About the Hertz CS 300 S2
Designed to fit
Designed to fit
With over two decades of experience, Hertz knows how to build great-sounding car audio gear, and their speakers, subs, and amps get raves from our customers. They designed the CS 300 S2 shallow-mount 12" subwoofer to get powerful bass from a very small enclosure, and its 4-1/2" mounting depth allows installation in the smaller spaces of today's cars.
Tough enough
The CS 300 S2 subwoofer features a rugged polypropylene cone that punches out deep, rich bass, while minimizing distortion. The sub handles up to 350 watts RMS, and its 2-ohm impedance makes it a great match for a mono sub amp. Push terminals accept up to 8-gauge speaker wire so you can maximize the signal delivered to the speaker.
Minimal clearance needed
This sub is designed to mount close to the back wall of your enclosure and requires very little clearance in front. It's optimized for enclosures as small as 1.13 cubic feet, so it will tuck into a corner of the trunk or under the rear seat of many trucks. A tough PVC gasket lets you install Hertz' CG 300 speaker grille (sold separately) for extra speaker protection and a clean, finished look.
For big bass in a small space, the CS 300 S2 is engineered to excel. You'll get the thump you're looking for in a rugged subwoofer that'll vanish in the corners of your vehicle.
Subwoofer Wiring Diagrams
To see sample wiring diagrams for all common subwoofer/amplifier combinations, check out this informative article.
Product highlights:
- 12" 2-ohm shallow-mount subwoofer
- polypropylene cone
- power handling: 350 watts RMS (700 watts peak)
- sensitivity: 86.5 dB
- top-mount depth: 5-1/8"
- push terminals handle up to 8-gauge wire
- sealed box volume: 1.13 cubic feet
- grille sold separately
- warranty: 1 year
- MFR # CS 300 S2
What's in the box:
Hertz CS 300 S2 owner's manual
- One 12" Single 2-ohm voice coil subwoofer
- Trim ring
- Eight 1-1/2" Screws
- 8 Speed clips
- Owner's manual (English/ Spanish/ French/ German/ Italian/ Portuguese/ 28 Others)
- Template on the box
Customer reviews for Hertz CS 300 S2
Loading reviews...
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Hertz CS 300 S2
Features & specs
| Features and Specs | ||
|---|---|---|
| Size | 12 -inch | |
| Impedance (Ohms) | 2 | |
| Cone Material | Polypropylene | |
| Surround Material | Rubber | |
| Port diameter (inches) | N/A | |
| Port length (inches) | N/A | |
| Free-Air | No | |
| Dual Voice Coil | No | |
| Sensitivity |
86.5 dB at 1 watt | |
| Frequency Response | --- | |
| Max RMS Power Handling | 350 | |
| Peak Power Handling (Watts) | 700 | |
| Top Mount Depth (inches) | 5 1/4 | |
| Bottom Mount Depth (inches) | 5 15/16 | |
| Cutout Diameter or Length (inches) | 11 1/16 | |
| Vas (liters) | 87.25 | |
| Fs (Hz) | 25 | |
| Qts | 0.46 | |
| Xmax (millimeters) | 12.5 | |
| Parts Warranty | 2 Years | |
| Labor Warranty | 2 Years | |
| Box Requirements | ||
| Ideal Sealed Box Volume (cubic feet) | 1.13 | |
| Minimum Sealed Box Volume (cubic feet) | N/A | |
| Maximum Sealed Box Volume (cubic feet) | N/A | |
| Ideal Ported Box Volume (cubic feet) | N/A | |
| Minimum Ported Box Volume (cubic feet) | N/A | |
| Maximum Ported Box Volume (cubic feet) | N/A | |
Product Research
Features
Terminals: The spring post terminals will accept pin connectors, single banana plugs (but not dual), and bare wire up to 8 gauge.
Klippel Verified: The Klippel distortion analyzer, a device that uses a laser and computer software to do large-scale analysis of drivers in motion, helps Hertz optimize the speaker's motor structure, voice coil alignment, and suspension to yield the best possible performance.
Sealed Box: Hertz recommends a sealed enclosure volume of 32 liters (1.13 ft³). Sealed enclosures provide the most control over a woofer, will handle a lot of power, and provide accurate sonic reproduction, making them suitable for all types of music.
Crossover: Hertz recommends a low pass crossover point of 60 Hz - 70 Hz and a subsonic filter at 15 Hz. A 24 dB/octave slope is recommended for both.
