About the Rockford Fosgate P16
High-quality replacement speakers
High-quality replacement speakers
Rockford Fosgate designed the Punch P16 6-1/2" speakers as a high-grade replacement for your factory speakers. Each speaker features a responsive polypropylene cone and butyl rubber surround that'll stand up to hours of high-volume jams. The dome tweeter provides clear, extended highs that can hold their own when the bass gets heavy.
Rockford Fosgate innovations
Take a closer look and you'll notice a couple of cool innovations. Rockford Fosgate uses a new technique to attach the surround to the cone that yields up to 25% more cone area, for fuller sound and stronger performance. The slots around the frame eliminate the need to redrill screw holes when the factory holes are just a little bit off. And these speakers come with adapter plates that you can modify to install these speakers into 5"x7", 6"x8", or 6"x9" openings. Grilles are included.
Note: The oversized terminals on these speakers won't connect to a Crutchfield wiring harness. A free 10-pack of female quick slides that you can splice onto our harness will be included with your speaker purchase.
- 2-way 6-1/2" speakers (pair)
- mineral-filled polypropylene woofer
- butyl rubber surround
- 3/4" polyetherimide (PEI) dome tweeter
- includes adapter brackets for 5"x7", 6"x8", or 6"x9" openings (brackets require modification)
- grilles included
- Vertical Attach Surround Technique (VAST™) increases cone area
- power range: 6-55 watts RMS (110 watts peak power)
- frequency response: 65-22,000 Hz
- sensitivity: 88 dB
- top-mount depth: 1-15/16"
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # P16
What's in the box:
- Two 2-way speakers
- 2 Grilles
- Two 6x9/5x7 Adapter brackets
- Eight 1-1/4" Allen head screws
- 3mm Allen head bit
- 8 Speed clips
- Installation/Operation manual (English/ French/ Spanish/ German/ Italian)
More details on the Rockford Fosgate P16
Features & specs
|Tweeter Design||3/4" Dome|
|Woofer Composition||Mineral filled poly|
|Woofer Surround||Butyl rubber|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||88|
|Sensitivity at 2.83 volts||91|
|Frequency Response||65 - 22k Hz|
|Minimum RMS Wattage||6|
|Maximum RMS Wattage||55|
|Peak Power Handling (Watts)||110|
|Top-mount Depth (Inches)||1 15/16|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||5|
|Mounting Height (Inches)||0.825|
Injection-Molded Polypropylene Woofers: The woofer cones are mineral filled, injection-molded polypropylene. This molding process assures a uniform cone thickness for superior linearity and clarity. It is also light weight and rigid for decreased distortion and improved bass response.
Butyl Rubber Surrounds: The butyl rubber surrounds dampen unwanted harmonic distortion while maintaining linear geometry under extreme weather conditions. This leads to less distortion, superior frequency response, and superior durability.
VAST Surround: The Vertical Attach Surround Technique (VAST) increases a speaker's effective radiating cone area without increasing the size of the basket.
Tweeters: Each speaker features a 3/4" PEI (Poly-Ether-Imide) dome tweeter; PEI is a polymer film that produces a wide soundstage for superior imaging.
FlexFit Basket: The Flex Fit frame utilizes slots (where possible) instead of single screw sized holes; allowing slight adjustment of the speaker when mounted.
StampCast Basket: The P16 features StampCast steel baskets for added rigidity.
Mounting: While Rockford Fosgate calls the P16 a 6" speaker, they are sized to mount in standard three-hole and four-hole 6-1/2 applications. They can also be easily mounted in 6-3/4 applications, but because the extra screw holes create an air leak in the larger opening, speaker baffles must be used.
Adapter Bracket: For mounting flexibility, the included brackets can be modified to fit 5x7, 6x8, or 6x9 applications.
Note: The bracket is generic (cutout sized for a 5-1/4) and requires modification before the P16 will fit into it.
Speaker Terminals: These speakers have 0.25" wide positive (+) terminals and 0.187" wide negative (-) terminals, which are too large for the vehicle-specific speaker harnesses supplied by Crutchfield for many vehicle applications. It is recommended that a pack of assorted female quick slides (item number 120FQS10PK, sold separately) be purchased and spliced to the harnesses to adapt them to the speaker terminals.
