How tweeter design affects sound

A tweeter's shape and composition influence your music

When you're shopping for car speakers, or looking for a way to improve the sound of your car's audio system, consider how important the tweeter is. Both the shape and the material it's made from have a direct impact on how your music sounds.

Alpine tweeter close-up

Close-up of the tweeter on a 2-way car speaker.

Tweeters reproduce the upper frequencies in your music — the vocals, guitars, horns and other high notes that make the music sparkle and come to life. They're also vital for proper soundstaging and stereo separation, so that the music sounds like it's coming from all around you, rather than from down at your knees or ankles.

Manufacturers try to balance several factors when they design a tweeter, including sound quality, sound dispersion, and cost. They want the tweeter to be light, so it moves quickly and easily, yet stiff enough to hold its shape and not distort when the volume is turned up. The ability of the tweeter to stop moving quickly when the music ends — damping — is also very important in creating accurate sound.

To these ends, they employ different tweeter shapes and materials. Understanding the characteristics of these shapes and materials will help you make a better decision about what kind of tweeters you want in your speakers.

Tweeter shapes

The shape of the tweeter determines how effectively it distributes the high frequencies in your car. Different tweeter shapes are used to get the best possible performance out of a given material at a certain price point. Here are some of the most commonly used tweeter designs.

The cone tweeter

The cone tweeter is the most common design in car audio, especially in factory speakers, because it's the least expensive to produce. Many factory tweeters use the infamous "whizzer cone" design, a paper megaphone that's built into the woofer to increase treble response. This shape doesn't spread the sound as widely as other designs, and the cheap materials used in many factory speakers do a poor job of accurately reproducing sound.

The semi-dome tweeter

A common design used in lower-cost speakers is the semi-dome, or balanced-dome, tweeter. The semi-dome features a small dome nestled inside a shallow cone. In a balanced-dome tweeter, the cone and dome are roughly equal in size.

This design allows the use of softer, less rigid materials.

Kicker speaker with semi-dome

This Kicker 6"x8" speaker employs a balanced-dome tweeter.

Semi-dome tweeters have a relatively low profile that makes them less prone to damage from a too-tight mounting space. You'll find semi-dome tweeters almost exclusively used in coaxial speakers, and rarely in separate tweeters or the tweeters in component speaker systems.

The dome tweeter

The dome tweeter is a step up from the semi-dome tweeter, primarily because of improved sound dispersion.

The dome shape radiates sound with a wider dispersion pattern than the semi-dome design. Since high-frequency sound waves are very directional, a wider dispersion of the sound waves will give you a larger "sweet spot" to work with when setting up your system.

Polk Audio db461p tweeter

Dome tweeters, like those on this plate-style speaker, are the most common design used in component speakers.

You'll often see the size of a dome tweeter listed with the speaker's details. A larger dome will disperse sound more effectively, but may require more power to be driven properly.

Other variations

Focal turns the dome tweeter upside-down with their inverted-dome design. As the name suggests, the inverted dome doesn't protrude up from the tweeter's voice coil, but rather sits upside down, like a crater in the center. This design improves the sound radiation pattern and efficiency of the tweeter, like a cone, while providing superior control.

Focal Access inverted dome tweeter

Many Focal speakers use an inverted dome tweeter design.

Materials — the big three

C.M.M.D., Kaladex, Mylar, PET, titanium, aluminum, polyimide, silk, beryllium — that's only a partial list of what you'll find when you start digging into tweeter materials. But once you get past the technical terms, you'll find there are three basic classes of materials used in tweeter construction.

Synthetic films

Synthetic films, like Mylar, polyimide, and PET have several desirable attributes. They're resistant to humidity — important in the extremes of the car environment — and they're light. Since they're light, film tweeters don't need a lot of power to drive them effectively. This makes film tweeters a good choice for lower-powered systems and speakers. On the downside, the lack of stiffness in the material means they have poor damping characteristics, and aren't the most accurate in musical reproduction.


The big player in the textile category is silk. Silk and silk-blend tweeters tend to sound warm, mellow, and refined. And silk is commonly used in good-quality home speakers to achieve a balanced, lifelike tone in the music. Silk tweeters designed for high power handling are often reinforced with synthetic materials that add extra stiffness for improved damping, so they can pump out the volume while still keeping things smooth and maintaining accuracy.

Metals and blends

If you like your highs crisp, bright, and loud, metal tweeters may be the choice for you. Aluminum is the most common. It's light, strong, and produces a bright sound at high frequencies. It's a good choice when you want to ensure that the highs cut through road noise and big bass.

Focal Polyglass tweeter

This Focal tweeter is made of an aluminum and magnesium blend.

Titanium is a popular material, because it is extremely light and less resonant than aluminum. These qualities allow it to reproduce high frequencies with extreme accuracy, but without the harsh edge that some audio enthusiasts attribute to aluminum tweeters.

Speaker manufacturers are always looking for new materials to improve tweeter designs so that they'll play music more accurately and with better clarity than the more mundane designs. Expect the range of exotic metals composite materials, like ceramic/metal and metal/metal blends, to expand over time.

Choosing between textile and metal

The real trick in buying speakers is knowing when to get silk and when to get metal.

  • If you have a lot of road noise or drive on the highway with the windows down, metal tweeters can cut through all that noise and maintain a clear sound.
  • If noise isn't a problem, or your vehicle's interior is mostly hard plastic, silk might give your music a more natural sound.

Other details about tweeter design

Knowing a little about a tweeter's shape and composition can help you understand more about the performance you can expect. Here are a few other details about tweeter design to consider.

Wave guides

Wave guides improve the sound radiation pattern of the tweeter, ensuring that the highs are more evenly broadcast. They also serve to direct the sound waves toward your listening position for better stereo imaging.

Alpine SPS-610 speaker

This Alpine speaker uses a wave guide to improve the tweeter's sound radiation.

Ferro-fluid cooling

Ferro-fluids are magnetic fluids that stick to the tweeter's voice coil. Tweeters designed for high power handling might use ferro-fluid cooling to help dissipate heat when the tweeter is being driven hard.

Coaxials or separates?

Tweeters are either integrated into a full-range speaker, like a coaxial speaker, or mounted separately from the woofer, as in component speaker systems or stand-alone tweeters. This positioning helps — the higher the tweeter is mounted in your car, the better it can spread the music (that's simplistic, but you get the idea). More important though, is how the tweeter is built. A low-quality tweeter is going to sound bad no matter where you mount it.

3-way and 4-way speakers

"3-way" or "4-way" speakers have more than one tweeter, and this design lets the speaker focus even more on separating the different sonic frequencies. A 3-way speaker adds either a midrange driver (for enhanced warmth in the music) or a supertweeter (for extended high-frequency response). A 4-way speaker adds both.

Infinity Primus PR9603is speaker

This Infinity 6"x9" car speaker has a 1" edge-driven tweeter and a 5/9" piezo supertweeter.

Get Everything You Need

Foam baffles protect your speakers from dust and moisture.

Bass blockers improve smaller speakers' efficiency by removing low frequencies they weren't designed to handle.

The right tools make removing a door panel a lot easier.

A Dynamat speaker kit lowers noise levels inside your vehicle, giving you improved clarity, volume, and bass response from your speakers.

Remember the tweeter

When you're shopping for speakers, it's easy to get carried away with checking specs — power handling, frequency response, and the like. Those numbers are important, but remember that the tweeter — how it's designed and what it's made of — will have a big effect on how your music sounds when you turn on the receiver.

For more information

Read our Glossary of Speaker Materials, or check out this entry from our Car Speakers FAQ — "What's the most affordable way to get crisper highs and better stereo imaging in my car?"

And use our Vehicle Selector to find out what fits in your car, then contact us if you have any questions.

  • Mark Dulaney from Louisa, Va.

    Posted on 3/8/2023

    Soft dome tweeters with FS of 2500khz and up with custom passive crossover 12db or more!

  • Dave Trayford from Lexington

    Posted on 3/10/2022

    nicely done...great learning experience that will help me and I expect others when selecting tweeters and other speakers for complementary speaker sound and performance!

  • Walt from Fitzgerald

    Posted on 1/22/2021

    I've used them all over the years. The best sounding tweeter I have owned were a pair of Pyle 1" silk dome from the 90's. Their frequency range was jaw dropping.

  • Donnie from Emerald Isle NC

    Posted on 12/31/2020

    you do not explain 'edge driven'. Compared to what 'driven'. What is best / why? thanks I am on the verge of ordering but... do tell. If I gotta take the whole door off, and put in the dynamat... I want to do this for the 'last ' time, ya know?

    Commenter image

    Alexander H. from Crutchfield

    on 12/31/2020

    Donnie, give us a call with any questions. An edge-driven dome is superior to a balanced dome design, building more surface area into a compact structure for minimal distortion at higher volumes.
  • Kevin Junek from Cameron

    Posted on 8/21/2020

    Hello from texas, I've been trying to research the best speakers/tweeters for my taste in music, my first pair of Memphis coaxials, the tweeters would always crack, the speakers were getting their rms and my eq seemed relatively relaxed. Im currently rocking Rockford fosgate 6x9 3 ways and ive been wondering about the infinity 6x9 component, some reviews mention that the tweeters crackle at higher volumes, could you recommend a set of tweeters that could maybe run with the infinity crossovers(not sure if thats a thing) but still have that amazing sound for pop and folk music. THANKS

  • steve kern from Palm Harbor

    Posted on 7/13/2020

    Great stuff, thanks for the info. You mentioned Beryllium. You carry the Focal Beryllium tweeters, big bucks. Do they give you that much better sound than other upper end tweeters that are way less expensive?

  • Jack Deckard from Columbus OH

    Posted on 1/28/2019

    I prefer silk dome tweeters in any speaker I can afford, but the best may be ribbons.

  • Greg Lancaster from Belton

    Posted on 11/21/2018

    Thanks for a fantastic and informative article, Ken! My first musical experiences as a child including 1" Silk Dome tweeters, so I've always gravitated to them in my multiple car stereo projects. Have Ribbon Tweeters gone the way of the grave? Just wondering, I never had any personal experiences with that form. Thanks again, you guys rock.

    Commenter image

    Alexander H. from Crutchfield

    on 11/23/2018

    Thanks, Greg. You're more likely to see ribbon tweeters in home audio than car audio.
  • James from Twin Lakes, WI

    Posted on 11/19/2018

    All it says about the tweeters in my JBL component set is "3/4" edge driven tweeter." Where does that fit in?

    Commenter image

    Alexander H. from Crutchfield

    on 11/20/2018

    James, an edge-driven dome design allows wider dispersion of your highs and tends to have less distortion in the ultra-high frequencies. That wider dispersion pattern gives you a more accurate sweet spot to work with when tweaking your EQ settings.
  • Robert A. Masters Sr. from Ohatchee

    Posted on 6/30/2018

    Whatzz up, I have a very hard time explaining the sound I'm looking for at audio stores. I have a high frequency hearing loss, making it tough to hear that crispy clean simble sound from groups like Santana (I'm old, ok)??. I had in a 81 Bronco a Sony receiver 45W X 4 ch to a Sony forgot watts X 4 ch to some very nice 6 or 6 1/2 Rockford Fosgate in the doors with separate crossovers & GREAT sounding tweets plus 2 nice 12" subs mounted in rear panels. This sounded as good if not better than a high end home sterio I purchased overseas in the Army!!! And definitely better than home unit I have now, beleived to be caused speakers I purchased a while back, back to that later. I want to update a old 01 Silverado I purchased new & finally the CD stopped working and given me a excuse to update ??. I don't know if you can make heads or tails of what I'm saying or the sound I'm going for, if so you'll be the 1st. Now that sounds are out the way, along with ur suggestions on that, l'm also looking for a receiver that has is Apple compatible, good GPS and a decent backup camera. Do to 20 back surgeries & more to come (no kidding) I refuse to give in, but have difficulty twisting to look back to hook up my boat, I mean a lot of in & out to see. Let's just say I remember my 65 BD,?? and my lovely wife I married at 17 & me at 19, died a few years back use to help me back up, but I'm it now. Please if you don't mind, let me know of any suggestions or recom. No chart. left 4 home speakers

    Commenter image

    Alexander Hrabe from Crutchfield

    on 7/2/2018

    Robert, we're certainly game to help! I've passed your questions along to our Advisors. Someone will contact you soon to get to the bottom of that perfect sound!
