iDatalink KIT-C200 Dash and Wiring Kit

Install an iDatalink-ready stereo and retain the steering wheel audio controls and factory amp in select 2015-17 Chrysler 200 models

Item # 794KC200

Your Chrysler 200 is a great car, but the factory radio leaves something to be desired.

Find what Fits your car

Your Chrysler 200 is a great car, but the factory radio leaves something to be desired.

Item # 794KC200

Ships from distributor

In stock
C$174.99

About the iDatalink KIT-C200 Dash and Wiring Kit

iDatalink KIT-C200

Your Chrysler 200 is a great car, but the factory radio leaves something to be desired. The KIT-C200 dash and wiring kit allows you to install an iDatalink-ready car stereo in the dash panel, while maintaining your climate controls, USB port, backup camera, parking assist, and other features. You'll also need iDatalink's Maestro ADS-MRR module (not included) for this installation.

iDatalink KIT-C200

Your Chrysler 200 is a great car, but the factory radio leaves something to be desired. The KIT-C200 dash and wiring kit allows you to install an iDatalink-ready car stereo in the dash panel, while maintaining your climate controls, USB port, backup camera, parking assist, and other features. You'll also need iDatalink's Maestro ADS-MRR module (not included) for this installation.

Your Chrysler features

The included wiring harness lets you keep your factory amplifier's Premium Audio functions (if equipped), as well as your secondary display's functions including audio information, hands-free info display, and navigation information. Your new radio will also display gauge information, parking assist distance, and other vehicle information.

The harness allows you to keep your steering wheel audio controls. The kit includes metal brackets for radio installation, and includes a button bar panel to fill the gap left when you remove the Chrysler radio without the button bar.

READ LESS

Product highlights:

  • allows installation of new iDatalink-ready receiver in select Chrysler 200 vehicles
  • requires the Maestro ADS-MRR module (not included)
  • retains the use of your steering wheel audio controls, factory amp, backup cam, and USB port
  • retains your secondary display (with phone call, audio, and navigation information)
  • includes metal brackets for radio installation and blank button panel for use in vehicles without the factory button bar
  • displays engine performance and other data on new car stereo's touchscreen
  • warranty: 1 year
  • Our 60-day money-back guarantee
  • MFR # KIT-C200

What's in the box:

  • Dash-panel
  • Radio bracket
  • 2 ISO-brackets
  • Vehicle harness
  • USB adapter cable
  • OBDII harness
  • 4 Screws
  • Quick Start Guide

Customer reviews

Loading reviews...

iDatalink KIT-C200 Dash and Wiring Kit reviews

Average review:

5 reviews

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the iDatalink KIT-C200 Dash and Wiring Kit

Stacey B.

Product Research

Features

Vehicle Compatibility: The iDatalink Maestro KIT-C200 consists of an OEM integration dash kit and vehicle harness designed specifically for 2015-2017 Chrysler 200(s) with or without a factory amplified audio system. The KIT-C200 lets you replace the factory radio of your 2015-2017 Chrysler 200 with an iDatalink Serial Port compatible head unit using the Maestro RR Car Radio Replacement Interface module (794ADSMRR, sold separately).

Make Model Year
Chrysler 200 (with factory amplifier 2015-2017
200 (without factory amplifier) 2015-2017
Note: The iDatalink Maestro KIT-C200 requires the purchase of the iDatalink Maestro RR (794ADSMRR) and the download of a vehicle specific firmware from iDatalink's Weblink site using a Windows PC (not compatible with Mac).

OEM Grade Fit & Finish Kit: The KIT-C200 OEM integration kit features a factory grade fit & finish to match the contour and color of your vehicle's dash. It will fit a double-DIN (4") size aftermarket head unit.

Vehicle Harness: The iDatalink Maestro KIT-C200 includes a vehicle harness which inserts into the iDatalink Maestro RR interface module (sold separately), plugs into your vehicle's factory radio harness, and hardwires to the harness of your new aftermarket double-DIN receiver. The installation harness contains one large Molex connector which plugs into your vehicle's factory radio harness. On the other end of the harness are four multi-pin connectors which plug into the Maestro RR interface module (sold separately). The harness also includes a composite video connector which plugs into your aftermarket head unit's rear-panel camera input in order to retain your vehicle's factory backup camera. In addition, a USB adapter harness retains your vehicle's factory USB port through your aftermarket receiver's rear-panel USB port.

Retained Features: The follow factory features (if applicable) are retained when replacing your aftermarket head unit with a compatible iDatalink Serial Port head unit from Kenwood, JVC, Alpine, or Pioneer using the Maestro RR Car Radio Replacement Interface module and KIT-C200 installation kit.

  • Steering Wheel Controls (with two function capability)
  • Factory Amplifier (with fader control, DSP settings, and gain adjustment)
  • Backup Camera
  • Secondary Vehicle Display (with Hands-Free, Audio, and Navigation Info)

Extra Features: The follow extra features are retained when replacing your aftermarket head unit with a compatible iDatalink Serial Port head unit from Kenwood, JVC, Pioneer, or Alpine using the Maestro RR Car Radio Replacement Interface module and KIT-C200 installation kit.

  • Selectable Performance Gauges
  • Park Assist (with distant display on-screen & warning chimes)
  • Tire Pressure Display
  • Battery Voltage Display
  • Read/Reset Check Engine Codes
  • Door Open Status and Warning

Navigation Outputs: To make installing an aftermarket navigation receiver easier; the KIT-C200 provides Parking Brake, Foot Brake, Reverse Gear, & VSS (Vehicle Speed Sense) output wires.

Loading accessories...

Customer Q&A

Q
Crutchfield asked: Why did you buy this?
A
ONLY kit for my 2015 Chrysler 200. Crutchfield is my main choice for car audio! [ Zaire  Feb 06, 2019 ]
A
i got this new dash kit for my 200 thats gonna go good with my pioneer nex 2300 double din [ nick  Aug 17, 2018 ]

1 question already asked

Q
Does this require the maestro Idatalink or is it optional?
[ Alexis  Jul 11, 2019 ]
3 answers
A
It is not optional it is required!
[ Kimberly  Jul 12, 2019 ]
A
It's not required, but if you want your steering wheel controls , back up cam, and climate controls to work it's best you installed it. It's a very easy install
[ Franklin  Jul 11, 2019 ]
A
If you want to retain steering wheel controls and climate control, you need the Maestro Idatalink
[ Daniel  Jul 11, 2019 ]
