JL Audio Stealthbox®

Custom-fit fiberglass enclosure with 10" 10TW3-D4 subwoofer — fits 2016-up Toyota Tacoma Double Cab trucks

Item # 13694654

The JL Audio Stealthbox® custom-fit subwoofer delivers incredible bass in a package that takes up minimal space...

Find what Fits your car

The JL Audio Stealthbox® custom-fit subwoofer delivers incredible bass in a package that takes up minimal space...

Item # 13694654

Ships from distributor

C$1,099.99

About the JL Audio Stealthbox®

The JL Audio Stealthbox® custom-fit subwoofer delivers incredible bass in a package that takes up minimal space and blends in with your vehicle's interior. JL Audio designs Stealthboxes to fit in specific vehicles, then loads them with appropriate subwoofers for optimal performance. Pair the system with an appropriate amp and wiring for stellar, concealed bass.
JL Audio Built In USA

The JL Audio Stealthbox® custom-fit subwoofer delivers incredible bass in a package that takes up minimal space and blends in with your vehicle's interior. JL Audio designs Stealthboxes to fit in specific vehicles, then loads them with appropriate subwoofers for optimal performance. Pair the system with an appropriate amp and wiring for stellar, concealed bass.

Perfect sound to go with the perfect fit

JL Audio puts months of research and design into each Stealthbox® custom-fit subwoofer to ensure not only that it fits, but that it sounds better than any other custom enclosed system. First, JL Audio determines the ideal shape and mounting location for each enclosure, so that it looks like an original part of the vehicle it's designed for. Next, they mount each high-performance subwoofer so it delivers amazing firepower from within its unique enclosure, without sacrificing clarity or musical depth.

The fiberglass enclosure offers superior rigidity while allowing more interior volume, so the sub can turn out louder, deeper bass. JL Audio craftsmen then laminate, grind, join, and finish each Stealthbox® by hand. The end result: full-bodied, distortion-free bass from an impressively stealthy enclosure.

Enjoy enhanced, custom-fit sound

This Stealthbox® enclosure fits behind the rear seat in select 2016-up Toyota Tacoma Double Cab trucks. This Stealthbox® includes one 10TW3-D4 10" DVC subwoofer from JL Audio, wired for 2-ohm impedance. Please check with us before purchasing by using the vehicle selector on our site, or calling a Sales Advisor at 1-888-955-6000 to verify fit information.

JL Audio has rated the difficulty of this Stealthbox® installation as easy.

READ LESS

Product highlights:

  • Stealthbox® custom-fit subwoofer
  • sealed fiberglass enclosure
  • 10TW3-D4 10" dual 4-ohm voice coil subwoofer
  • 2-ohm total impedance
  • installs behind the rear seat
  • power handling: 400 watts RMS (800 watts peak power)
  • warranty: 2 years
  • Our 60-day money-back guarantee
  • MFR # 94654

What's in the box:

  • Custom subwoofer enclosure loaded with a single 10" 10TW3-D4 subwoofer

Customer reviews

Loading reviews...

JL Audio Stealthbox® reviews

Average review:

15 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the JL Audio Stealthbox®

Pat M.

Product Research

Features

Overview: JL Audio's SB-T-TACDCG3/10TW3 Stealthbox has been specifically designed to fit select 2016 - up Toyota Tacoma Double Cab trucks. It features a single 10" 10TW3-D4 subwoofer in a custom sealed enclosure that mounts in the storage pocket behind the passenger side rear seat.

Note: Use our online vehicle selector to see what products work with your vehicle.

Subwoofers: The JL Audio Stealthbox's single 10" 10TW3-D4 subwoofer offers a powerful combination of a shallow mounting depth and high excursion capability, producing deep powerful bass from a small enclosure. The dual 4 ohm voice-coil subwoofer is wired for a 2 ohm output to a single set of terminals, and is capable of handling up to 400 watts RMS. A black steel mesh grille is included for protecting the subwoofer.

Enclosure: The Stealthbox enclosure is made from fiberglass coated in black carpet and is designed to mount inside the storage pocket behind the passenger's side rear seat.

Note: Installation requires relocation of the factory amplifier and removal of the factory subwoofer, if equipped. For models equipped with a factory subwoofer, a "plain" (non-subwoofer) passenger side rear cargo trim panel (Toyota part# 64429-04040-C0) must be purchased from Toyota parts.

Loading accessories...

Customer Q&A

9 questions already asked

Q
So where do you mount the amp?
[ CxRxM  Aug 21, 2019 ]
5 answers
A
Mines under the driver seat. 16 Tacoma OR. The speaker hits hard and fits perfect behind rear passenger seat
[ DAVID  Sep 11, 2019 ]
A
Behind the right rear passenger seat.
[ MARCELINO  Sep 11, 2019 ]
A
I put it under passenger seat
[ Raul  Sep 11, 2019 ]
A
On the back of the other seat
[ Matthew  Sep 11, 2019 ]
A
I have my amps mounted under the driver and passenger seats.
[ DANIEL A  Sep 11, 2019 ]
Q
So do I need to also buy an amplifier to run this?
[ Sam  Apr 12, 2019 ]
6 answers
A
It is recommended and will sound great with the amp.
[ DANIEL A  Apr 12, 2019 ]
A
I did. I JL Audio amp nothing to big just like 300-700 watt amp will do.
[ Christopher  Apr 12, 2019 ]
A
Yes you need to purchase an amplifier also. If you are installing the sub to run off of the factory stereo you will also need a Speaker to RCA line output converter. I used the Scosche LOC90.
[ Jason  Apr 12, 2019 ]
A
Yes
[ MARCELINO  Apr 12, 2019 ]
A
Yep ! It's not a powered enclosure
[ Michael  Apr 12, 2019 ]
A
It would depend on the headunit but most need one. I put the XD300/1v2 on in my Tacoma and it hits pretty hard for as small as the box is.
[ COLE  Apr 12, 2019 ]
Q
Would it fit on a 2019 tacoma doble cab?
[ Homero  Dec 01, 2018 ]
4 answers
A
It should, I have it in a 2017 and I don't believe any changes have been made behind the rear seat. That being said, maybe someone with a 2019 could better answer this question
[ Darren  Dec 02, 2018 ]
A
It fit in my 17. Had to do a little cutting but it's in there.
[ Christopher  Dec 01, 2018 ]
A
Yes, it will fit 2016 to 2019 tacoma double cab
[ Rolando  Dec 01, 2018 ]
A
Yes, it should fit perfectly in your 2019 Double cab. Pretty much all the 3rd Generation Tacoma and you only need one...it sounds great.
[ Dat  Dec 01, 2018 ]
Q
Does this work with the existing jbl amp if you have the jbl premium audio already?
[ Preston  Nov 26, 2018 ]
1 answer
A
No, that JL Audio Stealthbox would require its own amp - ideally something with at least 400 watts. If you want to look at options for adding a subwoofer to the factory system our Product Advisors can help you put together a personalized cart. You can reach them via phone or chat here https://bit.ly/2QNxGQB --Cosmo
[ Cosmo  Dec 05, 2018 ]  Staff
Q
What amp do you recommended?
[ Elicier  Jun 05, 2018 ]
1 answer
A
Thanks for your question. For information on selecting the best amp I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences between the amp models and help you make the best choice for your system.
[ Krissy  Jun 15, 2018 ]  Staff
Q
I'm wanting to buy a 5 channel amp to run this sub, what amp is recommended for this sub ?
[ Ira  Jun 04, 2018 ]
1 answer
A
Thanks for your question. For information on selecting the best amp for your subs I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences between the amp models and help you make the best choice for your system.
[ Krissy  Jun 11, 2018 ]  Staff
Q
Can the back of the seat be put back in the upright position again after the box is installed?
[ Leo  Jun 01, 2018 ]
3 answers
A
Yes, it can! It fits nicely in the little pocket behind the seat and it sounds great. Worth every penny!!
[ DANIEL A  Jun 01, 2018 ]
A
Yes
[ Richard  Jun 01, 2018 ]
A
Most certainly, that's why I went with this myself
[ Michael  Jun 01, 2018 ]
Q
Does it come with an amp?
[ Jeff Cavanaugh  Mar 13, 2018 ]
4 answers
A
No, recommended amp is the XD300/1v2. I went with it and it sounds pretty good when all tuned for the vehicle. I had mine all turned up too high and had to take to a pro. Once he fixed that, it sounded great.
[ COLE  Apr 12, 2019 ]
A
*No
[ Adam  Mar 27, 2018 ]
A
Ni
[ Adam  Mar 27, 2018 ]
A
Nope, amp is sold separately.
[ Nicholas  Mar 27, 2018 ]
