Sony XS-GS1631C

GS-Series 6-1/2" 3-way component speaker system

Item # 158GS1631C

Enjoy a new level of performance with Sony's XS-GS1631C 6-1/2" 3-way component speaker system.

Find what Fits your car

Enjoy a new level of performance with Sony's XS-GS1631C 6-1/2" 3-way component speaker system.

Item # 158GS1631C

Ships free

In stock
C$529.99

About the Sony XS-GS1631C

Enjoy 3-way sound

Enjoy a new level of performance with Sony's XS-GS1631C 6-1/2" 3-way component speaker system. The package includes two 6-1/2" woofers, two 3-1/2" midrange drivers, two 1" dome tweeters, and a pair of outboard crossovers. Each woofer and midrange driver features a rigid, reinforced special aramid fiber cone that delivers focused midrange definition and strong midbass punch, even during high-volume playback.

Enjoy 3-way sound

Enjoy a new level of performance with Sony's XS-GS1631C 6-1/2" 3-way component speaker system. The package includes two 6-1/2" woofers, two 3-1/2" midrange drivers, two 1" dome tweeters, and a pair of outboard crossovers. Each woofer and midrange driver features a rigid, reinforced special aramid fiber cone that delivers focused midrange definition and strong midbass punch, even during high-volume playback.

Distinct, clean highs

The separate 1" soft dome tweeter will reveal the natural detail that your factory speakers couldn't even hope to reproduce. Included external 3-way crossovers allow you to get cleaner highs and fuller lows by sending the appropriate frequencies to the woofer, midrange driver, and tweeter. Sony also provides mounting options, so you can install your tweeters closer to your ears to achieve the best possible sound staging for your car.

Classic Sony design

If you're planning on a custom installation, Sony includes refined, black grilles for seamless integration into most car interiors. Sony has also reduced the overall mounting depth, making this system a great fit for more vehicles. These component speakers are protected by the GS Series 3-year warranty, and they'll handle up to 120 watts RMS – so go ahead and rock out.

Installation note: You'll need a pair of our universal backstraps to install the tweeters in the factory locations.

READ LESS

Product highlights:

  • component speaker system includes two woofers, two midrange drivers, two tweeters, two external crossovers, and two woofer grilles
  • 6-1/2" mica reinforced cellular (MRC) aramid fiber matrix woofer with rubber surround
  • 3-1/2" mica reinforced cellular (MRC) aramid fiber matrix midrange driver
  • 1" soft dome tweeter
  • 3-way external crossovers
  • 4-ohm impedance
  • handles up to 120 watts RMS (320 watts peak power)
  • frequency response: 30-30,000 Hz
  • sensitivity: 87 dB
  • woofer top-mount depth: 2-1/4"
  • grilles included
  • warranty: 3 years
  • Our 60-day money-back guarantee
  • MFR # XSGS1631C

What's in the box:

  • 2 Woofers
  • 2 Woofer grilles
  • 2 Woofer grille frames
  • 2 Midrange drivers
  • 2 Crossovers
  • 2 Tweeters (each has attached 12" speaker lead)
  • 2 Surface mount tweeter housings
  • 2 Angled surface mount tweeter housings
  • 2 Adhesive backed surface mount pads
  • Sixteen 1-1/8" Screws
  • Two M4x6mm Flat head machine screws
  • Installation instructions (English/ French/ Spanish/ German/ Italian/ 15 other languages)
  • Warranty information

Customer reviews

Loading reviews...

Sony XS-GS1631C reviews

Average review:

4 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the Sony XS-GS1631C

Pat M.

Features & specs

General
Speaker Size 6 1/2
Design 3-way
Tweeter Design 1" Dome
Impedance (Ohms) 4
Tweeter Composition Synthetic Fiber
Woofer Composition MRC Aramid Fiber Matrix
Woofer Surround Rubber
Parts Warranty 3 Years
Labor Warranty 3 Years
Specifications
Sensitivity (1W at 1 meter) 87
Sensitivity at 2.83 volts N/A
Frequency Response 30 - 30k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 120
Peak Power Handling (Watts) 320
Top-mount Depth (Inches) 2 1/4
Bottom-mount Depth (Inches) N/A
Cutout Diameter or Length (inches) 5

Product Research

Features

Woofer Cones: The XS-GS1631C woofers use an MRC cone (Mica Reinforced Cellular glass fiber composite) with Aramid Fiber Matrix to reduce weight and increase rigidity, delivering full bass response.

Rubber Surrounds: For improved durability each woofer uses a rubber surround.

Tweeters: The tweeters are 1" soft synthetic fabric domes. They can be flush mounted, surface mounted, or surface mounted at an angle using the included housings.

Tweeter Mounting Dimensions:

  Frame Width Frame Length Cutout Diameter Mounting Height Mounting Depth
Flush Mount 2.079" 2.079" 1.57" 0.545" 0.518"
Flat Surface Mount 2.21" 2.21" N/A 1.2" Screw Depth
Angled Surface Mount 2.225" 2.44" N/A 1.3" Screw Depth

Crossovers: Each crossover has high-pass (tweeter), band-pass (midrange), and low-pass (woofer) outputs. The crossover points are 500 Hz and 5 kHz. A switch inside each crossover allows you to set the tweeter output level according to your system requirements and personal preference; choose +4 dB (factory setting), 0 dB, or -2 dB. The inputs and outputs are screw terminals; they will accommodate bare wire or spade connectors up to 0.3" wide. There are two mounting holes in the base of each crossover.

Bi-amp Inputs: The 3-way crossovers have separate inputs for the woofer and midrange/tweeter; this lets you drive the system with dedicated power for the woofers, instead of sharing power. If the system is powered using only two amplifier channels, the woofer and midrange/tweeter inputs should be shorted together.

Crossover Dimensions:

  • Width: 6.27"
  • Height: 1.4"
  • Depth: 4"

Mounting: The woofers can be easily mounted in a variety of 6-3/4" applications. Given the required cutout, they will also fit into the opening for a typical 6-1/2" speaker (approximately 5" diameter) but the screw hole pattern is larger than a standard 6-1/2", so new holes would have to be drilled.

Specification Note: Sony's rated power spec for the XS-GS1631C is 65 watts (derived using IEC 60268-5 standards). In the manual they also list the CEA 2031 compliant RMS power as 120 watts. We've adopted the 120 watt RMS rating because CEA 2031 is the more common rating system.

Loading accessories...

Customer Q&A

1 question already asked

Q
Will the midrange fit in a 2004 toyota camry dash location?
[ Chase  Mar 26, 2018 ]
1 answer
A
You can check to see if this will fit your vehicle by using our Outfit My Car tool: http://www.crutchfield.com/car/carselector.aspx For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Krissy  Apr 04, 2018 ]  Staff
