About the Rockford Fosgate P1675
High-quality replacement speakers
High-quality replacement speakers
Rockford Fosgate designed the Punch P1675 6-3/4" speakers as a high-grade replacement for your factory speakers. Each speaker features a responsive polypropylene cone and butyl rubber surround that'll stand up to hours of high-volume jams. The dome tweeter and supertweeter provide clear, extended highs that can hold their own when the bass gets heavy.
Rockford Fosgate innovations
Take a closer look and you'll notice a couple of cool innovations. Rockford Fosgate uses a new technique to attach the surround to the cone that yields up to 25% more cone area, for fuller sound and stronger performance. The slots around the frame eliminate the need to redrill screw holes when the factory holes are just a little bit off. And these speakers come with adapter plates that you can modify to install these speakers into 5"x7", 6"x8", or 6"x9" openings. Grilles are included.Note: The oversized terminals on these speakers won't connect to a Crutchfield wiring harness. A free 10-pack of female quick slides that you can splice onto our harness will be included with your speaker purchase.
- 3-way 6-3/4" speakers (pair)
- mineral-filled polypropylene woofer
- butyl rubber surround
- 3/4" and 1/2" polyetherimide (PEI) dome tweeter and supertweeter
- includes adapter brackets for 5"x7", 6"x8", or 6"x9" openings (brackets require modification)
- grilles included
- Vertical Attach Surround Technique (VAST™) increases cone area
- power range: 6-60 watts RMS (120 watts peak power)
- frequency response: 60-24,000 Hz
- sensitivity: 89 dB
- top-mount depth: 2-1/4"
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # P1675
What's in the box:
- Two 3-way speakers
- 2 Grilles
- Two 6x9/5x7 Adapter brackets
- Eight 1-1/4" Allen head screws
- 3mm Allen head bit
- 8 Speed clips
- Installation/Operation manual (English/ French/ Spanish/ German/ Italian)
More details on the Rockford Fosgate P1675
Features & specs
|Speaker Size||6 3/4|
|Tweeter Design||3/4" Dome|
|Woofer Composition||Mineral filled poly|
|Woofer Surround||Butyl rubber|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||89|
|Sensitivity at 2.83 volts||92|
|Frequency Response||60 - 24k Hz|
|Minimum RMS Wattage||6|
|Maximum RMS Wattage||60|
|Peak Power Handling (Watts)||120|
|Top-mount Depth (Inches)||2 1/4|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||5 5/8|
|Mounting Height (Inches)||0.611|
Injection-Molded Polypropylene Woofers: The woofer cones are mineral filled, injection-molded polypropylene. This molding process assures a uniform cone thickness for superior linearity and clarity. It is also light weight and rigid for decreased distortion and improved bass response.
Butyl Rubber Surrounds: The butyl rubber surrounds dampen unwanted harmonic distortion while maintaining linear geometry under extreme weather conditions. This leads to less distortion, superior frequency response, and superior durability.
VAST Surround: The Vertical Attach Surround Technique (VAST) increases a speaker's effective radiating cone area without increasing the size of the basket.
Tweeters: Each speaker features two tweeters, 1/2" and 3/4" domes. The material used is PEI (Poly-Ether-Imide); PEI is a polymer film that produces a wide soundstage for superior imaging.
FlexFit Basket: The Flex Fit frame utilizes slots (where possible) instead of single screw sized holes; allowing slight adjustment of the speaker when mounted.
StampCast Basket: The P1675 features StampCast steel baskets for added rigidity.
Adapter Bracket: For mounting flexibility, the included brackets can be modified to fit 5x7, 6x8, or 6x9 applications.
Note: The bracket is generic (cutout sized for a 5-1/4) and requires modification before the P1675 will fit into it.
Speaker Terminals: These speakers have 0.25" wide positive (+) terminals and 0.187" wide negative (-) terminals, which are too large for the vehicle-specific speaker harnesses supplied by Crutchfield for many vehicle applications. It is recommended that a pack of assorted female quick slides (item number 120FQS10PK, sold separately) be purchased and spliced to the harnesses to adapt them to the speaker terminals.
