JL Audio ACS110LG-TW1

PowerWedge+™ 10" powered subwoofer

Item # 13693334

JL Audio's ACS110LG-TW1 PowerWedge+ powered subwoofer delivers the impressive bass you expect from JL Audio...

JL Audio's ACS110LG-TW1 PowerWedge+ powered subwoofer delivers the impressive bass you expect from JL Audio...

Item # 13693334

Ships from distributor

In stock
C$759.99

About the JL Audio ACS110LG-TW1

JL Audio Built In USAEngineered for performance

JL Audio's ACS110LG-TW1 PowerWedge+ powered subwoofer delivers the impressive bass you expect from JL Audio without taking up a lot of space. The compact PowerWedge+ enclosure houses a built-in Class D amplifier that safely sends 400 watts RMS to the specially engineered, ultra-low-impedance TW1 10" subwoofer.

JL Audio Built In USA Engineered for performance

JL Audio's ACS110LG-TW1 PowerWedge+ powered subwoofer delivers the impressive bass you expect from JL Audio without taking up a lot of space. The compact PowerWedge+ enclosure houses a built-in Class D amplifier that safely sends 400 watts RMS to the specially engineered, ultra-low-impedance TW1 10" subwoofer.

Made in USA

JL Audio uses state-of-the-art automated woodworking equipment to fabricate the high-quality MDF enclosure with rugged automotive carpeting, a steel-mesh grille, 5-way binding posts, and solid internal wiring. The enclosure and subwoofer are constructed at the manufacturing facility in Florida to ensure that you get the bass that you expect from JL Audio.

Small enclosure, big sound

The specially designed, sealed enclosure measures just over 5 inches thick, so it'll fit just about anywhere. You'll enjoy thick low-frequency response from all of your music with this capable enclosure in your vehicle. And you can easily remove the power connector from this sub, so you can pull it out of your vehicle when you need a little extra space.

READ LESS

Product highlights:

  • 10" TW1 subwoofer in sealed enclosure
  • built-in Class D amp delivers 400 watts RMS at 0.25 ohms
  • woofer impedance: 0.25 ohms
  • low-pass filter (50-200 Hz, 12 dB slope)
  • recommended power/ground wire gauge: 8 AWG
  • fuse rating: 30 A
  • dimensions: 18.5"W x 11.125"H x 5"D
  • weight: 20.1 lb.
  • warranty: 2 years
  • Our 60-day money-back guarantee
  • MFR # 93334

What's in the box:

  • PowerWedge+ enclosure (loaded with one 10TW1-0.25 subwoofer and built-in amplifier)
  • Black metal grille (installed)
  • Power connection plug (installed)
  • 30-amp ATO fuse (installed)
  • 12" Speaker level r input harness
  • Owner's manual
  • Specification card
  • Warranty information

Customer reviews

Loading reviews...

JL Audio ACS110LG-TW1 reviews

Average review:

55 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the JL Audio ACS110LG-TW1

Pat M.

Features & specs

General
Enclosure Type Sealed
Finish Material Carpet
Grille Steel
Connector Type RCA/Set screw
Bi-amp Inputs No
Woofer Size (inches) 10
Woofer Material Mica-filled Poly
Passive Radiator ---
Width 18-1/2"
Height 11-1/8"
Depth 5-7/8"
Second Depth N/A
Parts Warranty 2 Years
Labor Warranty 2 Years
Specifications
Frequency Response N/A
Amplifier Power (RMS) 400 watts
Maximum Wattage N/A
Sensitivity N/A
Impedance 0.25 ohms
Second Voice Coil Impedance N/A
Crossover Point 50-200

Product Research

Features

Overview: The ACS110LG-TW1 PowerWedge+ is a compact powered subwoofer, useful in vehicles with limited space. The sealed enclosure is loaded with one 10TW1-0.25 10" low impedance subwoofer (0.25Ω) and a 400 watt RMS class-D amplifier. The amp uses JL Audio's exclusive DCD amplifier technology, combining direct power conversion (no conventional switching power supply) with an ultra-high current output section. The result is an efficient design (91-94%) with very little heat generated.

Enclosure Design: The enclosure features MDF (medium-density fiberboard), constructed using CNC woodworking equipment, and covered with high-grade automotive carpeting. The driver is protected by a black steel-mesh grille.

Power/Ground Plug: The power, ground, and remote turn-on wires attach to a removable terminal block; easily unplugged so the subwoofer can be removed when you need more storage space. Each terminal is a screw clamp that will accept up to 8 gauge wire (minimum 8 gauge power and ground recommend).

Audio Inputs: The amplifier section will accept either a line level (RCA) or speaker level signal. A 12" speaker level input harness is included.

Remote Level Control: An optional RBC-1 wired Remote Bass Control (item number 136RBC1, sold separately) allows bass level adjustment from the front of your vehicle.

Controls:

  • Input Sensitivity: rotary control; variable from 70 mV to 1.4 V for the RCA inputs and 280 mV to 5.4 V for the speaker level inputs
  • Turn-On Mode: three position switch:
    • REM: amp turns on when +12 volts DC is applied to the remote terminal
    • DC: the amp turns on when a DC offset voltage is detected on the speaker level inputs
    • Signal: the amp turns on when an audio signal is detected on the speaker level inputs, turns off after 30 seconds without an input signal
  • Crossover: rotary control; the crossover point is continuously variable from 50 Hz to 200 Hz; the slope is 12 dB/octave and the low-pass crossover is always engaged
  • Polarity: two position switch; allows you to reverse the phase of the subwoofer (0°, 180°)

Protection Circuit: The amp is equipped with thermal protection circuit; it will shut down if it overheats.

Dimensions:

  • Width: 18-1/2" (18-3/4" including wiring)
  • Height: 11-1/8"
  • Depth: 5-1/8" (5-7/8" including grille)

Loading accessories...

Customer Q&A

Q
Crutchfield asked: Why did you buy this?
A
Recommend by Gus [ J  Jun 02, 2019 ]
A
For upgraded bass in my 2018 ram 2500 mega cab truck. [ Daniel  Feb 06, 2019 ]
A
Recommended [ Jason  Dec 11, 2018 ]
A
Highly recommend to thump in a smaller space [ Bryan  Dec 06, 2018 ]
A
JL Quality [ ANTHONY F  Oct 04, 2018 ]
A
Made in USA [ bob  Sep 26, 2018 ]
A
The size should not take too much space up in my trunk and like the idea the integrated amp. [ Samuel  Aug 13, 2018 ]
A
It was recommended by one of your sales experts and it was the only one that would possibly fit my Toyota Tundra Crewmax. [ ADAM DE  Jun 19, 2018 ]
A
Based on the recommendation of Peyton, sales advisor, via email conversation. [ Henry  Apr 02, 2018 ]
A
Awesome advice from a crutchfield rep!!! [ michael  Mar 18, 2018 ]
A
Already like the 8 [ clinton  Dec 06, 2017 ]
A
Got it for it's compact design. [ Herbert  Jul 22, 2017 ]
A
I like the style and sound and all good reviews alsoNeal recommended because of soud quality thank you neal [ FABIAN  May 25, 2017 ]
A
JL Audio sound quality, compactness of unit and price--it was on sale almost $70 down from the last time I had considered it, so that sealed the deal! [ Alejandro  Jul 11, 2016 ]
A
Read reviews of this fitting under rear seat in crew cab truck, so decided to try myself. Also has a built in amp to help save space. [ Scott  Apr 25, 2016 ]
A
Good reviews on site and high power for the compact size I need. Respect JL Audio quality and made in USA workmanship [ Paul  Mar 20, 2016 ]
SHOW MORESHOW LESS

9 questions already asked

Q
Does this have good bass?
[ Big Rick  Jun 12, 2019 ]
5 answers
A
Yes definitely! It fills our Equinox nicely.
[ JASON A  Jun 13, 2019 ]
A
It is okay. I am deciding if it was work the money. I am not technical, so I will tell you what I was told. Do not install where it receives a signal. You have to wire to remote. You may know what that means. Mine would no longer receive a signal, so we had to go back later and install this way. I guess it is according to what your looking for. If you want big bass I would buy a sub amp and sub separately. JL Audio is good stuff. I am not sure it is worth the money.
[ Chris  Jun 12, 2019 ]
A
Yes. It's more of a tighter bass. I listen to rock and heavy metal and I actually has it turned down to reduce some of the bass. I give it a 10/10.
[ Kelley  Jun 12, 2019 ]
A
Runs me out of my Tacoma. I like it a lot.
[ David  Jun 12, 2019 ]
A
Go with a soar audio shallow 10 at 850 watts rms and 79.00 you can't beat it
[ A  Jun 12, 2019 ]
Q
What modifications must be made to install this behind rear seat of a 2006 f250 crew cab?
[ Jason  May 05, 2017 ]
1 answer
A
For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Kenny  May 06, 2017 ]  Staff
Q
Is there a big difference between the 8 inch and 10 inch? I just purchased the 8 inch one and it sounds great but it really doesn't have much of a low end bass. plus I noticed there's not a huge difference in price.
[ Paul  May 15, 2016 ]
1 answer
A
Thanks for your question. For information on comparing two or more models I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences and help you make the best choice for your system and your budget.
[ Krissy  May 16, 2016 ]  Staff
Q
Will this fit behind or under the seat of a 2016 Toyota Tacoma?
[ Superman  Mar 04, 2016 ]
3 answers
A
I don't know...I don't have a Tacoma. I will say that I love the speaker but I highly recommend buying the separate bass remote control, which really should come with the speaker.
[ Elliott  Mar 05, 2016 ]
A
It fits under the seat in my f-150, I really couldn't tell you anything about a toyota.
[ Kevin  Mar 04, 2016 ]
A
My suggestion is to make a mock-up of the speaker box from cardboard. Get the dimensions from Crutchfield and make a replica. I used this for my Mazda CX5 and it was incredibly helpful for testing the fit for installation. The real speaker box fit perfectly when I purchased it.
[ bryan  Mar 04, 2016 ]
Q
Has anyone installed the PowerWedge+ 10" or 12" Behind the back seat (Not Under the seat) in a 2016 or 2015 Ford F-150 XLT SuperCrew? For those who don't know, Both Rear Seats fold down to provide some Hidden Storage Space. I see 1 Review of an ACS110LG-TW1 10" PowerWedge in a 2016 F-150 from (Mark S. from Wayzata) He said the 10" fit under the seat without taking up any space. I'm hoping he meant behind the seat. Because if it's under the seat, it is taking up storage space. And I need all the space that I can get. I folded my seats down on my 2016 F-150 and it looks like it just might work. But it's hard to tell with the way the back panel bumps in and out. Really Hoping I could fit the 12" Wedge back there Thanks for any input. KZ
[ Ken  Feb 15, 2016 ]
2 answers
A
I tried to fit it behind the seat of my 2017 F-150 (same body as the 15 and 16's) and it won't quite fit. If you removed some of the rear cab insulation and carpeting, you might get it to fit. If you don't you will smash the metal speaker grille. I have it under the small rear seat (passenger side) and it fits perfectly there laying flat.
[ Derek  Nov 01, 2018 ]
A
While we do not have the available space researched in that location, we can provide the dimensions of the JL Audio enclosure which you can use to cross-reference against the space you find available there: 21"W x 13.5"H x 6.625"D I hope that helps! My Bio: http://www.crutchfield.com/Support/Bio.aspx?bio=5
[ Ryan  Feb 17, 2016 ]  Staff
Q
My powered sub did not come with installation instructions. Will you please send the installation instructions to me asap? I want to make sure I am pulling the dash properly, and don't want to break anything!
[ Ryan  Nov 12, 2015 ]
1 answer
A
If you purchased the product from Crutchfield, feel free to contact our Tech Support team. They can walk you through the settings on the product and see if there may be a fix. Our toll-free Tech Support number is printed on your invoice, and is also available under the "My Orders" tab in the "My Account" section of our website. If you did not purchase the unit from Crutchfield, then you may want to contact the manufacturer. You can also post your question in our forums: http://community.crutchfield.com. Or try our online support center: http://crutchfield.custhelp.com/app/answers/list/kw/.
[ Krissy  Nov 13, 2015 ]  Staff
Q
Is this box size really smaller than the JL Audio 8" version? How? This box with grill on is thinner than the JL Audio 6.5"? I'm looking for a sub box to fit under the passenger seat on a Dodge Ram Club Cab. Wanting to clear up my back seat where my huge JL 12" box is.
[ Max  Nov 12, 2015 ]
2 answers
A
I have the 10" version and it fits perfectly behind the single fold down seat in my 2005 Silverado crew cab.
[ Ryan  Nov 12, 2015 ]
A
The dimensions listed are exactly what I received. It is a thin sub with very low impedance and an amp that works with that low impedance. In my truck this delivers good performance, particularly considering the small amount of space it takes up. It won't outperform a properly powered JL12W3, for example, but it is no slouch.
[ Dennis  Nov 12, 2015 ]
Q
Which sub speaker is used? W3 or?
[ Joe  Oct 12, 2015 ]
1 answer
A
It seems like a variant of the TW1.
[ Dennis  Oct 13, 2015 ]
Q
Does this come with the bass knob and wire?
[ Ozzie  Jul 09, 2015 ]
1 answer
A
I forwarded your question to an Advisor and they responded with the following: It does not, you would need to purchase the JL RBC 1, and an amp wiring kit. If you would like to discuss further you can contact an Advisor directly by phone (1-800-324-9695) or online chat.
[ Krissy  Jul 13, 2015 ]  Staff
