Sound Ordnance™ B-17

Bandpass enclosure with 12" subwoofer

Item # 777B17

Sound Ordnance designed the B-17 bandpass subwoofer to be the bass fortress in your vehicle's sound system.

Sound Ordnance designed the B-17 bandpass subwoofer to be the bass fortress in your vehicle's sound system.

Item # 777B17

About the Sound Ordnance™ B-17

Sound Ordnance designed the B-17 bandpass subwoofer to be the bass fortress in your vehicle's sound system. Its 12" polypropylene woofer is mounted inside a sturdy enclosure, between an airtight sealed chamber and a second chamber that boasts a generous slot port for massive air movement. This bandpass design increases speaker efficiency, for impressive bass firepower from a relatively small box. Best of all, you can watch the woofer swing into action behind the clear acrylic front window.

Sound Ordnance designed the B-17 bandpass subwoofer to be the bass fortress in your vehicle's sound system. Its 12" polypropylene woofer is mounted inside a sturdy enclosure, between an airtight sealed chamber and a second chamber that boasts a generous slot port for massive air movement. This bandpass design increases speaker efficiency, for impressive bass firepower from a relatively small box. Best of all, you can watch the woofer swing into action behind the clear acrylic front window.

The heavy-duty speaker terminals provide excellent connections, and the rugged black carpet cover with the Sound Ordnance logo lets your competition know you mean business. And you'll have extra peace of mind with Sound Ordnance's 3-year warranty behind your investment. Add a suitable amplifier, mount the system safely in your trunk or cargo area, and get ready for a bass barrage.

Need an amp for this sub? Check out this Crutchfield-approved bass package.

READ LESS

Product highlights:

  • bandpass enclosure with 12" polypropylene woofer
  • 5/8" medium-density fiberboard construction
  • black carpet covering
  • clear acrylic front window
  • 4-ohm impedance
  • recommended power: 50-250 watts RMS (500 watts peak power)
  • frequency response: 45-150 Hz
  • sensitivity: 89 dB
  • 15-5/8"W x 15-1/8"H x 15-1/4"D1 x 10-1/4"D2
  • warranty: 3 years
  • Our 60-day money-back guarantee
  • MFR # B-17

What's in the box:

  • Bandpass enclosure loaded with one 12" subwoofer
  • Owner's manual
  • Warranty information

Featured video:

Customer reviews

Loading reviews...

Sound Ordnance™ B-17 reviews

Average review:

114 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the Sound Ordnance™ B-17

Pat M.

Features & specs

General
Woofer Size (inches) 12
Speakers Per Box 1
Woofer Material Polypropylene
Enclosure Type Bandpass
Color Black
Pieces in System 1
Width (inches) 15-5/8
Height (inches) 15-1/8
Depth (inches) 15-1/4
Second Depth (inches) 10-1/4
Connector Type Spring post
Frequency Response 45-150 Hz
Power Range (Watts RMS) 250
Maximum Wattage 500
Sensitivity 89 dB
Impedance 4 ohms
Parts Warranty 3 Years
Labor Warranty 3 Years

Product Research

Features

Materials: The Sound Ordnance B-17 is a pre-loaded bandpass style enclosure with a single 12" subwoofer. It is constructed of 5/8" MDF (medium-density fiberboard), covered in black carpet. It also features a clear acrylic front window for viewing the subwoofer. The subwoofer features a polypropylene cone with rubber surround, a 2" voice coil, and a heavy-gauge stamped steel basket.

Box Design: The enclosure has a sealed chamber in front of the subwoofer, and a vented chamber behind. The front-firing slot port to the right of the sub is 1-1/4" wide and 14" high. The box has a total of 1.46 cubic feet of airspace.

Terminals: The B-17 is equipped with a single set of spring-post speaker terminals, mounted in the rear panel. The spring terminals will accept bare wire up to 10 gauge, pin connectors, and single banana plugs, but are spaced too far apart for dual banana plugs.

Brackets: Brackets for securing the enclosure to your vehicle are recommended.

Specifications:

  • Frequency Response: 45-150 Hz
  • Power Handling: Up to 250 watts RMS, 500 watts peak
  • Sensitivity: 89 dB
  • Dimensions:
    • Width: 15-5/8"
    • Height: 15-1/8"
    • Depth (bottom): 18-1/4"
    • Depth (top): 10-1/4"

Loading accessories...

Customer Q&A

4 questions already asked

Q
what wires do i need to buy to hook it up to a aux?
[ ben diver  May 06, 2020 ]
2 answers
A
Thanks for your question. For information on selecting the best amp for your subs I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences between the amp models and help you make the best choice for your system.
[ Calvin  May 27, 2020 ]  Staff
A
You'll want to hook this up to an amp, not aux to a device.
[ Michael  May 21, 2020 ]
Q
does this come with the needed wires to wire this up?
[ Tater  Sep 18, 2019 ]
5 answers
A
No wires come with it
[ Farida  Sep 30, 2019 ]
A
No you will need to buy the speaker wire to hook it up to amp
[ Danny  Sep 26, 2019 ]
A
The subwoofer comes already wired and mounted inside the box ready to rock. You will have to provide the wire from the amp to the sub box
[ JEROMY A  Sep 26, 2019 ]
A
Does not include wires for connecting to battery or ground. Bought my own wiring kit.
[ Cindy  Sep 25, 2019 ]
A
No you still red a amplifier to push this sub
[ Eric  Sep 25, 2019 ]
Q
How many amps of current does this sub draw?
[ James  Aug 29, 2017 ]
1 answer
A
my amp is only 100 watts. its about 15 amps. but I have 8 gauge wire on it, with a 50 amp fuse. because the speaker is in closed the bass is louder so you dont need a big amp.
[ dan  Aug 30, 2017 ]
Q
What amp would best go with this Sound Ordnance sub?
[ allen  Jan 05, 2014 ]
2 answers
A
The best match for this subwoofer would be the Sound Ordnance M2100. It would actually be a PERFECT match. Not only is it the same brand but the power bridged into a 4 ohm load would be spot on.
[ JEROMY A  Dec 17, 2017 ]
A
Thanks for your question. For information on comparing amps I would recommend reaching out to an Advisor by phone or online chat. They will be able to help determine the differences and help you make the best choice for your system and your budget.
[ Jeff  Jan 06, 2014 ]  Staff
