Pioneer TS-A652C A-Series 6-1/2" component speaker system

Item # 130TSA652C

If anyone knows how to make music sound phenomenal in your car, it's Pioneer.

Find what Fits your vehicle

Remove

Checking fit...

If anyone knows how to make music sound phenomenal in your car, it's Pioneer.

Item # 130TSA652C

About the Pioneer TS-A652C

Alexander H.

Open, smooth sound

If anyone knows how to make music sound phenomenal in your car, it's Pioneer. With their A-Series speakers, you'll experience their signature, open-and-smooth sound which helps overcome the limitations of off-axis listening in a vehicle while ensuring a seamless transition between woofer and tweeter playback. Best of all, Pioneer gives you this powerful speaker solution with a friendly price tag so you don't go over budget building a whole system. Pair this TS-A652C 6-1/2" component system with an outboard amp and power it with up to 80 watts RMS for seriously clean sound.

Open, smooth sound

If anyone knows how to make music sound phenomenal in your car, it's Pioneer. With their A-Series speakers, you'll experience their signature, open-and-smooth sound which helps overcome the limitations of off-axis listening in a vehicle while ensuring a seamless transition between woofer and tweeter playback. Best of all, Pioneer gives you this powerful speaker solution with a friendly price tag so you don't go over budget building a whole system. Pair this TS-A652C 6-1/2" component system with an outboard amp and power it with up to 80 watts RMS for seriously clean sound.

Optimized materials and design

A woofer cone made of carbon- and mica-reinforced polypropylene means awesome rigidity, low-frequency responsiveness, and weather-resistance. Pioneer also gives you versatile woofer brackets for use across all kinds of makes and models. Use the included tweeter mounts to install the separate 3/4" tweeters in a good spot up high in your vehicle for better stereo imaging. Inline crossovers eliminate the need to find a spot for crossover modules.

READ LESS

Product highlights:

  • component speaker system includes 2 woofers and 2 tweeters
  • 6-1/2" multilayer carbon- and mica-reinforced IMPP woofer cone with elastic polymer surround
  • separate 3/4" polyimide hard dome tweeter with inline crossover
  • woofer adapter and tweeter mounting equipment included
  • grilles not included
  • handles up to 80 watts RMS (350 watts peak power)
  • frequency response: 34-49,000 Hz
  • impedance: 4 ohms
  • sensitivity: 85 dB
  • woofer top-mount depth: 2-3/8"
  • warranty: 1 year
  • MFR # TS-A652C

What's in the box:

  • Two woofers
  • Two tweeters (with attached 10" speaker leads terminated with quick-connects)
  • 2 Multi-application woofer mounting brackets
  • 2 Lengths of speaker wire (each has quick slides to connect to the woofer-a 40" tweeter output leg with integrated crossover-and an 11" input leg)
  • 2 Tweeter angled surface mount housings
  • 2 Tweeter flush mount rings
  • 2 Tweeter factory mount brackets
  • Eight 3/4" Screws
  • Eight 3/8" Screws
  • Six 1/2" Screws
  • 8 Flat washers
  • 2 Speed clips
  • 2 Adhesive backed foam discs
  • Warranty information
  • Template and specs on box

Featured video:

Customer reviews for Pioneer TS-A652C

Loading reviews...

Average review:

4.5 out of 5 stars
58 reviews

Filter by rating

Customer photos

Customer provided image, click to load a larger version.
Customer provided image, click to load a larger version.

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee review (What's this?)

Reviewed on Samsung.com

This review was collected as part of a promotion

Pros:

Cons:

Crutchfield response
Customer provided image, click to load a larger version.
<< >>

More details on the Pioneer TS-A652C

Pat M.

Features & specs

General
Speaker Size 6 1/2
Design 2-way
Tweeter Design 20mm Dome
Impedance (Ohms) 4
Tweeter Composition Polyimide
Woofer Composition Carbon and Mica reinforced IMP
Woofer Surround Rubber
Parts Warranty 1 Year
Labor Warranty 1 Year
Specifications
Sensitivity (1W at 1 meter) 85
Sensitivity at 2.83 volts N/A
Frequency Response 34 - 49k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 80
Peak Power Handling (Watts) 350
Top-mount Depth (Inches) 2 3/8
Bottom-mount Depth (Inches) N/A
Cutout Diameter or Length (inches) 5 7/16
Mounting Height (Inches) 0.229
Frame Width 6.479
Frame Length 6.479
The Pioneer TS-A652C replaces these items:

Product Research

Features

Size Classification Note: Some manufacturers, including Pioneer, call this size woofer a 6-1/2". Because it requires a larger cutout than a standard 6-1/2" speaker, Crutchfield has traditionally referred to this size speaker as a 6-3/4". Please enter your vehicle information to confirm fit.

Mounting Brackets: Pioneer includes a pair of mounting brackets to install the woofers in vehicle-specific applications. Again, enter your vehicle information to confirm fit.

Surrounds: For durability and a smooth response, each woofer uses an elastic polymer (synthetic rubber) surround.

Tweeter Mounting: The system includes flush mount rings and angled surface mount housings for the tweeters. The surface mount housing positions the tweeters at approximately a 45° angle. Bendable brackets are also included for mounting the tweeters in factory locations. Once installed the tweeters do not swivel.

Tweeter Mounting Dimensions:

  Angled Surface Mount Flush Mount
Mounting Height 1.47" 0.233"
Mounting Depth screw depth 0.552"
Frame Diameter N/A 1.955"
Frame Depth 1.785" N/A
Frame Width 1.5" N/A
Cutout Diameter N/A 1.641"

Crossovers: The high pass crossovers are integrated into the included speaker wire and the low pass crossovers are integrated into the woofer baskets. Both are 6 dB/octave and the crossover point is 2.5 kHz. Each length of speaker wire connects to both a woofer and tweeter. Quick slides connect to the woofer, a 40" output leg with integrated crossover (approximately 1/2" diameter x 1-3/4" long) connects to the terminals attached to the tweeter, and an 11" input leg connects to the source.

Loading accessories...

Customer Q&A

9 questions already asked

Q
I bought the TS-A652C speakers and when I installed them into my 2015 Honda Civic lx it wasnâ??t working. Is there a specific way to wire it? It didnâ??t come with directions.
nathan  Jan 10, 2021
2 answers
A
Are you hooking it up to a amplifier? Is so make sure your rca jacks are connected properly and the amp is on. If you are just using the stock speaker wires make sure you use the stock lines connected to the speakers properly including the tweeter wires. They usually complete a circuit. If you try and bypass the stock wires it won't work.
charles  Jan 11, 2021
A
If you are replacing factory speakers wire the Woofer with the factory wires and then parallel the tweeters off of the Woofer.
mike  Jan 10, 2021
Q
Can I run these with a pioneer SPH-DA23ODAB or do they need a separate amp?
michael  Nov 29, 2020
1 answer
A
These speakers have a low sensitivity which means they should be powered by an amp to get good sound
jason  Dec 14, 2020 (Staff)
Q
I do not have tweeters on my passenger doors, do the speakers have to come with the tweeters or can the woofers be sold separately?
jacob  May 09, 2020
1 answer
A
You can check to see if this will fit your vehicle by using our Outfit My Car tool: http://www.crutchfield.com/car/carselector.aspx For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
thomas  May 27, 2020 (Staff)
Q
With the included adapter rings will these fit in an MK5 Jetta with the windows still being able to go down all the way?
ricardo  Sep 23, 2019
1 answer
A
Hi Ricardo! We will need a little more info so we can take a closer look into your vehicle. One of our Advisors will be happy to help you out. Just chat with us online or by phone at 1-800-324-9695.
jessica  Oct 03, 2019 (Staff)
Q
Do you have to use the tweeter's to get any mids or highs out of these speakers?
john  Aug 10, 2019
3 answers
A
I would say yes. Especially the highs. This is a great component speaker system. The highs out of the tweets are extremely crisp!
scot  Aug 25, 2019
A
You can get some range out of the woofer alone but you have to remember the woofers frequency range is in the middle between 100hz to 5000hz. Anyrhing above or below will not be clear or quality sound. The 6db crossover further adds complication to get the right sound from just a woofer alone. If used in a rear door it may be ok for filling the rear space of the vehicle. This can also be problematic as your passengers listening back there will be missing fidelity. Short answer is that you can use them alone. But there is more to the question as to why you would need to.
brandon richard  Aug 19, 2019
A
If you don't want to install the tweeters then get the model with them built on
james  Aug 18, 2019
Q
There is one wide terminal and one thin terminal on the speakers. Which one is positive and which is negative?
donald  Aug 10, 2019
1 answer
A
Look on the speaker where the terminals come off the back. There should be + and - markings on the speaker body, right next to the terminal.
brad  Aug 18, 2019
Q
Does it come with the crossovers?
taylor  Jun 14, 2019
2 answers
A
Yes they are tiny inline ones non adjustable
michael  Jun 14, 2019
A
if it is integrated in the wire
santos  Jun 14, 2019
Q
where would you install the tweeters on a 2006 Tacoma?
edwin  Apr 04, 2019
1 answer
A
The factory location is in the top of the door according to our research file. That would be the best place but those Pioneer tweeters also come with some angled tweeter mounting housings if you prefer to surface mount.
casey  Apr 17, 2019 (Staff)
