Sony MEX-GS820BT

CD receiver

Item # 158GS820BT

Aftermarket car stereos typically provide a lot more power to your speakers than factory radios — I've...

Find what Fits your car

Aftermarket car stereos typically provide a lot more power to your speakers than factory radios — I've...

Item # 158GS820BT

Ships free

About the Sony MEX-GS820BT

Power to rock your ride

Aftermarket car stereos typically provide a lot more power to your speakers than factory radios — I've heard the difference. But Sony's MEX-GS820BT takes that to the extreme with its powerful Class-D amplifier. Boasting 45 watts of continuous output per channel, it'll take your system to a level once reserved for external power amps. You can tweak that output with an impressive array of sound-shaping tools, including a 10-band EQ, time alignment, and comprehensive frequency filters.

Power to rock your ride

Aftermarket car stereos typically provide a lot more power to your speakers than factory radios — I've heard the difference. But Sony's MEX-GS820BT takes that to the extreme with its powerful Class-D amplifier. Boasting 45 watts of continuous output per channel, it'll take your system to a level once reserved for external power amps. You can tweak that output with an impressive array of sound-shaping tools, including a 10-band EQ, time alignment, and comprehensive frequency filters.

Powerful smartphone integration

This Sony works hand in glove with your smartphone. You'll enjoy voice control though your Android™, or you can communicate with Siri when you use your iPhone®. Plug in your phone to either the front or rear USB inputs to access your stored music files. Enjoy your carefully curated streaming content by accessing Pandora® from the receiver's controls.

Sony MEX-GS820BT

Use Bluetooth to pair two phones at once.

Bluetooth® for hands-free calls and more

Bluetooth offers convenience when you're behind the wheel, with hands-free calling and wireless audio streaming from your mobile device. The MEX-GS820BT connects to two devices at the same time — great if you have work and personal mobile accounts. Pairing is easy with Sony's Simple Secure Pairing system, and even easier if your phone supports Near Field Communications (NFC) technology — just touch your device to the receiver and you're set.

A wealth of playback options

This Sony delivers great sound from your CDs, and plays a variety of file formats via the front and rear USB inputs. Sony's Quick-BrowZer search tool makes finding the right playlist, album, artist, or song an easy task.

And you can reach for the stars by adding a SiriusXM satellite radio tuner (not included, requires subscription). Satellite radio offers an unparalleled variety of music, news, sports, and talk, plus your favorite channels will stay with you wherever you drive.

Want to keep your steering wheel controls?

This Sony has the ability to retain the steering wheel controls in many Japanese vehicles, but we recommend using a separate SWC adapter. In all other vehicles, you'll need an adapter to retain those controls with this car stereo. Connect a few wires, then program the adapter for your particular car and radio, and you'll retain the convenience of your steering wheel controls. You'll see the adapters that work with your vehicle when you add this receiver to your cart.

Bluetooth note: Use of this receiver's Bluetooth features will depend upon your phone's Bluetooth capabilities. Learn more in our article explaining Bluetooth profiles.

Installation Note: We recommend running a dedicated constant power wire to the battery for optimal performance from this Sony's amp — we offer an inexpensive wiring kit for this installation. This Sony's high-powered amp won't work in systems where an outboard factory amplifier is still active.

iPod/smartphone note: If you're going to use your iPod or smartphone with this receiver, be sure to check "Details" for compatibility information.
READ LESS

Product highlights:

    General Features:
    • CD receiver with AM/FM tuner
    • built-in MOSFET amplifier (45 watts RMS/100 peak x 4 channels)
    • plays CDs, CD-Rs, and CD-RWs, including discs loaded with MP3, WMA, and WAV files
    • MP3, WMA, AAC, FLAC, WAV playback from USB drives
    • Bluetooth hands-free calling and audio streaming
    • NFC offers instant Bluetooth pairing with compatible phones
    • detachable face with dual-zone variable color illumination
    • Sound Synchronization displays color changes timed to your music
    • remote control
    Smartphone Features (see Details for info on compatibility with specific smartphones and apps):
    • built-in iPod, iPhone, and iPad control
    • Pandora Internet radio control
    • music file playback from select Android devices through USB input
    • voice control with Android and Siri Eyes Free
    Audio Features:
    • EQ10 10-band equalizer
    • Digital Sound Enhancement Engine improves digital file sound quality
    • Listening Position time alignment
    • high- and low-pass filters
    • loudness
    Expandability:
    • compatible with SiriusXM satellite radio tuner
    • inputs: front panel auxiliary input; front and rear USB inputs
    • outputs: 6-channel preamp outputs (5-volt front, rear, subwoofer)
    Other Info:

    What's in the box:

    • CD receiver (15A fuse)
    • Face
    • Sleeve (installed)
    • Trim ring (installed)
    • Wiring harness
    • Wireless remote control (RM-X231)
    • CR2025 Lithium battery (installed in remote)
    • Microphone w/ bracket (attached 11' cord terminated by a right-angle mono 3.5mm connector)
    • Two-sided tape
    • 2 Radio removal tools
    • 4 Flathead ISO-mount screws
    • Face fixing screw
    • Operating Instructions (En/Fr)
    • Face fixing screw note
    • Important Notice For Dealer
    • Warranty Information

    Featured video:

    Customer reviews

    Loading reviews...

    Sony MEX-GS820BT reviews

    Average review:

    67 reviews

    Filter by rating

    Customer photos

    Sort reviews

    Sort by:
    Items per page:
    View page:

    Verified customer (What's this?)
    Verified employee purchase (What's this?)

    Pros:

    Cons:

    Crutchfield response

    << >>

    More details on the Sony MEX-GS820BT

    Stacey B.

    Features & specs

    Expandability
    AUX Input Front
    Audio/video Input ---
    USB Input Front/Rear
    Backup Camera Input No
    Second Camera Input No
    CarPlay No
    Android Auto No
    Siri Control Yes
    Android Control Yes
    Memory Card Slot USB
    Bluetooth Compatible Built-in
    Satellite Radio Ready SiriusXM
    HD Radio No
    Navigation ---
    iPod Compatibility
    Full size No
    Nano 7
    Touch 6/5
    iPhone 7+/7/6S+/6S/6+/6/5S/5/SE/4S
    General
    RMS Power (CTA-2006) 45 watts
    RMS Power (Manufacturer) 45 watts
    Peak Output 100 watts
    RMS Power Bandwidth 20-20kHz
    Preamp Outputs 6-channel
    Sub Preamp Outputs Yes
    Switchable Rear Preamp Outputs No
    Video Screen No
    Navigation App Compatible (iOS)
    Navigation App Compatible (Android)
    Preamp Voltage 5 volts
    Screen Size ---
    Display Color Variable
    Key Button Color Variable
    EQ Bands 10
    Wireless Remote Yes
    Steering Wheel Control Compatible Adapter required
    Parts Warranty 3 Years
    Labor Warranty 3 Years
    Tuner
    FM Sensitivity 8 dBf
    European Tuning No
    Seek/Scan Seek
    Radio Data System Yes
    File Playback
    Music File Playback MP3, WMA, FLAC
    High-res Playback N

    Product Research

    Built-in Bluetooth
    Android/iPhone Integration
    Pandora+SiriusXM+AM/FM Radio
    Disc/USB/Aux Playback
    Audio & DSP Section
    Remote Control
    Display Features

    Built-in Bluetooth

    Bluetooth 3.0: The Sony MEX-GS820BT is equipped with built-in Bluetooth 3.0, allowing you to make and receive phone calls wirelessly through the receiver; as well as stream music wirelessly from your smartphone to the head unit. In order to use Bluetooth wireless technology, your phone must also be Bluetooth compatible and be able to interpret certain profiles. This unit is compatible with the following Bluetooth Profiles:

    • Hands-Free Communication: HFP 1.6 (Hands Free Profile), PBAB 1.0 (Phone Book Access Profile).
    • Audio Streaming: A2DP 1.3 (Advanced Audio Distribution Profile), AVRCP 1.5 (Audio/Video Remote Control Profile).
    Note: Due to the differences in Bluetooth technology, some Bluetooth enabled devices may be incompatible, function improperly, or may not support all features when used with the Sony MEX-GS820BT.

    Multi-Device Pairing w/ Dual-Phone Connection: Up to nine Bluetooth-compatible devices can be paired to this receiver. You are even able to keep two Bluetooth-enabled phones connected at the same time, so you can make and receive calls from either phone through the head unit. Only one audio device can be connected at a time, which means only one of the two connected phones can stream audio. Once an already paired device is in close proximity to the Sony receiver, the two units will automatically re-connect. The head unit offers three pairing modes - SSP, NFC, & USB Auto

    • Simple Secure Pairing: With Simple Secure Pairing (SSP), you can easily pair a Bluetooth enabled phone to the Sony MEX-GS820BT without having to enter pin codes or go through complicated settings.
    • Near Field Communication (for Android): Android (OS 4.0+) smartphones that have Near Field Communication (NFC) pair simply by touching the Android device's NFC tag to the head unit's NFC tag on its rotary-knob. For older Android smartphones that don't have OS 4.0 or better installed, download the NFC Easy Connect app from Google Play to use the head unit's NFC pairing function.
    • USB Auto (for iPhone): You can pair your Apple iPhone (iOS 5.0+) by simply connecting it to the Sony head unit via USB and activating the Bluetooth function on your Apple device.

    Hands-Free Communication w/ External Mic: The Sony MEX-GS820BT supports Bluetooth hands-free communication for your Bluetooth enabled cell-phone (such as your iPhone or Android smartphone). Bluetooth hands-free communication helps to minimize distraction while driving by allowing you to control your mobile phone from the head unit, so you don't have to touch your mobile phone. The unit features an external microphone (featuring adjustable gain), so you can carry on your side of the conversation while listening to the caller through your vehicles speakers. And thanks to the latest Hands-Free Profile (HFP 1.6) with wideband speech capability, the MEX-GS820BT provides more natural sound quality and details during wireless calls.

    • Answering Calls: Incoming calls can be answered manually or automatically (between 3-10 seconds) through the Sony head unit, while the ring tone is output from your car speakers and the caller's name or phone number is displayed on the head unit's LCD. Incoming calls can also be rejected if desired.
    • Dialing a Number: Using the MEX-GS820BT, you can dial a phone number in one of the following ways.
      • Entering Phone #: Allows you to manually dial a phone number using the unit's control dial.
      • Preset Dial: You can store up to 6 contacts in the preset dial for quick dialing.
      • Phone Book: You can store up to 1,000 contacts in the unit's phone book. Up to a 40 character name can be input for each contact.
      • Call History: The unit will store the last 20 calls, allowing you to select a previous phone number quickly from the list.
      • Voice Dial: You can make a call using the voice tags stored on your connected cellular phone.
      • Redial: Use to easily redial the last number you called.
    Note: During a conversation, you can switch between the Private Mode (talking directly on your cell phone) and the Hands Free Mode.

    Wireless Audio Streaming: The Sony MEX-GS820BT supports wireless audio playback (AD2P) and control (AVRCP) of a Bluetooth-enabled smartphone or audio player, plus song/artist information display. You are able to stream your stored music library on your Bluetooth-enabled smartphone, as well as music apps downloaded on your smartphone to the Sony MEX-GS820BT for playback.

    • SBC + AAC Codecs: In addition to support for the standard SBC Bluetooth audio codec, the MEX-GS820BT offers support of AAC. By supporting AAC, the MEX-GS820BT offers better audio performance of the music streamed from your Apple iPod, iPhone, or iPad.
    • Music Browsing: In addition to basic playback functions (Play/Pause, FF/RW, Skip, Random/Repeat) for both stored music and music apps, the MEX-GS820BT provides a Search List of your stored music by Category or Playlist (AVRCP 1.4 phones only; which includes Android 4.0+ and iPhone 5.0+).
    • Song/Artist Information: The head unit will also display your stored music and music app's song information; such as Artist name and Song/Album title (not compatible with all apps).
    Note: When an incoming call or outgoing call is in progress from your Bluetooth enabled mobile phone, audio streaming will be paused so you can take your call. Once the call is finished, your streaming music will resume.

    Siri Eyes Free Control (for iPhone): When paired and connected to an iPhone with Siri via Bluetooth, the Sony MEX-GS820BT has the ability to access Siri through its front-panel controls and external microphone. Simply activate the "voice dial" function on the MEX-GS820BT to engage Siri and use the included microphone to communicate with Siri. Siri's voice will be heard through your vehicle's speakers. All Siri functions including hands-free calling, music search, setting reminders, text-messaging, audible navigation, and more can be done through the head unit and its microphone. You can even ask Siri to get directions to a destination and the turn-by-turn instructions will be heard through your vehicle's speakers, while the on-screen map still displays on your iPhone with Siri. The head unit's audio is attenuated while Siri provides audible directions.

    Note: The head unit will only display hands-free calling and Bluetooth audio information (all other functions of Siri are only audible through the MEX-GS820BT; visual data will still need to be viewed from your iPhone).

    Android & iPhone Integration

    Android Direct Connect via USB: The Sony MEX-GS820BT enables playback of stored music and music apps on select Android devices through its front- or rear-panel USB port. There are two types of modes (AOA 2.0 or MTP) to choose from based on your Android smartphone's operating system, what content you want to listen to, and what features you need.

    • AOA 2.0 (Android Open Accessory): The Sony MEX-GS820BT supports Android Open Accessory 2.0 (AOA 2.0), which lets you connect your Android smartphone (OS 4.1-7.1.2) to the MEX-GS820BT's USB port and listen to stored music and music apps from your Android device through the Pioneer receiver. You'll be able to control basic playback functions such as Play/Pause and Previous/Next Track (there is not song/artist/album info display). You'll also still be able to access other functions and applications from your Android smartphone's touchscreen, while listening to music through the head unit. If you make a call or answer a call from your smartphone while listening to music in this mode, the music will pause until you are finished with the call and then start back up again.
    • MTP (Media Transfer Protocol): The MEX-GS820BT also supports MTP for playback & control of stored MP3/WMA music files on your Android (OS 4.0+) device through the Sony receiver's USB port. In this mode, you get basic playback control (like Play/Pause & Previous/Next Track), plus song/artist information on the receiver's LCD screen. During MTP connection, you cannot use your Android smartphone's touchscreen to control music playback and you cannot select music apps from your smartphone for playback. However, you can continue to listen to stored music on your Android smartphone through the head unit while you check your Calendar, Facebook, Texts, etc on your phone.
    Note: Not all Android devices are compatible with AOA 2.0 or MTP, regardless of operating system.

    iPod/iPhone Direct Connect via USB: The Sony MEX-GS820BT supports direct connection of select Lightning or 30-pin Apple iPod/iPhone devices through its front or rear panel USB port. The MEX-GS820BT offers playback of your music library or music apps, music navigation and control, song/artist/album display, and charging of select Apple devices. Simply connect your compatible iPod/iPhone using the cable that came with your Apple device, or purchase another Lightning-to-USB or dock-to-USB cable (sold separately) to be used in the car.

    • Music Browsing: The unit offers basic playback controls - such as Play/Pause, Fast Forward/Rewind, Previous/Next Track, and Repeat/Random. Your iPod/iPhone will remain unlocked during connection, so you can continue to control your Apple device from its touchscreen for advanced music browsing and to access additional music apps.
    • Song/Artist Info: The digital media receiver will display your iPod/iPhone's stored music file information; including Track number, Elapsed playing time, Song Title, & Artist/Album Name. The MEX-GS820BT will also display song/artist information and station identification from select music apps.
    Note: Access to your iPhone's downloaded applications will depend on the availability of a cellular and/or WiFi network for purposes of allowing your iPhone to connect to the Internet.

    Smartphone Charging: The head unit's USB connection provides 1.5A of current to power and charge your connected Apple iPod/iPhone or Android smartphone when your vehicle's ignition switch is set to the 'ACC' or 'On' position (if your device has no initial battery charge, then the unit will not recognize it).

    iPod/iPhone Compatibility Chart: The Sony MEX-GS820BT is "Made for iPod/iPhone" compatible and supports the following iPod/iPhone model features (as of 10/20/2017):

    Apple Device Generation Tested Version Media Type Control Type Display Type Bluetooth Charge
    Audio Video Head Unit iPod/iPhone Music Center Pandora Artist/Song Text Track Info Phone Audio Siri
    iPhone
    4S 9.3.5 Y N Y Y Y Y Y Y Y Y Y Y
    5/5C 10.3.3 Y N Y Y Y Y Y Y Y Y Y Y
    5S 11.0.2 Y N Y Y Y Y Y Y Y Y Y Y
    SE 11.0.2 Y N Y Y Y Y Y Y Y Y Y Y
    6/6+/6S/6S+ 11.0.2 Y N Y Y Y Y Y Y Y Y Y Y
    7/7+ 11.0.2 Y N Y Y Y Y Y Y Y Y Y Y
    touch
    5th 9.3.5 Y N Y Y N N Y Y N Y Y Y
    6th 11.0.2 Y N Y Y N N Y Y N Y Y Y
    nano
    7th 1.02PC Y N Y Y N N Y Y N Y N Y
    Note: Apple iPod/iPhone software updates may change functionality results. If you download a newer software version, you may need to reset the head unit and your iPod/iPhone to regain functionality. If this doesn't work, you may need to wait until a newer software update is available.

    Pandora+SiriusXM+AM/FM Radio

    Pandora Internet Radio: The Sony MEX-GS820BT lets you playback and control the online Pandora music service that is being streamed to your USB or Bluetooth connected Apple iPhone (iOS 9.0+), or Bluetooth connected Android smartphone (OS 4.0+). The MEX-GS820BT will also display Artist, Album, & Song information provided by the Pandora app. Your iPhone or Android smartphone will need an active Data Plan account with connection to the Internet via 3G, EDGE, LTE (4G), or WiFi. In addition, you will need an active Pandora music service account. The Sony MEX-GS820BT provides the following control over the Pandora music service streamed to your USB-connected iPhone or Bluetooth-enabled Android smartphone.

    • Station List: You can select Pandora stations from your Station List by date or alphabetically (A-Z).
    • Skip Songs: You can skip song tracks within a station. You cannot skip back to a previous song. Pandora limits the number of skips allowed.
    • Thumbs Up/Down: You can give songs a thumbs up or thumbs down to help Pandora personalize stations to suit your preferences.
    • Bookmarking: The song or artist currently being played can be bookmarked & stored in your Pandora account.

    Note: Access to the Pandora service will depend on the availability of a cellular and/or WiFi network for purposes of allowing your iPhone or Android smartphone to connect to the Internet. Pandora is not supported in Canada and only available in the United States.

    SiriusXM-Ready: The Sony MEX-GS820BT is SiriusXM-Ready and compatible with the SiriusXM Connect Vehicle Tuner (220SXV300 sold separately). The SiriusXM Connect Vehicle Tuner supports SiriusXM programming with access to 175+ SiriusXM channels via subscription; check out the most popular SiriusXM subscription packages here. Additional features of the SiriusXM Connect tuner include:

    • Channel list displays a list of all available channels
    • Category Search searches for channels in a certain category
    • Displayed Information such as Channel Name, Artist Name, & Song Title can be viewed on the head unit's LCD
    • Up to 18 SiriusXM Satellite Radio station presets
    • Channels containing unsuitable content for children can be blocked
    Note: A separate SiriusXM Satellite Radio subscription is required (operates on the XM Network). However, you can easily add this SiriusXM tuner to an existing Sirius or XM account for a Multi-Radio Discount Plan.

    Digital Clarity Tuner w/ RDS: The Sony MEX-GS820BT CD receiver is equipped with a Digital Clarity Tuner for clear AM/FM stereo sound with digital processing technology. The Radio Data System (RDS) feature displays radio broadcast information such as artist & track information when listening to compatible AM/FM stations. The radio features 5 memory bands to store and receive AM/FM stations. You can store up to 6 presets in each in band (FM 1-3/AM 1-2), for a total of 18 FM presets and 12 AM presets. Presets can be stored automatically using the Best Tuning Memory (BTM) feature.

    Disc/USB/Aux Playback

    Disc Compatibility: The Sony MEX-GS820BT features a single disc player that will playback CD-Audio and finalized CD-R/CD-RW audio discs. The unit supports the playback of MP3, WMA, and AAC music files on a CD-R or CD-RW disc.

    • Off Insert/Eject: A CD can be inserted or ejected with the power off. The head unit will automatically begin disc playback, when a disc is inserted with the receiver set to a different source.
    • Auto Reload: The CD player will automatically reinsert the disc if it's ejected, but not removed for 20 seconds or more.
    • Mounting Angle: For proper CD playback, this unit must be mounted between 0° (horizontal) and 45°.

    USB MSC (Mass Storage Class) Playback: The head unit features a front-panel USB (type-A) port hidden behind a sliding cover and a rear-panel USB (type-A) port attached to the rear-chassis via a 58" cable. The receiver's USB ports can be used for plugging in (MSC) Mass Storage Class USB devices, such as a USB thumbdrive or portable digital audio player. The head unit can play MP3, WMA, AAC, WAV, and FLAC music files stored on compatible USB device. USB portable devices that can be charged via USB will be charged when plugged into the CD receiver's front-panel (1A) or rear-panel (1.5A) USB port, and the vehicle's ignition switch is set to ACC or On.

    Music File Playback: The Sony MEX-GS820BT supports the a variety of music files recorded onto CD-R/RW disc or loaded onto a USB mass storage class device; see below for details.

    Media Type CD-R/RW USB MSC Device
    File System ISO9660 Level 1/2, Romeo, or Joliet, FAT 16/32
    Playable File Types MP3: bit rate of 8-320kbps with sampling frequency of 16-48kHz
    WMA: bit rate of 32-192kbps with sampling frequency of 32, 44.1, or 48kHz
    AAC:
    bit rate of 8-320kbps with sampling frequency of 11.025-48kHz
    MP3: bit rate of 8-320kbps with sampling frequency of 16-48kHz
    WMA: bit rate of 32-192kbps with sampling frequency of 32, 44.1, or 48 kHz
    AAC:
    bit rate of 8-320kbps with sampling frequency of 11.025-48kHz

    WAV:
    bit depth of 16-bit with sampling frequency of 44.1 or 48kHz
    FLAC:
    bit depth of 16 or 24-bit with sampling frequency of 44.1 or 48kHz
    Maximum # of Folders/Files 150 folders/300 files 10,000 total tracks
    Tags ID3 (version 1.0/1.1/2.2/2.3/2.4), WMA, AAC, && FLAC tags

    Song/Artist Information: The CD receiver can display the following ID3, WMA, AAC, and FLAC tag information; Track number, Elapsed Playing Time, Song Title, Artist Name, or Album Label.

    Playback & Search Functions: The Sony CD receiver offers a variety of unique playback & search functions.

    • Quick-BrowZer: The unit's Quick-BrowZer feature allow you to search for a track on a CD or connected USB Mass Storage Device easily by category (Genre, Artist, Album, or Playlist).
    • Jump Mode: Jump Mode gets you closer to the song you want by allowing you to fast forward through a music folder in 10% increments.
    • Repeat/Random: Repeat a single track or repeat an entire folder. Shuffle all tracks or a specific folder.

    Front-Panel Auxiliary Input: A front panel stereo 3.5mm mini-jack is provided to allow the connection of a portable audio source. Just connect your portable digital music player to this unit, and you can listen to the audio from the portable player through the speakers in your mobile audio system. The volume level of the auxiliary input is adjustable from -8 to +18 dB to compensate for any difference between the unit and your portable device. The aux input can be deactivated in the menu, so it does not appear as an available source.

    Audio & DSP Section

    High Power Class-D Amplifier: A built-in class-D amp delivers huge power with minimal interference, for audio that's crystal clear even at its loudest. Circuitry and components are carefully laid out for low-noise, highly efficient electric power transmission. Placing the power block close to the input and amp minimizes power loss, while electrolytic capacitors ensure precise, responsive bass. An oversized heat sink with an optimally designed fin structure ensures efficient ventilation for your amp.

    Notes:
    • Because of its high-powered amplifier design, the Sony MEX-GS820BT does require that a separate +12V constant power wire is run to the battery with a separate inline 15A fuse in vehicles with lower than a 15A fuse protecting the factory radio. Check out the "Accessories" tab for wiring kit.
    • This Sony receiver's built-in high-powered amplifier isn't compatible with car audio systems where an outboard factory amplifier will remain active.

    CTA2006 Compliant: The power specifications for the Sony MEX-GS820BT are compliant with the CTA2006 Mobile Amplifier Power Testing and Measurement standards from the Consumer Technology Association (CTA). These standards were developed as a way to equitably compare power specs from model to model and between manufacturers. The power output specs for the MEX-GS820BT are as follows:

    • Continuous Power Output: 45 watts RMS x 4 channels (at 4 ohms, 20Hz-20kHz, 1% THD-N)
    • Peak Power Output: 100 watts x 4-channels (400 total watts)

    6ch/5V Preamp Outputs + Sub Control: The Sony MEX-GS820BT is equipped with 5-volt Front, Rear, & Sub pre-amp outputs giving you the ability to connect external amplifiers to your car stereo system. The unit's subwoofer preamp output is non-fading. You can adjust the subwoofer preamp output's volume level independently from the head unit's main volume control from -10 to +10 in 1dB increments. In addition, you can select the phase of the subwoofer output from Normal or Reverse.

    Note: You can also connect a subwoofer to this head unit without the need of a separate power amplifier. Simply connect a single subwoofer (4-8 ohm) directly to head unit's left or right rear speaker leads (but not both). Same subwoofer controls apply.

    High-Pass & Low-Pass Crossovers: The front & rear speaker outputs offer a selectable high-pass crossover frequency of 50Hz, 60Hz, 80Hz, 100Hz, 120Hz, or Off. You can also adjust the slope (1/2/3) of the high-pass crossover. The subwoofer preamp output features a low pass filter with a selectable cut-off frequency of 50Hz, 60Hz, 80Hz, 100Hz, 120Hz, or Off. You can also adjust the slope (1/2/3) of the low-pass crossover.

    EQ10: Select from a variety of EQ presets like R&B, Rock, Pop, Dance, Hip-Hop, Electronic, Jazz, Soul, Country, Custom, or Off (Flat). The Custom mode allows you to make your own equalizer settings. You can adjust the level (+/-6dB) of 10 different frequency bands - Band 1 (32Hz), Band 2 (63Hz), Band 3 (125Hz), Band 4 (250Hz), Band 5 (500Hz), Band 6 (1khz), Band 7 (2khz), Band 8 (4kHz), Band 9 (8kHz), and Band 10 (16kHz).

    Digital Time Alignment (DTA): This unit can change the localization of sound by delaying the sound output from each speaker to suit your position, and simulate a natural sound field with the feeling of being in the center of it wherever you sit in the car. You can choose from Front Right, Front Left, Front Center, or Off. You can also set the subwoofer distance of the subwoofer to Near, Normal, or Far. You can also further fine tune the listening position from -3 to +3.

    DSO & DSEE: Dynamic Stage Organizer (DSO) adjusts the signal, improving the stereo positioning so music sounds like it's coming from the dashboard. Digital Sound Enhancement Engine (DSEE) improves digitally compressed music files by restoring high frequencies lost in the compression process.

    ExtraBass + RBE: Activate ExtraBass at the touch of a button for an instant, low-end boost. Unlike conventional bass boosters, ExtraBass minimizes distortion at all volume levels by automatically adjusting frequency and gain to their optimal positions. RBE (Rear Bass Enhancer) enhances the bass sound by applying the low-pass filter setting to the rear speakers. This function allows the rear speakers to work as a subwoofer even if there is no subwoofer connected.

    ClearAudio+: ClearAudio+ reproduces sound by optimizing the digital signal with the Sony recommended sound settings. It automatically adjusts the head unit's EQ, ExtraBass, and DSO.

    Advanced Auto Volume (AAV) + Loudness: This feature adjusts the playback volume level of all playback sources to the optimum level. Loudness reinforces bass and treble for clear sound at low volume levels.

    Beep Tone: The in-dash head unit provides an audible beep to confirm button operation. This function can be turned On or Off.

    Remote Control

    Music Center App (formerly know as SongPal): Download Sony's free Music Center app (for Apple iOS 9.0+ and Android OS 4.4+) onto your Bluetooth connected Apple iPhone or Android smartphone and take control of the Sony MEX-GS820BT head unit right from your mobile device. You'll enjoy control over basic head unit functions, as well as navigation and seamless access to all your sources, music, apps, and more from your smartphone. The Music Center app also integrates Apple iOS and Android apps into the selectable source list of the Sony MEX-GS820BT and lets you launch apps from the head unit. In addition the app can also be used to help customize sound and display settings of the Sony receiver.

    • Receiver Sources: From the Music Center app on your smartphone device you can access and select the head unit's Tuner (AM/FM), CD, USB, Bluetooth, and Aux sources. You'll also be able to control basic playback functions such as Play/Pause and Previous/Next Track or Station. In addition, you'll be able to view song/artist information and station identification from the Music Center app on your mobile device.
    • Add-On Applications: You can integrate music, movie, navigation, and other applications that are already on your smartphone device within the Music Center app for easier access. Once an app is selected within the Music Center app, your smartphone's screen will divert to selected app. Audio of that source will be played through the MEX-GS820BT; any visual data will only be displayed by your iPhone or Android device. Basic playback functions such as Play/Pause and Next Track are available from the head unit; advanced control functions are still done from your smartphone device.
    • Volume & Sound Adjustments: You can access the head unit's sound menu and make adjustments from the app on your iPhone or Android device. Sound adjustments included Volume Up/Down, Balance/Fader, EQ, ExtraBass, and Sub Level.
    • Display Settings: Using the Music Center app on your iPhone or Android device you can make adjustments to the head unit's front-panel LCD and button illumination. Make changes to the preset color of the LCD and/or button illumination, as well as activate or deactivate Sound Synchronization.
    • Voice Recognition (Android only): You can use voice commands to ask for directions from Google maps or to play a particular song/artist in your smartphone's music library. You can even assign a music application within the Music Center app as a voice tag, so you can access it by simply speaking the name of the application. While using voice commands there will still be times where you have to make a selection on your smartphone's touchscreen.
    • Notification Readout (Android only): Exclusive to Android devices, incoming SMS/E-mail and Twitter/Facebook/Calendar notifications are automatically read aloud through the MEX-GS820BT and your vehicle's speakers to keep you safe and in touch. You can even reply to a text message via voice command and a list of preset replies.

    Wireless Remote Control: The head unit comes supplied with an IR wireless remote control (RM-X231) for easy operation. The included wireless remote allows you to control the basic functions (not Bluetooth) of the Sony head unit while keeping your eyes on the road.

    Steering Wheel Remote Compatibility: The head unit features an OEM steering wheel remote control input on the rear of the unit that lets you keep your vehicle's factory radio steering wheel remote controls when used with an optional steering wheel audio control adapter (sold separately).

    Display Features

    Detachable Face w/ Caution Alarm: The Sony MEX-GS820BT features a detachable face for theft prevention. If you turn the ignition switch to the Off position without detaching the head unit's front-panel, the caution alarm will sound for a few seconds. The alarm will only sound if the unit's built-in amplifier is used. No face case is included with this unit. An optional soft face case (142DFC1X, sold separately) can be purchased for this unit. A face-fixing screw is supplied for making the face non-detachable, if desired.

    High-Contrast LCD: With 5x the contrast of conventional screens, plus an optimized viewing angle, the MEX-GS820BT's LCD screen is always easy to read. You can adjust its brightness level from 1-10. You can also set its dimmer to Auto, Clock, On, or Off. The Auto mode dims the head unit's display automatically when you turn your vehicle's lights on (illumination wire must be connected). The Clock mode allows you to set a fixed time for when the display's dimmer is turned on and off.

    Dynamic Color Illuminator (35,000 colors): Dynamic Color Illuminator lets you match the head unit's LCD & button illumination to complement your existing vehicle lighting components. You can select from 15 preset colors or a customized color (R-G-B). You can choose to use the same color for the LCD screen and button illumination, or use a separate color for each one. You can even set the head unit's LCD screen's illumination to pulse with your music.

    Sound Synchronization: The color illumination changes according to synchronization of playing music and sound.

    Auto Scroll: The Auto Scroll feature allows long displayed items to scroll automatically across the display when the track is changed on a disc or device.

    Display Illumination/Clock Display: Pressing the SRC/OFF button once will switch sources. Pressing and holding the SRC/OFF button for one second will turn off audio output, but the clock display and button illumination remain on. To turn the unit off completely, you must press and hold the SRC/OFF button for two seconds.

    Auto Off: When installing in a vehicle without an accessory power wire at the radio location, you can set the unit to turn off all lighting after 30 minutes of the power being turned off to the head unit.

    Demo Mode: The head unit's demo mode can be turned On or Off.

    Loading accessories...

    Customer Q&A

    Q
    Crutchfield asked: Why did you buy this?
    A
    Distortion Free Units! [ Peter  Aug 30, 2019 ]
    A
    100 watt per channel [ Kyle  Jun 05, 2019 ]
    A
    Power of unit. [ Daniel  Feb 15, 2019 ]
    A
    Seems to have the best mix of features and power for the money [ G  Feb 08, 2019 ]
    A
    Features and output [ NICK  Feb 02, 2019 ]
    A
    chat adviser recommended it [ Rob  Jan 16, 2019 ]
    A
    I purchased this HU based on the high reviews it received and the manufacturers warranty. [ Don  Dec 13, 2018 ]
    A
    Familiar with product [ joseph  Nov 26, 2018 ]
    A
    I chose this unit because the Alpine stereo I bought in December of 2015 has developed gremlins. I won't be buying Alpine again, and this is Sony's first and only chance to impress me. I'll see what happens 2-3 years from now. [ Joseph  Aug 16, 2018 ]
    A
    good price, the unit had good write-ups and for the power great deal [ Thomas  Aug 08, 2018 ]
    A
    My factory stereo has failed, I wanted something with the same features, same power, etc. [ Paul  May 13, 2018 ]
    A
    power [ william  Apr 04, 2018 ]
    A
    the best trade off of features in my price range [ GLENN  Mar 11, 2018 ]
    A
    Highly sought after high powered unit. Great for Jeep to hear over road noise created by larger tires. Great Crutchfield prices!!! [ Michael  Nov 29, 2017 ]
    A
    The best rms rating [ Michael  Nov 11, 2017 ]
    A
    Had all the features I wanted at a good price. [ Stephen  Oct 21, 2017 ]
    SHOW MORESHOW LESS

    17 questions already asked

    Q
    What is the warranty length?
    [ Richard  Feb 11, 2019 ]
    1 answer
    A
    It's 3 years! You'll find this info under the "Product Highlights" section on the stereo's main webpage and also by clicking the "Details" tab. I hope that helps. My bio: https://www.crutchfield.com/bio/Ryan
    [ Ryan  Feb 15, 2019 ]  Staff
    Q
    Will it charge a phone when hooked up to USB port?
    [ Matthew  Feb 03, 2019 ]
    2 answers
    A
    Of course it does.
    [ Joan  Feb 06, 2019 ]
    A
    Yes, plus play any mp3 that are on the SD card.
    [ Amy  Feb 06, 2019 ]
    Q
    What is the difference between this and the MEX-XB120BT? It's hard for me to tell based on the specs.
    [ Eric  Jan 12, 2019 ]
    1 answer
    A
    Thanks for your question. For information on comparing two or more models I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences and help you make the best choice for your system and your budget.
    [ Krissy  Jan 15, 2019 ]  Staff
    Q
    Will this work with an iPhone X?? The specs show up to an 8, but on other units it lists the X. I'd think it would, but want to be sure before I pull the trigger.
    [ 202382  Oct 23, 2018 ]
    1 answer
    A
    Yes. The stereo was developed and tested before the X became available but the USB port is compatible with all of the lighting-connector iPhone models.
    [ Ryan  Nov 02, 2018 ]  Staff
    Q
    Wondering if the time alignment on this unit is fully adjustable (in feet/inches) or if the settings are more general (normal, far, near)? Thanks!
    [ Jeremy  Aug 09, 2018 ]
    2 answers
    A
    not exactly sure what your referring to, but i will assume it is for the listening position option. It seems to be more of a general adjustment, ref. owners manual pg. 23.
    [ michael  Aug 11, 2018 ]
    A
    They are general.
    [ Amy  Aug 10, 2018 ]
    Q
    I can not browse through playlists on my connected ipod. Is this because I have an old ipod, or can this receiver not browse through ipods???
    [ nick  Jul 23, 2018 ]
    2 answers
    A
    I was going to say to call their customer service on crutchfield website, they are really professional and should be able to answer that question
    [ sirpal1971  Jul 25, 2018 ]
    A
    I dont have an IPod, never tried
    [ KATHY  Jul 24, 2018 ]
    Q
    Direct 12ga power cable for Sony mex-gs820bt . This new model has a small 18ga power wire coming out from the head unit . Should a step down butt connector be used to go from 18 ga. To 12 ga. ? Sony's earlier 4 x 45 RMS models used a much larger ga. Out for power !
    [ Scott  Jun 15, 2018 ]
    3 answers
    A
    You can do it.
    [ Joan  Feb 06, 2019 ]
    A
    Hey Scott! I also have he Sony MEX model in question however since I now have an Audi TT with an alarm I didn't want to attempt installing this myself. I had a local company install it so I have no idea what they did. I can tell you this unit sounds amazing and I'm super happy with my choice.beat of luck!!
    [ Lynne  Jun 20, 2018 ]
    A
    The bigger ga would be nice. I use solder seal wire connectors, they're heat shrink/solder in one. If you can use a heat gun, you can solder and shrink like a pro.
    [ jason  Jun 20, 2018 ]
    Q
    So I am installing the MEX-GS820BT with its high power internal amp 45watt x 4 . I ordered it with the ready/harness . My concern is the small gauge power & ground wires coming out of the receiver compared to the heavy ones on sony's earlier models with this much power . Crutchfield recommended the use of a 12Ga. wire kit . Do I just connect the small lead of the harness to the much larger 12Ga from the battery ? Have found very little info online about this Sony model !
    [ Scott  Jun 08, 2018 ]
    3 answers
    A
    I agree with the best answer.
    [ Joan  Feb 06, 2019 ]
    A
    I used the kit that was recommended by crutchfield it was strange to me but everything works great. This stereo is amazing.
    [ Nathan  Jun 18, 2018 ]
    A
    I ran into the same concern when installing this stereo. I also purchased the 12 gauge wiring kit to power it directly from the battery. With the power wires, I crimped a butt connector to both the stereo wire and the 12 gauge wire coming from the battery and then inserted a 20 amp fuse (I believe it was a 20 amp fuse. It was the same amp fuse that comes with the 12 gauge wiring kit) into the other ends of the butt connectors to connect them together. I didn't crimp them to the fuse but used electrical tape. This way if the battery was to much power for the stereo wire the fuse would blow instead of frying the stereo wire. For the ground I just butt connected them together and grounded it on the metal floor. It worked great and I have had no issues. It made me feel better having a safety fuse between the two power wires. I hope this helps.
    [ Jason  Jun 15, 2018 ]
    Q
    Do I need a Rux knobe for my Alpine mono subwoofer amp or will I be able to do that through this head unit ?
    [ Scott  Jun 06, 2018 ]
    2 answers
    A
    The Sony MEX-GS820BT does include subwoofer controls so you can adjust the subwoofer's volume level independently from the head unit's main volume control (from -10 to +10 in 1dB increments). For more details or to discuss further, please contact an Advisor directly by phone (888.955.6000) or online chat. Thanks!
    [ Larry  Jun 19, 2018 ]  Staff
    A
    what is a RUX knobe?
    [ michael  Jun 18, 2018 ]
    Q
    Can I attach my Sony 10 disk changer to this?
    [ Porscheguy  May 04, 2018 ]
    3 answers
    A
    Why would u want too if you have a good streaming music app?
    [ Joan  Feb 06, 2019 ]
    A
    U should ask Crutchfield experts. I think u can but not 100% sure.
    [ Joan  May 09, 2018 ]
    A
    You will want to contact an Advisor by phone (1-800-324-9695) or online chat to discuss compatibility with your factory system. They will be able to pull up your vehicle and see if this will integrate. If it does not, then they will also be able to discuss other options with you.
    [ Krissy  May 08, 2018 ]  Staff
    Q
    separated hpf setting for front and rear speakers?
    [ alireza_asol  Feb 16, 2018 ]
    1 answer
    A
    The high-pass crossover settings used on the Sony MEX-GS820BT would be applied to both the front & rear speakers (together). For more details or to discuss further please feel free to contact an Advisor directly by phone (888.955.6000) or online chat. Thanks!
    [ Larry  Feb 21, 2018 ]  Staff
    Q
    Is it possible to lock a certain color and keep it the whole time so it doesn't change colors while playing music?
    [ Anthony  Jan 03, 2018 ]
    8 answers
    A
    yes, once you delete the demo mode (that is what most see in video's) there are 2 zones, buttons and display you can set to different color's and several modes, one will dance with music, another just changes thru range of colors I used the song pal app, its easy to set up with a wide range of colors, sound tuning, vehicle tuning ect. it does flash white when you change modes or make a change balance ect. example: using the source button on radio and switching from radio to BT it will flash white then return to set color hope this helps IMHO amazing sound quality, without an external amp. very versatile head unit
    [ ROBERT M  Jan 04, 2018 ]
    A
    Yes you can. I have one color for the central info and a second color for the control buttons. Matches my dash perfect. Consult your manual for the details.
    [ Joseph Scott  Jan 04, 2018 ]
    A
    Yes, you can set a color for the face and a different color for the display. You can use 2 different colors or one color for everything. To stop the colors from changing, turn the DEMO MODE TO OFF.with the big button. 1 hit the button, go to DEMO ON HIT THE SIDE BOTTOM to set to OFF. and that's it.
    [ FRANCISCO  Jan 04, 2018 ]
    A
    Yes, take it out of demo mode
    [ Heather  Jan 04, 2018 ]
    A
    Yes. You can set the entire front panel to a specific color or a color scheme that does not change with the music. You can also program the display and the buttons/dials to two different colors.
    [ Aaron  Jan 04, 2018 ]
    A
    Yes, there is a wide variety of colors to set from and you can set it to a specific color so it won't change.
    [ Bobby  Jan 04, 2018 ]
    A
    Yes, I forget exactly how.... in the display menu somewhere
    [ David  Jan 04, 2018 ]
    A
    I use the APP ( Sony Music Center) to lock the colors I want.
    [ Carlos  Jan 03, 2018 ]
    Q
    I noticed it was recommended to wire directly to the car battery with a 12 gauge kit. Are there directions where to connect the 12 gauge wire to the head unit?
    [ Christopher J.  Dec 07, 2017 ]
    5 answers
    A
    You connect the power cable to the yellow cable coming out of head unit. I just cut it long and folded it to get a good connection on the larger connector before crimping. Be sure to add an inline fuse close to battery. I bought the 12 gauge kit they suggested and it came preinstalled. Great radio and happy with my purchase. It gives you more power without an amp. For super loud an amp is the way to go. I just wanted some extra power without an amp so it fits my needs.
    [ Guest  Dec 08, 2017 ]
    A
    I had mine professionally installed. But I do. believe the owners manual goes through the installation process and how to connect to the battery. So far I'm very please with this stereo. I used this with a small 8" powered sound ordinance sub and the combo is very good.
    [ Michael  Dec 08, 2017 ]
    A
    I have no clue. It is a gift for my son, so I won't open it till after Christmas.
    [ Michael  Dec 08, 2017 ]
    A
    I recently installed this Sony in my 1995 Toyota 4Runner. The Wiring Harness that comes with the order for your specific vehicle, will need to be soldered and heat shrinked to the Wiring Harness from thw back of rhe Sony. There are clear instructions on connecting the specific wire directly to the battery. I elected not to do this and wire it as directed on the installation sheet. In the future, I may do a test someday to determine if the unit is putting out full power and delivering optimum performance. I did notice this unit seems a bit "Underpowered" for the EMS Rating and distorts faster than I expected as the volume is increased. I installed new Memphis Audio 4" Direct Fit drivers in front and Focal 5 1/4" drivers direct fit on the rear, with no subwoofer. It sounds very good compared to the old factory radio. I love the features, lighting, bell's and whistles and amazing interface and sound fields. Bluetooth is fantastic ! Added XM tuner. Very satisfied!
    [ John  Dec 08, 2017 ]
    A
    Buy the recommended wire kit. It includes the fuse. Then it is pretty straight forward, in that you need to find a path though the firewall. If this sounds confusing, watch a YouTube video or hire someone to do it.
    [ Ed  Dec 08, 2017 ]
    Q
    Hi, is the facia detachable?
    [ Sylver  Nov 17, 2017 ]
    6 answers
    A
    Yes it is
    [ Paul  Dec 01, 2017 ]
    A
    Yes
    [ Brad  Nov 29, 2017 ]
    A
    Yes, but it does not bring a case. Brought that separate.
    [ FRANCISCO  Nov 28, 2017 ]
    A
    Yes it is.
    [ Carlos  Nov 28, 2017 ]
    A
    The face is detachable.
    [ DOUGLAS  Nov 28, 2017 ]
    A
    I have not opened the box yet. I do not know. Sorry
    [ Randolph  Nov 28, 2017 ]
    Q
    Can this hu be used with a Pixel 2 phone?
    [ Drewski  Nov 07, 2017 ]
    1 answer
    A
    Yup! Works well with nearly all Android phones. I recommend using Android Auto (the app) with it for the hands free features. I'm using a OnePlus One and Motorola E4 and various newer LG phones here.
    [ Strongtut  Nov 07, 2017 ]
    SHOW MORESHOW LESS

    Loading articles...

    TOP
