Built-in Bluetooth
Android & iPhone Integration
Internet+SiriusXM+AM/FM Radio
USB/Aux Playback
Audio Section
Remote Control
Display Features

Built-in Bluetooth

Bluetooth 3.0: The MVH-X690BS is equipped with built-in Bluetooth 3.0, allowing you to make and receive phone calls wirelessly through the receiver; as well as stream music wirelessly from your smartphone to the head unit.  In order to use Bluetooth wireless technology, your phone must also be Bluetooth compatible and be able to interpret certain profiles. This unit is compatible with the following Bluetooth Profiles -

• Hands-Free Communication: HFP 1.6 (Hands Free Profile), OPP 1.1 (Object Push Profile), PBAB 1.0 (Phone Book Access Profile).
• Audio Streaming: A2DP 1.3 (Advanced Audio Distribution Profile), AVRCP 1.5 (Audio/Video Remote Control Profile).

Multi-Device Pairing w/ Dual Phone Connection: Up to three Bluetooth-compatible devices can be paired to this receiver. You are even able to keep two Bluetooth-enabled phones connected at the same time, so you can make and receive calls from either phone through the head unit. You can only stream music from one phone at a time; you will be able switch between the two phones in the head unit's menu. Additional pairing features include -

• SSP (Simple Secure Pairing: With Secure Simple Pairing (SSP), you can easily pair a Bluetooth enabled phone to the MVH-X690BS without having to enter pin codes or go through complicated settings (your phone must also support SSP).
• USB Pairing for iPhone: You can also pair your Apple iPhone (iOS 5.0+) by simply connecting it to the Pioneer head unit via USB and following a single prompt on the head unit's display.
• Guest Mode: "Guest Mode" allows you to add and replace a third mobile device instantly to the receiver; Guest Mode is a great feature for a family vehicle with multiple drivers or a driver with multiple devices because it allows users to pair and delete devices easily without a lengthy registration or deletion process.

Hands-Free Communication (w/ External Mic): The MVH-X690BS supports wireless hands-free communication (HFP/PBAB) for your Bluetooth enabled mobile phone. And, thanks to the latest Hands-Free Profile (HFP 1.6) with wideband speech capability, the MVH-X690BS provides more natural sound quality and details during wireless calls. The MVH-X690BS allows you to carry on a phone conversation from your Bluetooth enabled mobile phone using the head unit's external microphone and your car audio speakers. During a conversation you can adjust the volume, as well as switch between the Private Mode (talking directly on your cell phone) and the Hands Free Mode.

• Answering A Call: During an incoming call, the head unit will display the caller's information and an audible ring tone will be heard through your vehicle's speaker. You can manually answer an incoming call or have the unit automatically answer the call.
• Making A Call: Using the MVH-X690BS, you can dial a phone number in one of the following ways -
  • Phone Book: The phone book in your Bluetooth enabled cellular phone will be transferred automatically when the phone is paired to this unit. After finding the number you want to call in the phone book from the head unit, you can select the entry and make the call. If a lot of numbers are registered in the phone book, you can search for a phone number by the contact person's name alphabetically.
  • Presets: You can easily store up to six phone numbers as presets for speed dialing.
  • Call Log: The most recent calls dialed, received, and missed are stored in memory. You can browse them and call numbers from these lists.
  • Voice Dialing (Siri & Google Voice): When paired and connected with an iPhone 4S or later via Bluetooth, the Pioneer head unit has the ability to access Siri through its front-panel controls and external microphone. It also supports Google Voice for select Android smartphones (not compatible with Samsung "S Voice"). You'll be able to dial a phone number or contact via voice command.

Wireless Audio Streaming: The Pioneer MVH-X690BS also supports wireless audio playback (AD2P) and control (AVRCP) of a Bluetooth enabled audio player or smartphone. The head unit can stream music stored on your Bluetooth enabled device or music apps you have downloaded on your device. When an incoming call or outgoing call is in progress from your Bluetooth enabled mobile phone, audio streaming will be paused so you can take your call.

• Music Control: In addition to basic playback functions (Play/Pause, FF/RW, Skip, Random/Repeat), the MVH-X690BS lets you browse your stored music by Playlist, Artist, Album, Song, etc. (AVRCP 1.4 phones only; which includes Android 4.0+ and iPhone 5.0+).
• Song/Artist Info: The head unit will also display song/album/artist information from your Bluetooth device's stored music and select music apps on your device.

Siri Eyes-Free Control: When paired and connected to an iPhone with Siri via Bluetooth, the Pioneer MVH-X690BS has the ability to access Siri through its front-panel controls and external microphone. Simply press and hold head unit's phone key to engage Siri and use the included microphone to communicate with Siri. Siri's voice will heard through your vehicle's speakers. All Siri functions including hands-free calling, music search, setting reminders, text-messaging, audible navigation, and more can be done through the MVH-X690BS and its microphone. You can even ask Siri to get directions to a destination and the turn-by-turn instructions will heard through your vehicle's speakers, while the on-screen map still displays on your iPhone with Siri. The head unit's audio is attenuated while Siri provides audible directions.

Android & iPhone Integration

Android Direct Connect via USB: The Pioneer MVH-X690BS enables playback of stored music and music apps on select Android devices through its front-panel USB port. There are two types of modes to choose from based on your type of Android smartphone and what content you want to listen to.

• AOA 2.0 (Stored Music & Music Apps): The Pioneer MVH-X690BS supports Android Open Accessory 2.0 (AOA 2.0), which lets  you connect your Android smartphone (OS 4.1+) to the MVH-X690BS's front-panel USB port and listen to stored music and select music apps from your Android device through the Pioneer receiver. You'll be able to control basic playback functions such as Play/Pause and Previous/Next Track. Other advanced music navigation will still be done from your Android smartphone's touchscreen. In this mode, the head unit will not display song/artist information; you'll continue to view song/artist information from the Android device's touchscreen. You'll still be able to access other functions and applications from your Android smartphone's touchscreen, while listening to music through the head unit. If you make a call or answer a call from your smartphone while listening to music in this mode, the music will pause until you are finished with the call and then start back up again.
• MTP (Stored Music + Song/Artist Info): The MVH-X690BS also supports MTP for playback & control of stored MP3/WMA music files on your Android (OS 4.0+) device through the Pioneer receiver's front-panel USB port. In this mode, you get basic playback control (like Play/Pause & Previous/Next Track), plus song/artist information on the receiver's LCD screen. During MTP connection, you cannot use your Android smartphone's touchscreen to control music playback and you cannot select music apps from your smartphone for playback. However, you can continue to listen to stored music on your Android smartphone through the head unit while you check your Calendar, Facebook, Texts, etc on your phone.

iPod Direct Connect via USB: The Pioneer MVH-X690BS supports audio playback of stored music & music apps on your Apple iPod/iPhone, along with control and song/artist information display through its front-panel USB port. If you have a newer iPod/iPhone with the Lightning-connector, you can use Pioneer's Lightning-to-USB cable (130CDIU52, sold separately) or the Lightning-to-USB cable that came with your Apple device to connect your iPod/iPhone to the MVH-X690BS. If you have an older iPod/iPhone with a 30-pin dock connector, you can use the dock connector-to-USB cable that comes with your Apple device or a 3rd party dock connector-to-USB cable (sold separately) to connect your iPod/iPhone to the MVH-X690BS. Control modes include -

• Head Unit Mode: From the head unit, you can browse your iPod/iPhone's music library by Artist, Album, Song, Genre, Playlist, Composer, Podcast, or Audiobook. Once you have selected a category, you can search each category alphabetically. In addition, the head unit offers Link Play, which allows you to play songs related to the currently playing song. Link Play lets the head unit create an album list of the currently playing artist, a song list of the currently playing album, or an album list of the currently playing genre. You can also select Random & Repeat functions for a certain song or specific folder. The head unit will display your iPod/iPhone's stored music file information; including Track number, Elapsed playing time, and Song/Artist/Album name. Apple devices w/ iOS 6.0+ will stay unlocked, so you can access music apps; other iPod/iPhone device's clickwheel or touchscreen will be locked during this mode.
• iPod/iPhone Mode: In iPod/iPhone mode, you can navigate the stored music on your iPod/iPhone from its clickwheel or touchscreen, while still being able to view song/artist information and control basic playback functions from the head unit. You will not be able to browse your iPod/iPhone's music by category from the head unit or use Link Play in this mode.
• App Mode: App mode lets you listen to your favorite music apps from your iPhone (iOS 5.0+) through the Pioneer head unit and your vehicle's speakers. Once you have selected the music app from your iPhone, you'll be able to listen to music from that app through the Pioneer head unit, view song/artist information on the head unit's LCD, and operate basic playback functions such as Play/Pause and Previous/Next Track from the head unit's front-panel control. Not all apps will be compatible with App Mode.

Apple Device Compatibility Chart: The Pioneer MVH-X690BS is "Made for iPod/iPhone" compatible and supports the following iPod/iPhone model functions (as of 9/14/2016):

Mobile Device Charging: The head unit's USB connection provides 1.5A of current to power and charge your connected Android smartphone or Apple iPod/iPhone when your vehicle's ignition switch is set to the 'ACC' or 'On' position (if your mobile device has no initial battery charge, then the unit will not recognize it).

USB Auto Function: The receiver's "USB Auto" function can be set to ON to enable the head unit to automatically switch to the USB source for playback when a USB-enabled device is connected. If set to OFF, the receiver will not switch sources and simply charge the connected USB device.

Internet+SiriusXM+AM/FM Radio

Pandora Internet Radio: The free Pandora App (either from the Apple App Store or Google Play) lets you play music from the Pandora music service through the Pioneer MVH-X690BS using your USB-connected Apple iPhone (iOS 7.0+) or Bluetooth paired Android smartphone. Your Apple iPhone must be connected to the MVH-X690BS via the CD-IU52 Pioneer iPod connector cable or the connector-cable that came with your iPhone. Your Android smartphone must support A2DP/AVRCP/SPP Bluetooth profiles and be paired with the Pioneer receiver. Your iPhone or Android smartphone will also need an active Data Plan account with connection to the Internet via 3G, EDGE, or WiFi. The unit provides control over the Pandora music service and displays Artist, Album, and Song information.

• Station List: You can select Pandora stations from your Station List by date or alphabetically (A-Z).
• Shuffle Station List: You can listen to songs played randomly from various stations within your Station List.
• New Stations + Delete: New stations can be created based on the current songs or artists playing. You can also delete a station from your Pandora station list.
• Skip Songs: You can skip song tracks within a station. You cannot skip back to a previous song. Pandora limits the number of skips allowed.
• Thumbs Up/Down: You can give songs a thumbs up or thumbs down to help Pandora personalize stations to suit your preferences.
• Bookmarking: The song/artist currently being played can be bookmarked & stored in your Pandora account.

Spotify Online Music Service: The Pioneer MVH-X690BS has the ability to playback & control content from the Spotify music app on your USB-connected iPhone (iOS 7.0+) device or Bluetooth-paired Android smartphone. You can play, pause and skip tracks, browse playlists, albums and radio stations through the Pioneer receiver's front-panel controls. You also get song/artist information on the unit's front-panel LCD. Access to the Spotify service will depend on the availability of a cellular and/or WiFi network for purposes of allowing your iPhone or Android device to connect to the Internet. If you are a Spotify Premium user (requires a monthly paid subscription), you can enjoy ad-free, high quality music even when there is no internet connection.

SiriusXM Ready: The Pioneer digital media receiver is SiriusXM 3.0 Ready, so you can listen to commercial-free music, all your favorite sports, exclusive talk and entertainment, comedy, news, traffic, weather, and more. Simply connect the SiriusXM Connect Vehicle Tuner (20SXV300, sold separately) to the dedicated SiriusXM port on the rear of the head unit and enjoy satellite radio without additional translators or cables. With the SiriusXM Connect tuner you'll have access to more than 175 channels of exclusive programming directly from SiriusXM; check out the most popular SiriusXM subscription packages here. Additional features include:

• Channel List + Song/Artist Info Category Lists: The Channel List displays a list of all available channels. Displayed Information such as Channel Name, Artist Name, & Song Title can be viewed on the head unit's LCD.
• Category Lists & Scan: The Category List displays all available categories and stations within those categories. During Category Scan, the live broadcast for each channel in the current category plays for six seconds at a time.
• Instant Replay: The SiriusXM Instant Replay function lets you pause, rewind, and replay up to 60 minutes of live content from the station that you are currently listening to.
• Presets: You can store up to 18 SiriusXM Satellite Radio Station Presets with special tuning features; such as TuneStart, TuneScan, & TuneMix.
  • TuneStart: TuneStart automatically start songs from the beginning when you tune to one of your preset music channels stored on the current band of presets.
  • TuneScan: TuneScan lets you scan through short previews of songs you may have missed on music channels stored on the current band of presets.
  • TuneMix: Create a music channel that's a blend of songs made up from the music channels stored on the current band of presets.
• Parental Control: The SiriusXM Parental Control feature allows you to control access to channels that you consider inappropriate for younger listeners. When enabled, The Parental Control feature requires you to enter a 4-digit passcode to tune to the locked channels.

Supertuner IIID AM/FM Tuner: The Supertuner IIID features Feed Forward Control, which avoids multi-path interference. This pre-detection of interference enables quick filter control and results in less distortion. In addition, the Supertuner IIID creates enhanced stereo during multi-path interference, unlike conventional tuners that collapse to mono. Digital processing reduces distortion, and improves Signal-to-Noise Ratio and stereo separation. Advanced analog technology improves signal processing sensitivity.

• RDS: The Radio Data System (RDS) feature displays radio broadcast information such as artist, title, and album when listening to compatible AM/FM stations.
• BSM (Best Stations Memory): The BSM (Best Stations Memory) function lets you automatically store the six strongest stations under preset buttons 1-6 of the currently tuned band. The tuner has 3 FM banks and 1 AM bank. You can store 6 presets for each bank giving you a total of 18 FM presets and 6 AM presets.
• Local Tuning: Local seek tuning lets you tune in only those radio stations with sufficiently strong signals for good reception. There are 4 levels of sensitivity for FM and two levels for AM. The higher settings allow reception of only the strongest stations, while lower settings let you receive progressively weaker stations.

USB/Aux Playback

USB Mass Storage Class Device: In addition to Apple and Android device connectivity, the digitial media receiver's front-panel USB-A 2.0 port allows you to connect a USB Mass Storage Class (MSC) device, such as a USB thumbdrive or flashdrive (up to 32GB). The USB port enables audio playback & control of MP3, WMA, AAC, FLAC, and WAV audio files stored on your portable USB MSC device through the Pioneer MVH-X690BS. Basic playback controls included Play/Pause, FW/RW, Previous/Next Track, and Random/Repeat. Song/artist information such as track, artist, and album name will also be displayed on the head unit.

Audio File Compatibility: The Pioneer MVH-X690BS supports the following types of MP3, WMA, AAC, & WAV files loaded onto a USB MSC device.

File/Track Name List: The Name List feature displays a list of MP3, WMA, AAC, FLAC albums and tracks on a connected USB device, so you can easily access your music. Music files are listed first by Artist name, then by Album name, and finally by Song title.

Song/Artist Information: During MP3, WMA, AAC, or FLAC playback, the unit displays any recorded ID3 Tag (ver. 1.x/2.x) and WMA/AAC/FLAC Tag information; including artist, song, and album name.

Playback Controls: The Pioneer digitial media receiver provides basic operations like Play/Pause, Fast Forward/Rewind, Previous/Next Track, and Repeat/Random for USB device playback.

Auxiliary Input: The MVH-X690BS is equipped with a front-panel 3.5mm stereo minijack auxiliary input for connecting external audio sources, such as a portable digital audio player.

Audio Section

24 Bit D/A Converter: The Pioneer in-dash head unit utilizes a 24-bit digital to analog converter for superior sound quality.

MOSFET Amplifier: The MVH-X690BS is equipped with a MOSFET amplifier. Compared to conventional power supplies, the MOSFET amplification circuit is smaller and more efficient, and it delivers increased power with less distortion and absolutely zero on/off switching noise. More power means louder and cleaner music at higher volumes because you're not pushing the limits of the amplification circuit.

• CEA2006 Specs: 14 watts RMS x 4 channels (at 4 ohms, 20Hz-20kHz, 1% THD-N)
• Continuous Power Output: 22 watts RMS x 4 channels (at 4 ohms, 50Hz-15kHz, 5% THD)
• Maximum Power Output: 50 watts x 4 channels

2V/6CH Preamp Outputs + Sub Control: The Pioneer MVH-X690BS features three pair of 2.0-volt preamp outputs (Front/Rear/Subwoofer). The unit's front and rear preamp output can be faded (front/rear), while the subwoofer preamp output is non-fading. The Pioneer DEH-X6800BS lets you adjust the subwoofer preamp output's phase (normal/reverse) and volume (+10 to -24).

Crossovers: The MVH-X690BS employs high-pass and low-pass crossovers to tailor the head unit to your connected speaker setup.

• Standard: Allows you to set the high-pass and low-pass crossover network for a standard Front, Rear, and Subwoofer speaker setup using either speaker-level or low-level outputs.
  • HPF: The head unit's -6 to -24dB/octave high pass filter only allows frequencies higher than those in the selected range (50, 63, 80, 100, 125, 160, 200Hz) to your front and rear speakers through the unit's speaker-level or line-level outputs.
  • LPF: The subwoofer preamp output features an -6 to -24dB/octave low pass filter so only frequencies lower than those in the selected range (50, 63, 80, 100, 125, 160, 200Hz) are output to your connected subwoofer.
• Network: Allows you to set the high-pass and low-pass crossover network for a complex 3-way speaker system with Highs, Mids, and Sub using low-level outputs only.
  • Highs: The high-pass crossover for your tweeters can be set to 1.25, 1.6, 2, 2.5, 3.15, 4, 5, 6.3, 8, 10, or 12.5 kHz with a -6 to -36dB/octave roll-off.
  • Mids: You can set a high-pass and low-pass crossover from your midrange/midbass drivers. The high-pass crossover can be set to 1.25, 1.6, 2, 2.5, 3.15, 4, 5, 6.3, 8, 10, or 12.5 kHz with a -6 to -36dB/octave roll-off. The low-pass crossover can be set to 26, 31.5, 40, 50, 63, 80, 100, 125, 160, 200, or 250 Hz with a -6 to -36dB/octave roll-off.
  • Lows: The low-pass crossover for your subwoofers can be set to 26, 31.5, 40, 50, 63, 80, 100, 125, 160, 200, or 250 Hz with a -6 to -36dB/octave roll-off.

EEQ (Easy EQ) w/ 13-Band Graphic EQ: There are seven stored equalizer curves which you can easily recall at any time. You can choose from - Powerful, Natural, Vocal, Super Bass, Flat, Custom 1, or Custom 2. The Custom 1 and Custom 2 EQ modes allow you to manually adjust the level (+/- 12dB) of each band of the head unit's 13-band graphic equalizer (50, 80, 125, 200, 315, 500, 800, 1.25k, 2k, 3.15k, 5k, 8k, and 12.5k Hz).

Advanced Sound Retriever: The Advanced Sound Retriever automatically enhances compressed audio and restores the original richness of the recording. Hear the detail, warmth, and clarity, the way the artist intended it, from all of your highly compressed MP3 and WMA files stored on your USB, iPod/iPhone, Android, devices. By restoring data (especially higher frequencies) that tends to get lost in the digital compression process, Pioneer's Advanced Sound Retriever technology enhances audio reproduction nearly all the way up to 20 kHz frequencies.

Listening Position & Time Alignment: For a better sound-stage you can select your optimal listening position. You can choose from All, Front Left, Front Right, or Front. You can also select to manually fine tune the sound stage, using Digital Time Alignment (DTA) by selecting the distance (0-140") for each individual speaker in the vehicle compared to your listening position.

Audio Level Settings: The Pioneer MVH-X690BS digitial media receiver offers a variety of audio settings to tailor the bass, treble, and volume level to your preference.

• Bass Boost The MVH-X690BS features a bass boost function which can be used to enhance low-frequency bass sound. The bass boost function can be set between 0-6.
• Loudness: The Loudness feature compensates for deficiencies in the low and high sound ranges at low volume. You can set the Loudness feature to Low, Mid, High, or Off.
• Speaker Level: You can adjust each speaker and sub channel independently from +10 to -24 to best even out the sound in your vehicle.
• Source Level Adjustment (SLA): This function lets you adjust the volume level of each source to prevent radical changes in volume when switching between sources. Settings are based on the volume level of the FM tuner, which remains unchanged. Each source can be independently adjusted from -4dB to +4dB.
• Auto Level: This function automatically corrects the audio level difference between the music files and/or the sources.

Rear Speaker Setup: The rear speaker outputs can be set to provide full range output with full fading capability, or they can be set to provide non-fading subwoofer (low-pass) output. When the rear speaker outputs are set to subwoofer mode, the rear preamp outputs also switch from full range to subwoofer outputs. When set for subwoofer operation, you can connect the rear speaker leads directly to two small 4-ohm passive subwoofers or a dual voice coil sub with 4-ohm voice coils. If you prefer to use a single 2-ohm subwoofer, you can connect the woofer to one set of speaker leads, leaving the other set of rear leads disconnected. The maximum output provided when a 2-ohm load is connected to one set of leads is 70 watts.

MIXTRAX: Drawing from Pioneer's rich DJ heritage and passion for music, MIXTRAX delivers a unique DJ infused listening experience to listeners in the car. MIXTRAX is an innovative Pioneer technology that creates a non-stop mix of your music library complete with a range of DJ-inspired effects. MIXTRAX takes your typical music listening experience and creates a non-stop mix of your music with 3 random DJ effects and transitions, by removing the breaks and pauses normally introduced between tracks and replacing them with various beats. MIXTRAX is compatible with USB-connected iPod/iPhone, USB MSC device, and select Android devices. There is also a Short Playback option which limits the amount of time each track plays; select from 1, 1.5, 2, 2.5, or 3 minutes.

Remote Control

Advanced Remote Control App (for Apple iOS & Android): Download the Pioneer ARC (Advanced Remote Control) App onto your Apple iOS (8.0+) or Android (4.1+) device to turn your smartphone or tablet device into a remote control for the Pioneer head unit. Your Apple iOS device can be connected via USB or Bluetooth, while your Android device can only be connected via USB. The following control features are available via the Pioneer Advanced Remote Control App.

• Source Selection: From the app on your Apple iOS or Android device, you can select between the head unit's sources for playback. Choose AM/FM tuner, Aux, or the music library on your device.
• Playback Functions: The app offers basic playback functions like Play/Pause, Previous/Next Track, and Random/Repeat for your mobile device's music library. You are also able to browse your Apple iOS or Android device's music library by Artist, Album, Song, Genre, or Playlist. For AM/FM tuner, you are able to seek stations, switch AM/FM bands, and select presets from the Pioneer ARC app.
• Song/Artist Info + Album Art: The Pioneer Advanced Remote Control App provides song/artist information with album art for the music stored on your Apple iOS or Android device. You also get station identification for AM/FM radio; if an AM/FM station supports RDS, you will even get song/artist info.
• Favorites: The app lets you quickly display radio stations saved as favorites, plus favorite songs in your Apple iOS or Android device's music library. From the Favorite screen, you also get access to contacts saved as "favorites" on your smartphone.
• Select Apps: From the Pioneer ARC app, you can also pick from select music apps (like Pandora, iHeart, Spotify, TuneIn) that are installed on your Apple iOS or Android device. Once you select a specific music app, that particular music app opens on your mobile device for playback control.

Wireless Remote Control: The MVH-X690BS comes with an IR wireless remote control. The remote allows you to control the volume, switch between sources, pause playback, skip music tracks, change display info, and answer/end Bluetooth phone call. You can also mute the volume (function that cannot be performed from the front panel).

Steering Wheel Remote Compatibility: The head unit features an OEM steering wheel remote control input on the rear of the unit that lets you keep your vehicle's factory radio steering wheel remote controls when used with an optional steering wheel audio control adapter (sold separately).

Display Features

Color Customization: Color Customization lets you match the receiver's illumination to your vehicle's interior lighting. Over 210,000 colors are available to match the illumination of almost any car. The display & button illumination colors can be customized separately for an endless number of color combinations. You can select from 12 preset colors, customize an illumination color (by adjusting Red/Blue/Green brightness levels), or scan through a variety of colors.

Brightness & Dimmer Control: You can manually adjust the brightness (1-10) of the head unit's display & button illumination to suit your viewing needs. You can also sync the receiver's display & button illumination to the head units' clock or your vehicle's headlights. To dim the receiver's display & button illumination automatically when the vehicle's headlights are turned on, you'll need to hardwire the orange/white wire of the head unit's harness to your vehicle's parking light circuit.

MIXTRAX Illumination: MIXTRAX features a club-style illumination that enhances the mood with a dynamic dance club-like lighting effect. As MIXTRAX begins, lights start pulsing to the beat of the music, adding an extra level of entertainment. You can choose different patterns of lighting variations from sound pressure level or low-pass synchronization modes. The lighting effects work like a spectrum analyzer, reaching peak colors based on the intensity of the music.

Clock Display: You can select between the receiver's clock display or source display. Pressing and holding the "SRC/OFF" button turns off the head unit's audio output, but the clock display and button illumination remains on (you can then press the "DISP" button to turn off all illumination).

2-DIN Chassis: The Pioneer MVH-X690BS has a 2-DIN chassis (also known as "Double -DIN"), and will fit in many vehicles with a large dash opening. The unit can be ISO-mounted using factory brackets. There is also an optional double-DIN sleeve (130ADTV133, sold separately) available for this unit that will allow you to Euro-mount or custom mount the Pioneer head unit in your vehicle.
