Disc Player: The
Marantz CD6006 Single Disc CD Player can play CD, CD-Text, CD-R, and CD-RW discs
(both 12cm and 8cm discs). The CD6006 supports MP3, WMA, WAV, and AAC audio files that have been
recorded onto CD-R or CD-RW discs in ISO9660 mode 1/2 or Juliet/Romeo disc format. The Marantz CD player will recognize up to
255 total files and folders on a single
disc. The unit will also display CD-Text, MP3-ID3, WMA, and AAC song/artist information.
Front-Panel USB Port: The CD player features a front-panel USB (type-A)
port. The front panel port is designed for USB mass storage class devices, such
as your Android smartphone/tablet or USB thumbdrive. The front-panel USB port is
compatible with FAT16/FAT32 file systems and will play MP3, WMA, AAC, and WAV
files. The CD6006 can support 700 folders and 65,535 files per folder. The unit
will also display MP3/WMA tag data information. The front-panel controls and
supplied wireless remote will operate basic playback functions of your connected
USB device. The 5V/1A USB port will also charge your device while
Compressed Music File Formats: The Marantz CD6006 supports the
following compressed music files on CD-R/RW discs and USB.
|File Format ||Sampling
Frequency ||Bit Rate ||Extension |
|MP3 ||32/44.1/48 kHz ||32-320 kbps ||.mp3 |
|WMA ||32/44.1/48 kHz ||32-192 kbps ||.wma |
|AAC ||32/44.1/48 kHz ||32-320 kbps ||.m4a |
(PCM) ||32/44.1/48 kHz ||16-bit ||.wav |
iPod/iPhone Direct: You can connect your iPod or iPhone to
the front-panel USB port using the Lightning or 30-pin cable supplied with your
Apple device (not included with this unit). Sound quality is maximized by using
the USB connection along with the CD6006's D/A converter. Playback can be
controlled using the front-panel or remote buttons, or the iPod/iPhone itself.
You can browse your iPod/iPhone's music library from the CD6006 by Album,
Artist, Genre, Playlist, or Track. The CD6006 will also display song/artist
information, as well as charge your iPod/iPhone. The unit is "Made for
iPod/iPhone" compliant and supports the following iPod/iPhone model features (as
| Apple Device || Generation || Tested Version || Media Type || Control Type || Display Type || Charge |
| Audio || Video || Unit/Remote || iPod/iPhone || Artist/Song Text || Track Info |
| iPhone || 2G || 3.1.3 || Y || N || Y || Y || Y || Y || Y |
| 3G || 4.2.1 || Y || N || Y || Y || Y || Y || Y |
| 3GS || 6.1.6 || Y || N || Y || Y || Y || Y || Y |
| 4 || 9.3.2 || Y || N || Y || Y || Y || Y || Y |
| 4S || 9.3.2 || Y || N || Y || Y || Y || Y || Y |
| 5/5C/5S || 9.3.2 || Y || N || Y || Y || Y || Y || Y |
| 6/6+/6S/6S+ || 9.3.2 || Y || N || Y || Y || Y || Y || Y |
| touch || 1st || 2.2.1 || Y || N || Y || Y || Y || Y || Y |
| 2nd || 4.2.1 || Y || N || Y || Y || Y || Y || Y |
| 3rd || 5.1.1 || Y || N || Y || Y || Y || Y || Y |
| 4th || 6.1.6 || Y || N || Y || Y || Y || Y || Y |
| 5th/6th || 9.3.2 || Y || N || Y || Y || Y || Y || Y |
| nano |
| 3rd || 1.1.3 || Y || N || Y || Y || Y || Y || Y |
| 4th || 1.0.4 || Y || N || Y || Y || Y || Y || Y |
| 5th || 1.0.2 || Y || N || Y || Y || Y || Y || Y |
| 6th || 1.2 PC || Y || N || Y || Y || Y || Y || Y |
| 7th || 1.02PC || Y || N || Y || Y || Y || Y || Y |
| classic || 80GB || 1.1.2 || Y || N || Y || Y || Y || Y || Y |
| 120GB || 2.0.1 || Y || N || Y || Y || Y || Y || Y |
| 160GB || 2.0.4 || Y || N || Y || Y || Y || Y || Y |
| iPad || 1 || 5.1.1 || Y || N || Y || Y || Y || Y || N |
| 2/3 || 9.3.2 || Y || N || Y || Y || Y || Y || N |
| 4 || 9.3.2 || Y || N || Y || Y || Y || Y || N |
| Air 1/2 || 9.3.2 || Y || N || Y || Y || Y || Y || N |
| mini 1/2/3/4 || 9.3.2 || Y || N || Y || Y || Y || Y || Y |
Note: Apple iPod/iPhone software updates may change
functionality results. If you download a newer software version, you may
need to reset the head unit and your iPod/iPhone to regain functionality. If
this doesn't work, you may need to wait until a newer software update is
Marantz HDAM + HDAM SA2 Technology: Ordinary CD players employ conventional
IC-based op-amps in the D/A and analog output sections, but the CD6006 is
equipped with Marantz exclusive HDAM & HDAM SA2 technology, which uses discrete circuit
elements and not ICs. HDAM technology provides wide dynamic range and wide
frequency response along with lowest distortion for the utmost musical fidelity
High Current Power Supply: For the most stable power to the various
circuit blocks, the power supply employs high speed, high current Shottky
Barrier Diodes in the AC-DC conversion circuit, and the power supply is fitted
with high current storage capacitors for the most stable DC supply to the
mechanical and electrical sections.
Reference Quality D/A Conversion: The CD6006 features high resolution
D/A conversion and is equipped with the reference class CS4398 D/A converter,
which provides up to 192kHz/24-bit resolution for optimum fidelity with high
resolution audio file types. To prevent interference with the critical analog
audio output circuitry, the digital audio circuit block is housed in its own
Precision System Clock: The CD6006 employs a precision
system clock to virtually eliminate any jitter for distortion-free music that
sounds like the artist intended.
Fully Discrete Headphone Amplifier: The all discrete headphone
amplifier section features Marantz's HDAM-SA2 circuit with three gain settings
(Low/Mid/High) for a wider range of headphones, plus independent volume control.
The gold-plated 1/4" jack is compatible with audiophile and studio headphone
types and adapters.
Audio EX Function: For improved analog audio output fidelity, the
Audio EX function lets you disable the front-panel fluorescent display, to
minimize noise artifacts. You can also disable the digital audio outputs when
listening via analog audio for even greater noise reduction.
Gold Plated Analog & Digital Outputs: The analog audio RCA outputs,
along with the digital coaxial output connector, are all gold plated to ensure
optimum signal transfer with no degradation.
- Analog RCA Outputs: The CD player also features a stereo RCA
output for analog connection.
- Optical/Coaxial Digital Outputs: For optimum compatibility with
digital audio amplifiers and decoders the CD6006 is equipped with both
optical and coaxial digital audio outputs (supports 2ch PCM only).
Rigid Chassis Design: The CD6006 CD player's front-panel is
constructed from aluminum and glass-reinforced resin, which resists harmful
resonances that can harm sonic quality. The panel is finished in a soft black
tone, and features a graceful curvature that complements any home décor. The CD
player also employs a double layered bottom plate to prevent unwanted resonance
that could lead to distortion.
Two-Line Florescent Display: For optimum visual clarity, the CD6006
features a deluxe two-line fluorescent display that features alphanumeric
characters (up to 16) for song/artist information from CD-Text discs and
MP3/WMA/AAC music tracks. The display is dimmable.
Remote Control: The supplied IR remote control features an easy to use
ergonomic design, and can control the CD6006 as well as control the matching
PM6006 integrated stereo amplifier (sold separately). The remote can also be
used to control your USB-connected iPod or iPhone. The CD player also includes a
Remote Input/Output and Flasher Input.
- Remote Input/Output: Two RCA jacks
(1 In/1 Out) are provided for connecting the player and another Marantz
A/V component for system remote control purposes. The accompanying switch allows
you to select the remote control mode you desire: External (when the player is
connected to another component's remote control jacks) or Internal (when the
player is used as a standalone component).
- Flasher In: This 3.5mm minijack input is used to control this unit
using an optional keypad (sold separately) from another room of your house.
Playback Functions: The Marantz CD player offers basic
playback functions like Play/Pause, Stop, Fast Forward/Rewind, and
Random/Repeat. It also has variety of unique playback functions like Direct
Search, Program Play, Quick Replay, Time Player, and A-B Repeat.
- Direct Search: You can use the numeric keypad on the remote control to select a specific music
- Program Play: You can arrange and play tracks on a disc in a
specific sequence. Up to 25 tracks can be programmed. As you are selecting
tracks, the display will show the number of tracks in the program, and the total
playing time of the programmed tracks. During program play, you can repeat the
entire list of programmed tracks, or play them in random order.
- Quick Replay: During Quick Replay, the music track or file
rewinds the set amount of time (5-60 seconds), and then resumes playing from
the rewind point.
- A-B Repeat: You can specify the section within a track that you
want to hear, and play it back repeatedly.
- Timer Play: When this CD player is connected to a commercially
available external audio timer (sold separately), the unit's power is switched
on and media playback starts at the specified time.
Auto Standby: With Auto Standby On, you can automatically
set this unit to standby mode after the CD player is in stop-mode (no operation)
continuously for approximately 30 minutes.
