About the JL Audio ACP108LG-W3v3
Engineered for performance
Engineered for performance
JL Audio's ACP108LG-W3v3 MicroSub+ powered subwoofer delivers the impressive bass you expect from JL Audio without taking up a lot of space. The compact MicroSub+ enclosure houses a built-in Class D amplifier that safely sends 250 watts RMS to the specially engineered, ultra-low impedance W3v3 8" subwoofer.
The system's controls and connections are readily accessible.
Made in USA
JL Audio uses state-of-the-art automated woodworking equipment to fabricate the high-quality MDF enclosure with rugged automotive carpeting, a steel-mesh grille, 5-way binding posts, and solid internal wiring. The enclosure is and subwoofer are constructed at the manufacturing facility in Florida to ensure that you get the bass that you expect from JL Audio.
Small enclosure, big sound
The specially designed, slot-ported enclosure measures just over 5 inches thick, so it'll fit just about anywhere. Its flared slot-port design cuts down on air turbulence and keeps your bass rich and clear. You'll enjoy thick low-frequency response from all of your music with this capable enclosure in your vehicle. And you can easily remove the power connector from this sub, so you can pull it out of your vehicle when you a little extra space
- 8" W3v3 subwoofer in ported enclosure
- woofer impedance: 0.4 ohms
- built-in Class D amp delivers 250 watts RMS
- 8-gauge amp wiring kit required (sold separately)
- fuse rating: 30 A
- dimensions: 18-1/2"W x 11-1/8"H x 5-1/8"D1
- weight: 19.9 lbs.
- warranty: 2 years
- Our 60-day money-back guarantee
- MFR # 93330
What's in the box:
- MicroSub+ enclosure (loaded with one 8W3v3-0.40 subwoofer and built-in amplifier)
- Black metal grille (installed)
- Power connection plug (installed)
- 30-amp ATO fuse (installed)
- 12" Speaker level amplifier input harness
- Owner's manual
- Specification card
- Warranty information
More details on the JL Audio ACP108LG-W3v3
Features & specs
|Connector Type||RCA/Set screw|
|Woofer Size (inches)||8|
|Woofer Material||Mineral-filled Pol|
|Parts Warranty||2 Years|
|Labor Warranty||2 Years|
|Amplifier Power (RMS)||250 watts|
|Second Voice Coil Impedance||N/A|
Overview: The ACP108LG-W3v3 MicroSub+ is a compact powered subwoofer, useful in vehicles with limited space. The ported enclosure is loaded with one 8W3v3-0.40 8" low impedance subwoofer (0.4Ω) and a 250 watt RMS class-D amplifier. The amp uses JL Audio's exclusive DCD amplifier technology, combining direct power conversion (no conventional switching power supply) with an ultra-high current output section. The result is an efficient design (91-94%) with very little heat generated.
Enclosure Design: The enclosure features MDF (medium-density fiberboard), constructed using CNC woodworking equipment, and covered with high-grade automotive carpeting. The driver is protected by a black steel-mesh grille. The port and amplifier panel are both on the same side of the enclosure.
Flared Port: The enclosure has a side-firing flared slot-port. The flared slot-port design minimizes turbulence and improves fidelity. The port is approximately 1-3/8" x 4" at the opening.
Power/Ground Plug: The power, ground, and remote turn-on wires attach to a removable terminal block; easily unplugged so the subwoofer can be removed when you need more storage space. Each terminal is a screw clamp that will accept up to 8 gauge wire (minimum 8 gauge power and ground recommend).
Audio Inputs: The amplifier section will accept either a line level (RCA) or speaker level signal. A 12" speaker level input harness is included.
Remote Level Control: An optional RBC-1 wired Remote Bass Control (item number 136RBC1, sold separately) allows bass level adjustment from the front of your vehicle.
- Input Sensitivity: rotary control; variable from 70 mV to 1.4 V for the RCA inputs and 280 mV to 5.4 V for the speaker level inputs
- Turn-On Mode: three position switch:
- REM: amp turns on when +12 volts DC is applied to the remote terminal
- DC: the amp turns on when a DC offset voltage is detected on the speaker level inputs
- Signal: the amp turns on when an audio signal is detected on the speaker level inputs, turns off after 30 seconds without an input signal
- Crossover: rotary control; the crossover point is continuously variable from 50 Hz to 200 Hz; the slope is 12 dB/octave and the low-pass crossover is always engaged
- Polarity: two position switch; allows you to reverse the phase of the subwoofer (0°, 180°)
Protection Circuit: The amp is equipped with thermal protection circuit; it will shut down if it overheats.
- Width: 18-1/2" (18-3/4" including wiring)
- Height: 11-1/8"
- Depth: 5-1/8" (6-5/8" including grille)
