 99-3012G-LC Dash and Wiring Kit
Vehicle Compatibility: The Metra 99-3012G-LC OEM Integration Kit allows you to replace your Chevy Sonic's factory radio with an aftermarket head unit. This OEM Integration Kit is compatible with 2012-up Chevrolet Sonic vehicles with 29-bit LAN v2 44-pin connector factory radios.
Single-DIN or Double-DIN Dash Kit: The included dash kit is constructed of ABS plastic and designed to match the color, texture, and contours of your dash. The dash kit fits both double-DIN and single-DIN aftermarket head units. A pocket is included, when installing an aftermarket single-DIN head unit.
Radio Replacement Interface Module + Chime: In addition to allowing the installation of an aftermarket stereo in your vehicle, the included interface module retains all your vehicle's factory warning chimes through its integrated speaker and provides a 12V/3A accessory power output.
Note: This OEM Integration Kit does not retain factory OnStar or steering wheel audio controls.
Wiring Harness: The included wiring harness features a 4-pin connector that plugs into the interface module and a 44-pin connector which plugs into your vehicle's factory radio harness. The harness also contains the following bare wires that will need to be hardwired to your aftermarket head unit's wiring harness.
|Yellow||+12 Volt Constant|
|Red||+12 Volt Accessory|
|Blue/white||Remote Amp Turn-On|
|White||Left Front Speaker +|
|White/black||Left Front Speaker -|
|Gray||Right Front Speaker +|
|Gray/black||Right Front Speaker -|
|Green||Left Rear Speaker +|
|Green/black||Left Rear Speaker -|
|Purple||Right Rear Speaker +|
|Purple/black||Right Rear Speaker -|
|Blue/pink||Vehicle Speed Sensor|
|Light Green||Parking Brake|
