JL Audio 10W0v3-4

W0v3 Series 10" 4-ohm subwoofer

Item # 13610W0V34

The JL Audio name means high-quality sound, and the 10W0v3-4 10" subwoofer doesn't come up short when...

The JL Audio name means high-quality sound, and the 10W0v3-4 10" subwoofer doesn't come up short when...

Top seller

Item # 13610W0V34

Out of stock
C$159.95 each

About the JL Audio 10W0v3-4

Precision-built bass

The JL Audio name means high-quality sound, and the 10W0v3-4 10" subwoofer doesn't come up short when delivering trademark JL performance. You'll find patented technologies like an optimized motor system that promotes precise, linear cone movement, plus advanced cooling systems throughout the frame for rapid heat dissipation.

Precision-built bass

The JL Audio name means high-quality sound, and the 10W0v3-4 10" subwoofer doesn't come up short when delivering trademark JL performance. You'll find patented technologies like an optimized motor system that promotes precise, linear cone movement, plus advanced cooling systems throughout the frame for rapid heat dissipation.

Side view of 10W0v3-4 subwoofer

Long-lasting performance

This W0v3 Series sub features a tough polypropylene cone that resists flexing, and a durable foam surround that'll stand up to hard use. The cone's extra-long excursion capability lets it hit truly deep notes without distorting, while the hefty 2-inch voice coil drives the woofer accurately for top-notch performance under extreme conditions.

The patented elevated frame design delivers air flow directly to the voice coil, cooling it for better power handling. JL Audio designed this sub to work in compact sealed or medium-sized ported enclosures, and they offer an optional grille that'll protect your JL Audio sub in its box.

Need an amp for this sub? Check out these Crutchfield-approved single- and dual-sub bass packages.

READ LESS

Product highlights:

  • 10" 4-ohm subwoofer
  • polypropylene cone with foam surround
  • power range: 75-300 watts RMS
  • peak power handling: 600 watts
  • frequency response: 25-250 Hz
  • sensitivity: 84.07 dB
  • top-mount depth: 4-15/16"
  • sealed box volume: 0.65 cubic feet
  • ported box volume: 1.125 cubic feet
  • grille not included
  • warranty: 1 year
  • Our 60-day money-back guarantee
  • MFR # 92165

What's in the box:

  • One 10" Single voice coil 4-ohm subwoofer
  • Owner's Manual

Customer reviews

Loading reviews...

JL Audio 10W0v3-4 reviews

Average review:

178 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the JL Audio 10W0v3-4

Pat M.

Product Research

Features
Enclosure Compatibility

Features

Dynamic Motor Analysis (DMA): DMA is JL Audio's proprietary method aimed at improving dynamic motor behavior. As a result of DMA optimization, 10W0v3-4 motors display linear force over a long excursion range, and also maintain a stable fixed magnetic field in the gap over a wide power range. The result is reduced distortion, faithfully reproduced transients, and tight, clean, articulate bass.

Elevated Frame Cooling: The elevated frame design of the 10W0v3-4 delivers cool air through slots directly above the top plate to the voice coil. This not only enhances power handling, but also sound quality by minimizing dynamic parameter shifts and power compression.

Rear Gasket: The woofer has a rear gasket to provide an optimal seal when installing into the enclosure.

Long Excursion: The 10W0v3-4 subwoofer has 11.4mm of linear excursion, giving you louder bass with less distortion.

Enclosure Compatibility

Recommended Sealed Box Volume: JL Audio recommends a 0.65 ft³ sealed box. A diagram is provided in the owner's manual for a sealed box with external dimensions of 18" W x 11" H x 9" D, assuming 3/4" thick material. (If you are using 5/8" thick materials, you should subtract 1/4" from each dimension.)

Recommended Ported Box Volume: JL Audio recommends a 1.125 ft³ ported box. A diagram is provided in the owner's manual for a ported box with external dimensions of 23" W x 12" H x 13.625" D, assuming 3/4" thick material. (If you are using 5/8" thick materials, you should subtract 1/4" from each dimension.) A slot port measuring 10.5" tall x 1.25" wide x 32" long is recommended, resulting in a tuning frequency of 30 Hz and a -3 dB point of 29.6 Hz.

Loading accessories...

Customer Q&A

21 questions already asked

Q
l was thinking of upgrading my Kickers 2 10tens subs to JL is this going to sound better than kickers?
[ Samuel  Aug 01, 2020 ]
3 answers
A
JL Audio has much better quality than Kickers. Ive had these before and they sound amazing, punchy or clear depending on your use when paired with an amp, correct wiring, and a sealed or ported box.
[ Nicholas  Aug 07, 2020 ]
A
so you saying it'll sound much better?
[ Samuel  Aug 03, 2020 ]
A
Any day of the week.
[ joey  Aug 01, 2020 ]
Q
Can they be wired to 1 0hm?
[ Courtney  Mar 03, 2020 ]
1 answer
A
These are a 4-ohm subwoofer. To get to 1-ohm you would need 4 of them., all wired in parallel.
[ Calvin  Mar 18, 2020 ]  Staff
Q
What do I need to wire the subwoofer?
[ Zack  May 21, 2019 ]
1 answer
A
Of course you need a power source, an amplifier, and 12 or 14 gauge speaker wire.
[ TMoh  May 22, 2019 ]
Q
Does it fit for a 2016 Mitsubishi Outlander Sport Gt?
[ lilrob  Apr 25, 2019 ]
1 answer
A
You can check to see if this will fit your vehicle by using our Outfit My Car tool: http://www.crutchfield.com/car/carselector.aspx For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Krissy  May 06, 2019 ]  Staff
Q
Does this fit an Acura RSX 10" Unloaded Subwoofer Box 2002-2006?
[ Jacob  Dec 11, 2018 ]
1 answer
A
It does fit our Q-Logic 10" unloaded subwoofer box that we carry for those cars. Here is this box: www.crutchfield.com/p_044C1RSA01/item.html My Bio: https://www.crutchfield.com/bio/Paul
[ Paul  Dec 20, 2018 ]  Staff
Q
a 0.95 cubic ft sealed box be too big for this sub-woofer?
[ Juan  May 03, 2018 ]
2 answers
A
That is about time and a half the recommendations from JL. They are spot on with their specs so I tend to stay as close to them as possible. That said, your personal preference on sound may dictate that you are going with just what you need. I would give it a shot and see if you get the bass you're looking for. Hope that helps.
[ Anthony  May 08, 2018 ]
A
It is bigger than the specs suggest , but it will work if you absolutely can't get closer to specs.
[ Jason  May 08, 2018 ]
Q
I have an old school Punch 800a2 amp that puts out 200w rms x 2 at 4 ohms per channel and 800w on a 4 ohm load running in mono. If I run a single one of these subs, can I run it off of only one channel and leave the other channel unused? The amp is probably overkill for this sub, but I don't want to buy a different amp and I don't want to/can't step up to a w3 or a thin line because they are super expensive and probably overkill for what I want.
[ Jon  Nov 30, 2017 ]
1 answer
A
Thanks for your question. I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat to discuss compatibility with your amplifier in more detail. They will be able to help determine if the JL W0v3-4 is the right option; and if not, they can suggest an alternative better suited for your amp.
[ Larry  Dec 04, 2017 ]  Staff
Q
Would this subwoofer be a better choice than running two 10WOV-3-4 subwoofers together in parallel? I'm trying to decide between the two.
[ Orlando  Oct 22, 2017 ]
1 answer
A
I would think it would depend on your amplifier, and subjectively on your needs. Im running a single with a nonported box sized to spec, as well as a RF amp at nearly 600w and I don't feel I would ever need more.
[ kenneth  Oct 23, 2017 ]
Q
is this tight bass?
[ MACDADDY1971  Jun 15, 2017 ]
3 answers
A
Yes it very tight bass
[ Richard  Jun 19, 2017 ]
A
It is. It's tight and punchy though I have it in a smaller box due to my truck size. 2008 chevy Silverado extended cab. Hope that helps.
[ MARK A  Jun 18, 2017 ]
A
Yes. High bass is really tight. Mid to lows sound good on these subs, but they do not project outside the vehicle very much. I was running three of these on direct with a 2000w Kenwood and they would hit really hard and tight inside the truck, but were not very loud outside the truck
[ MIKE  Jun 18, 2017 ]
Q
How is the transient response for this sub? I am looking for a sub that can react well to rock and electronic music with double bass drums. Would you recommend this sub for that application?
[ Will  Jan 16, 2017 ]
2 answers
A
I can tell you that I listen to rock, metal, country and some electronic music and my sub hits perfect. I'm running mine in a sealed enclosure and putting 500w to it. I couldn't be happier.
[ Brian  Jan 16, 2017 ]
A
Yes, I have this sub and it's great! I have it in a sealed enclosure with a sound ordnance M-1500 amp. I mostly listen to rock and alternative, the response and punch is amazing.
[ Desert racer  Jan 16, 2017 ]
Q
Is this sub suitable to use in a free air application?
[ Matthew  Jan 16, 2017 ]
1 answer
A
The JL Audio 10W0v3-4 is not designed for free-air installations. JL recommends either a sealed or ported box, and includes diagrams in the owner's manual with specific dimensions for both. If you would like to discuss further or explore free-air rated subs we car, you can contact an Advisor directly by phone (1-800-324-9695) or online chat.
[ Larry  Jan 25, 2017 ]  Staff
Q
Fit in f150?
[ Yeaplease  Aug 25, 2016 ]
1 answer
A
You can check to see if this will fit your vehicle by using our Outfit My Car tool: http://www.crutchfield.com/car/carselector.aspx For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Krissy  Aug 26, 2016 ]  Staff
Q
What mono amp will work best for one of this subwoofer?
[ bestgio  Jul 01, 2016 ]
1 answer
A
Thanks for your question. For information on selecting the best amp for your subs I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences between the amp models and help you make the best choice for your system.
[ Krissy  Jul 01, 2016 ]  Staff
Q
I'm trying to replace the old blue speaker for rear and want to know if this will fit?
[ Heather  Mar 21, 2016 ]
1 answer
A
You can check to see what fits your vehicle by using our Outfit My Car tool: http://www.crutchfield.com/car/carselector.aspx For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on what fits and what you will need for an installation in your vehicle.
[ Kenny  Mar 21, 2016 ]  Staff
Q
I have a factory sub in my car. Is this a plug and play replacement?
[ Tony  Feb 19, 2016 ]
1 answer
A
You will want to contact an Advisor by phone (1-800-324-9695) or online chat to discuss compatibility with your factory system. They will be able to pull up your vehicle and see if this will integrate. If it does not, then they will also be able to discuss other options with you.
[ Kenny  Feb 19, 2016 ]  Staff
Q
Which sealed box would you recommended for the sub?
[ Andrew  Jan 31, 2016 ]
2 answers
A
JL Recommends .65 cu ft sealed enclosure for this Sub. I have mine in a custom stealth enclosure thats about .6 cu ft. Stuffed it with a little extra baffling and it kicks @ss. JL sells stealth boxes for many different model cars if you're interested
[ Mark  Feb 01, 2016 ]
A
You can use a .75 up to 1.0 cubic ft sealed box.
[ JUAN  Feb 01, 2016 ]
Q
I have a 2015 toyota tacoma with Jbl system. The subwoofer is not really that strong. Would this fit in my truck with out any modifications and would it be a simple swap, remove the jbl sub and just install this sub? Thanks.
[ Miguel  Oct 20, 2015 ]
1 answer
A
For details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Krissy  Oct 20, 2015 ]  Staff
Q
What amp would you recommend to power one of these in a g35 coupe? im on about a 400 dollar budget.
[ Alonso  Sep 25, 2015 ]
1 answer
A
Thanks for your question. For information on selecting the best amp for your subs I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences between the amp models and help you make the best choice for your system.
[ Krissy  Sep 28, 2015 ]  Staff
Q
What is the minimum top mount depth for the box? The sub specs say its' mount depth is 4 15/16 and I have a box that is 5 1/4.... is that enough? Thanks!
[ Hunter  Jul 29, 2014 ]
3 answers
A
I wish I could remember exactly how much room it took. Even though I don't recall the exact number, I do remember initially thinking that there was going to be enough room looking at the specs, but then I still end up having to buy a spacer to make them fit. I know the lack of exact details doesn't help as much, but that's what I recall.
[ JUSTIN  Jul 30, 2014 ]
A
Mine are in a custom JL ported box so I don't know sorry.
[ REGINALD O  Jul 30, 2014 ]
A
As long as you have a half inch between the bottom of the box and magnet you should be fine
[ MARTIN  Jul 29, 2014 ]
Q
What is the recommend size amp to power 2 of these in a sealed enclosure box . Just these two subs seperate from the rest of the car system ??? I will be running a seperate amp for the front and rears .
[ Jason  Apr 28, 2014 ]
7 answers
A
If you are looking for an amp to only push the subs then you want to look for an amp that ranges between 500 and 600 watts.
[ TOMMY G  Apr 29, 2014 ]
A
My one is currently wired into a 420w channel in my amp and that's too much power. I had to adjust the settings and ride around for awhile to get the sound just right. It states that the Recommended Power Range is 100-300w and that's the truth. So for two I say nothing over 800w.
[ ADAM  Apr 29, 2014 ]
A
They have a 250 watt max I would run a 500-1 mono amp and bride the speakers so that both recieve 250 watts a speaker.wich will run these at the optimal power setting with blowing them
[ CHRISTOPHER  Apr 29, 2014 ]
A
something rated at about 500watts rms for 2. why are you using two seperate amps? i would recomend an alpine pdx-v9.
[ JASON S  Apr 29, 2014 ]
A
At minimum I would suggest an amp that pushes 700 watts RMS.. it's always better to go with something a little more powerful than the sub so that you are actually powering the sub.. I had one of these in a sealed box with an 350 watt RMS amp it was an MTX mono block. No complaints.
[ JEREMY  Apr 28, 2014 ]
A
At minimum I would suggest an amp that pushes 200 watts RMS.. it's always better to go with something a little more powerful than the sub so that you are actually powering the sub.. I had one of these in a sealed box with an 150 watt RMS amp it was an MTX mono block. No complaints.
[ JEREMY  Apr 28, 2014 ]
A
I have a 300 watt amp powering one of these and it sounds great. Amp is turned up barely over half way. I would think a 400 to 500 watt amp should work well unless you like a heavy amount of bass. Thanks
[ MATTHEW J  Apr 28, 2014 ]
