About the Rockford Fosgate T1650
The tweeter is mounted on an offset suspension system, minimizing any acoustic reflections.
Rockford Fosgate builds their Power Series speakers for people who won't put up with inferior sound in their cars. These Power T1650 6-1/2" speakers utilize advanced design elements to ensure that they'll deliver superior sound in your vehicle for a long, long time. The lightweight polypropylene cone is reinforced with strong carbon fibers so it'll keep its shape when you're pushing the speaker hard. You'll hear accurate midrange and bass reproduction, while the 1" aluminum dome tweeter makes the high frequencies sparkle. These speakers will handle up to 75 watts RMS so you'll want to use an outboard amplifier to get the most out of them.
Signature Rockford Fosgate design
Proprietary VAST™ technology increases the woofer's cone area without increasing the size of the basket. This larger cone gives you deeper lows and more power handling, and it's supported by a durable rubber surround that's designed to last a long time. Rockford Fosgate mounts the tweeter on an offset suspension system, minimizing any acoustic reflections from back of the tweeter and maximizing accuracy. And open slots on the frame make it easier to install these speakers if the factory holes are slightly off, especially in certain European imports.
- 2-way 6-1/2" speakers (pair)
- injection molded carbon fiber and polypropylene woofer
- Santoprene rubber surround
- 1" aluminum dome tweeter
- integrated concealed 12dB/octave crossover
- grilles included
- Vertical Attach Surround Technique (VAST™) increases cone area
- power range: 10-75 watts RMS (150 watts peak power)
- frequency response: 44-22,000 Hz
- sensitivity: 88 dB
- top-mount depth: 2-9/16"
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # T1650
What's in the box:
- 2 Two-way speakers
- 2 Grilles
- Eight 1-1/4" Allen head screws
- 3mm Allen head bit
- 8 Speed clips
- Installation/Operation manual (English/ French/ Spanish/ German/ Italian)
More details on the Rockford Fosgate T1650
Features & specs
|Speaker Size||6 1/2|
|Tweeter Design||1" Dome|
|Tweeter Composition||Treated Aluminum|
|Woofer Composition||Carbon Fiber filled IMPP|
|Woofer Surround||Santoprene Rubber|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||88|
|Sensitivity at 2.83 volts||91|
|Frequency Response||44 - 20k Hz|
|Minimum RMS Wattage||10|
|Maximum RMS Wattage||75|
|Peak Power Handling (Watts)||150|
|Top-mount Depth (Inches)||2 9/16|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||5 1/2|
|Mounting Height (Inches)||1.108|
Injection-Molded Woofers: The woofer cones are injection-molded carbon fiber filled polypropylene. This molding process assures a uniform cone thickness for superior linearity and clarity. It is also light weight and rigid for decreased distortion and improved bass response.
Klippel Verified: The Klippel distortion analyzer, a device that uses a laser and sophisticated software to do large-scale analysis of drivers in motion, lets Rockford Fosgate optimize the speaker's motor structure, voice coil alignment, and suspension to yield the best possible performance.
VAST Surround: The Vertical Attach Surround Technique (VAST) increases a speaker's effective radiating cone area without increasing the size of the basket.
FlexFit 2 Basket: The FlexFit 2 frame utilizes slots (where possible) instead of single screw sized holes; allowing slight adjustment of the speaker when mounted.
Size Classification Note: Some manufacturers, including Rockford Fosgate, call this size speaker a 6-1/2". Because it requires a larger cutout than a standard 6-1/2" speaker, Crutchfield has traditionally referred to this size woofer as a 6-3/4". Please refer to the Crutchfield Vehicle Selector to confirm fit in your vehicle.
Tweeters: Each speaker features a 1" treated aluminum dome tweeter mounted to an offset cantilever to eliminate frequency response anomalies due to acoustic reflection between the woofer cone and the rear of tweeter. The tweeters are angled so you can direct them toward the listening positions.
Speaker Terminals: These speakers have 0.25" wide positive (+) terminals and 0.187" wide negative (-) terminals, which are too large for the vehicle-specific speaker harnesses Crutchfield supplies for many vehicle applications. We recommend that a pack of assorted female quick slides (item number 120FQS10PK, sold separately) be purchased and spliced to the harnesses to adapt them to the speaker terminals.
